功能模拟输出
拟输出–CC-PAON01功能模拟输出（AO）模块向致动器和记录/指示装置提供高电平恒定电流。值得注意的功能•广泛的自我诊断•可选冗余•每个通道可配置的安全状态（FAILOPT）行为•输出回读和差异报警•非易燃输出FAILOPC系列AO模块支持每个通道的FAILOPD参数。用户可以将每个通道配置为保持最后一个值或设置为安全值。如果IOM设备电子设备发生故障，输出将始终归零，即安全状态。开路检测此C系列IO功能将能够通过通道软故障指示来检测和通知开路现场线详细规范-高级模拟输出参数规范输入/输出型号CC-PAON01-高级模拟输入IOTA型号CC-TAON01非冗余6“CC-TAON 11冗余12”输出类型4-20 mA输出通道16输出纹波<100电源线频率下的峰间电压为mV
At power line frequency
Lower peak value to peak value, across 250 Ω load Output temperature drift 0.005% Full scale/° C Output back reading accuracy ± 4% Full scale output current linearity ± 0.05% Full scale nominal resolution ± 0.05% Full scale calibration accuracy ± 0.35% Full scale (25oC), including linearity Direct setting output current range 0 mA, 2.9 mA to 21.1 mA maximum resistive load (24 V power supply=22 VDC to 28 VDC) 800 ohms maximum output compatible voltage (24 V power supply=22 VDC to 28 VDC) 16 V Experion Series-C I/O specification, EP03-490-520 26 version 1.5 Honeywell proprietary 2021 December parameter specification The maximum open circuit voltage 22 V response time (DAC input code to output) settles to within 1% of the final value within the 80 millisecond gap (0 mA) when the output is switched to the site in the maximum 10 milliseconds (only applicable to redundancy) Experience Series-C input/output specification, EP03-49 0-520 27 version 1.5 Honeywell proprietary 2021 December 5.11.
Function analog output
Intended Output – The CC-PAON01 functional analog output (AO) module provides a high level constant current to the actuator and the recording/indicating device. Notable functions • Extensive self diagnosis • Optional redundancy • Configurable safe state (FAILOPT) behavior for each channel • Output readback and differential alarm • Non incendive output FAILOPC series AO modules support FAILOPD parameters for each channel. You can configure each channel to hold the last value or set it as a safe value. If the electronic device of the IOM device fails, the output will always return to zero, that is, the safe state. Open circuit detection This C series IO function will be able to detect and notify the open circuit field line detailed specification - advanced analog output parameter specification Input/output model CC-PAON01 - advanced analog input IOTA model CC-TAON01 non redundant 6 "CC-TAON 11 redundant 12" output type 4-20 mA output channel 16 Output ripple<100 Peak to peak voltage at power line frequency is mV
