D0801 工控模块前置控制器
重复步骤
① 设置重复步骤。② 如果您想以相同的模式重复特定的步骤部分，这是一个方便的功能。③ 在开始重复步骤号的REPEAT中设置“00”，在结束重复步骤号REPEAT设置“REPEAT count”。如果设置了“01”，则设置的步骤重复部分将重复一次，因此整个相同的重复步骤部分将运行两次。④ 在相同的模式下，步骤重复设置可以进行任意次数。但是，不能设置重复部分的重复和大重复中的小重复。设置多组重复步骤时，设置方式应确保“00”和重复计数设置始终在模式中交替配对。⑤ 在此设置屏幕的右上角，显示正在设置的步骤的捕捉格式。
复位时的SV
① 在模拟输出规格、数字输出规格或通信规格的情况下，当选择[TRANS]（传输）时，将显示该选项。② 重置时设置SV。③ 当按变速器类型选择“SV”时，复位时的变速器值变为该设定值。11.时间单位① 设置与节目模式和时间信号相关的公共时间单位。② 如果选择“小时：分钟”，则变为“小时：最小”。③ 如果选择“MIN:SEC”，则变为“MIN:SEC”。④ 程序运行时无法更改此设置。-30-7-5.模式5模式5执行与SV相关的设置。
Repeat step
① Set the repeating step. ② This is a convenient feature if you want to repeat specific steps in the same pattern. ③ Set "00" in the REPEAT of the start repeating step number, and set "REPEAT count" in the REPEAT of the end repeating step number. If "01" is set, the set step repeating part will repeat once, so the entire same repeating step part will run twice. ④ In the same mode, the step repeat setting can be performed for any number of times. However, you cannot set the repetition of the repeated part and the small repetition in the large repetition. When setting multiple groups of repeat steps, the setting method should ensure that "00" and repeat count settings are always paired alternately in the mode. ⑤ In the upper right corner of the setting screen, the snap format of the step being set is displayed.
SV at reset
① In the case of an analog output specification, a digital output specification, or a communication specification, this option is displayed when [TRANS] is selected. ② Set SV on reset. ③ When "SV" is selected according to the transmission type, the transmission value during reset will change to the set value. 11. Time unit ① Set the public time unit related to program mode and time signal. ② If "hour: minute" is selected, it becomes "hour: minimum". ③ If "MIN: SEC" is selected, it becomes "MIN: SEC". ④ This setting cannot be changed while the program is running- 30-7-5. Mode 5 Mode 5 executes SV related settings.
