DS200TCQCG1BFE模拟量输入模块
电压：
5V至60VDC电流：0.001A至2A关断状态泄漏电流，最大值100uA，60VDC仪表套件规格（2）支持的校验仪脉冲输出功能从选定的双通道对提供“良好脉冲”，以支持校验仪应用。最多支持5个脉冲IOTA总线连接在一起。校准仪电气特性开式发射器源极驱动器-参考系统接地开路电压：22V短路电流限制：35mA脉冲数据保真度符合ISO 6551:1995规定的A级保真度注1：可选的交流继电器（51190516-332）可替代提供的直流继电器，以提供交流切断信号。切断时间延长至交流电源信号的一个线路周期。注2：需要MeterSuite应用注3：对于双通道操作，最小可检测脉冲宽度为10us。（双流配置具有“内置”10us脉宽抑制功能）Experion Series-C输入/输出规范，EP03-490-520 21版本1.5霍尼韦尔专有2021 12月8。模拟输出具有HART–CC-PAOH01功能模拟输出（AO）模块向执行器和记录/指示设备提供高电平恒定电流。
显著特点
•广泛的自我诊断•可选冗余•支持HART，多变量仪表•多个调制解调器用于快速收集控制变量•安全状态（FAILOPT）行为可按每个通道配置•输出回读和差异报警•非易燃输出FAILOPC系列AO模块支持按每个通道的FAILOPD参数。用户可以将每个通道配置为保持最后一个值或设置为安全值。如果IOM设备电子设备发生故障，输出将始终归零，即安全状态。开路检测此C系列IO功能将能够检测并通过通道软故障指示通知开路现场线。详细规范–HART模拟输出
参数规范输入/输出型号CC-PAOH01-带HART IOTA型号CC-TAOX01的高电平模拟输出，非冗余6“CC-TAOX11冗余12”CC-GAOX11非冗余12“CC-GAOX21非冗余6”输出类型4-20 mA输出通道16输出纹波<100 mV
Voltage:
5V to 60VDC current: 0.001A to 2A off state leakage current, maximum 100uA, 60VDC instrument kit specification (2) The supported calibrator pulse output function provides "good pulse" from the selected dual channel pair to support the calibrator application. Up to 5 pulse IOTA buses can be connected together. Electrical characteristics of the calibrator Open transmitter source driver Reference system Ground open circuit voltage: 22V Short circuit current limit: 35mA Pulse data fidelity in accordance with ISO 6551:1995 Class A Fidelity Note 1: The optional AC relay (51190516-332) can replace the DC relay provided to provide an AC cut-off signal. The cut-off time is extended to one line cycle of the AC power signal. Note 2: MeterSuite application is required Note 3: For dual channel operation, the minimum detectable pulse width is 10us. (Dual stream configuration has "built-in" 10us pulse width suppression function) Experion Series-C input/output specification, EP03-490-520 21 version 1.5 Honeywell proprietary December 8, 2021. Analog output with HART – CC-PAOH01 function Analog output (AO) module provides high level constant current to actuator and recording/indicating equipment.
Salient features
• Extensive self diagnosis • Optional redundancy • Support HART, multivariable instruments • Multiple modems for fast collection of control variables • Safe state (FAILOPT) behavior can be configured per channel • Output readback and differential alarm • Non incendive output FAILOPC series AO modules support FAILOPD parameters per channel. You can configure each channel to hold the last value or set it as a safe value. If the electronic device of the IOM device fails, the output will always return to zero, that is, the safe state. Open circuit detection This C series IO function will be able to detect and notify open circuit field lines through channel soft fault indication. Detail Specification – HART Analog Output
Parameter specification Input/output model CC-PAOH01 High level analog output with HART IOTA model CC-TAOX01, non redundant 6 "CC-TAOX11 redundant 12" CC-GAOX11 non redundant 12 "CC-GAOX21 non redundant 6" output type 4-20 mA output channel 16 output ripple<100 mV
