模式屏幕
锁定状态][显示关闭状态]① 模式2屏幕。② 通过单击･ 键，显示“锁定”和“无显示”。③ 对于模式2设置屏幕，如果要禁止更改设置，请选择“锁定”。④ 通过通信进行设置时，将所有模式屏幕设置为“锁定”。⑤ 当不显示模式2的设置屏幕时，选择“无显示”。2.程序模式① 设置时间和SV，这是程序模式的基础。② 'PTN’表示（程序）模式，可以设置从01到30的模式号。选择任意数字并设置图案。③ 'STEP’表示步长，每个模式最多可设置19个步长。④ 设置标准SV，使“SV”最终达到该步骤。当SV小数点、SV刻度等发生变化时，有时小数点位置会自动发生变化，因此要小心。⑤ 'TIME”设置该步骤所需的时间。可以在模式2的“时间单位”中设置单位，可以选择“小时：分钟”或“分钟：秒”。⑥ 设置程序如下选择图案编号。▪在步骤编号00的“SV”中设置启动SV的设置值。考虑步骤编号01并设置SV和初始步骤的时间。
SV的设定范围在设定范围内
时间的设置范围在“000:00”到“999:59”的范围内。通过设置“000:00”，还可以考虑瞬时设置的SV（逐步设置）同样，下一步，设置SV和TIME，并将其与所需的程序模式相结合该设置过程成为标准规范中存在的称为标准SV系统的系统。在选项中，有一种叫做斜率SV系统的东西。对于该系统，在“SV”中设置每个单位时间的SV变化，并在“time”中设置时间，直到SV变化可以继续。-28-･与所需的程序模式组合，当您想退出设置时，在最后一步的时间中设置“END/LINK00”，从而结束模式设置。在初始设置状态下，“END/LINK00”始终在最后一步设置当您想链接（链接另一个图案）一个图案时，请在最后一步的“END/LINK00”的link右侧的“00”中设置要链接的图案编号。当连接多个模式并将结束模式连接到第一个模式时，或将其中一个模式设置为自身链接时，将成为无限循环。然后模式重复不受影响如果要删除某个步骤，请在要删除的步骤编号的时间中设置“STEPDELETE”。该步骤的内容将被删除，下一步的步骤编号将自动更新如果要插入某个步骤，请在要插入的步骤编号的时间中设置“STEPINSERT”。插入与所选步骤的每个参数相同的内容，并自动更新从下一步开始的步骤编号。
Mode screen
Lock Status] [Display Closed Status] ① Mode 2 screen. ② Click the Element key to display "Lock" and "No Display". ③ For the Mode 2 settings screen, select Lock if you want to prevent changing settings. ④ When setting through communication, set all mode screens to "locked". ⑤ When the setting screen of mode 2 is not displayed, select "No Display". 2. Program mode ① Set time and SV, which is the basis of program mode. ② 'PTN' indicates the (program) mode, and the mode number from 01 to 30 can be set. Select any number and set the pattern. ③ 'STEP' indicates the step size. Each mode can set up to 19 steps. ④ Set the standard SV so that "SV" finally reaches this step. When the SV decimal point and SV scale change, sometimes the decimal point position will automatically change, so be careful. ⑤ 'TIME' sets the time required for this step. You can set the unit in "Time Unit" of mode 2. You can select "Hour: Minute" or "Minute: Second". ⑥ The setup procedure is as follows to select the pattern number. ▪ Set the setting value for starting SV in "SV" of step No. 00. Consider step number 01 and set the time for SV and initial step.
The setting range of SV is within the setting range
