DS200TBQCG1AAA工控备件
跨越250 负载输出
温度漂移0.005%满量程/°C输出回读精度±4%满量程输出电流线性度±0.05%满量程标称分辨率±0.05%全量程校准精度±0.35%满量程（25oC），包括线性度直接设定输出电流范围0 mA，2.9 mA至21.1 mA最大电阻负载（24 V电源=22 VDC至28 VDC）800欧姆最大输出兼容电压（24 V供电=22 VDC到28 VDC）16 V最大开路电压22 V响应时间（DAC输入代码到输出）在80 ms内稳定在最终值的1%以内Experion Series-C输入/输出规范，EP03-490-520 29版本1.5霍尼韦尔专有2021 12月5.12。
功能数字输入
数字输入24VDC–CC-PDIL01功能数字输入24VDC接受24VDC信号作为离散输入。值得注意的功能•广泛的数据完整性内部诊断•开路检测•可选冗余•内部或外部磁场电源选择•车载励磁电源（无需编组电源）•提供非易燃磁场电源•直接/反向输入指示•电流隔离开路不良PV检测此C系列IO功能将能够检测并通知开路场线。此外，来自被诊断为开路的通道的看似有效的PV将提供“无效”状态（从而防止不正确的控制动作）。
Output across 250 Ω load
Temperature drift 0.005% of full scale/° C Output back reading accuracy ± 4% of full scale output current linearity ± 0.05% of full scale nominal resolution ± 0.05% of full scale calibration accuracy ± 0.35% of full scale (25oC), including linearity directly setting output current range 0 mA, 2.9 mA to 21.1 mA maximum resistive load (24 V power supply=22 VDC to 28 VDC) 800 ohm maximum output compatible voltage (24 V power supply=22 VDC to 28 VDC) 16 V maximum open circuit voltage 22 V response time (DAC input code to output) is stable within 1% of the final value within 80 ms. Experion Series-C input/output specification, EP03-490-520 29 version 1.5 Honeywell proprietary December 5.12, 2021.
Function digital input
Digital input 24VDC – CC-PDIL01 function Digital input 24VDC accepts 24VDC signal as discrete input. Notable functions • Extensive data integrity internal diagnosis • Open circuit detection • Optional redundancy • Selection of internal or external magnetic field power supply • On board excitation power supply (without marshalling power supply) • Providing non flammable magnetic field power supply • Direct/reverse input indication • Current isolation and poor open circuit PV detection This C series IO function will be able to detect and notify open circuit field lines. In addition, a seemingly valid PV from a channel diagnosed as open will provide an "invalid" state (thus preventing incorrect control actions).
