CI858K01工控模块
ABB能力
-TU830V1 ™ System 800xA®硬件选择器数据表TU830V1 MTU可具有多达16个I/O通道和两个过程电压连接。每个通道有两个I/O连接和一个ZP连接。MTU是一个无源单元，用于将现场接线连接到I/O模块。它还包含ModuleBus的一部分。工艺电压可以连接到两个单独隔离的组。每组有一个6.3 a保险丝。最大额定电压为50 V，最大额定电流为每通道2 A。MTU将模块总线分配到I/O模块端到下一个MTU。它还通过将输出位置信号移位到下一个MTU，为I/O模块生成正确的地址。特点和优点使用三线连接、保险丝和现场配电完成I/O模块的安装。
电源连接
多达16路现场信号和过程电源连接。模块总线和I/O模块的连接。机械键控可防止插入错误的I/O模块。用于接地的DIN导轨锁紧装置。DIN导轨安装。一般信息产品编号3BSE013234R1型扩展连接端子排通道16电压50 V安装双向安装详图55ºC（131°F）与I/O AI810、AI815、AI820、AI830、AI820A、AI835、AI835A、AI843、AI845、AO810、AO810V2、AO815、AO820、AO845、AO845A、DI810、DI811、DI814、DI818、DI830、DI831、DI840、DI880、DI825、DO814、DO815、DO828、DO840、DO880，DP820和DP840工艺连接56单/冗余I/O单1数据表TU830V1 | 2022-11-10 |版权所有©2022 ABB详细数据每个I/O通道的最大电流2 A最大电流工艺连接5 A可接受的导线尺寸实心：0.2-4mm²绞合：0.2-2.5 mm²，24-12 AWG建议扭矩：0.5-0.6 Nm剥离长度：7 mm绝缘测试电压500 V A.c
ABB capabilities
-TU830V1 ™ System 800xA ® The hardware selector data sheet TU830V1 MTU can have up to 16 I/O channels and two process voltage connections. Each channel has two I/O connections and one ZP connection. The MTU is a passive unit used to connect field wiring to the I/O modules. It also contains part of ModuleBus. The process voltage can be connected to two separate isolated groups. Each group has a 6.3 a fuse. The maximum rated voltage is 50 V and the maximum rated current is 2 A per channel. The MTU assigns the module bus to the I/O module end to the next MTU. It also generates the correct address for the I/O module by shifting the output position signal to the next MTU. Features and advantages The installation of I/O modules is completed using three wire connections, fuses and field power distribution.
Power connection
Up to 16 field signals and process power connections. Module bus and I/O module connections. Mechanical keying prevents incorrect I/O modules from being inserted. DIN rail locking device for grounding. DIN rail mounting. General Information Product No. 3BSE013,234R1 Type Extended Connection Terminal Block Channel 16 Voltage 50 V Installation Details 55 º C (131 ° F) and I/O AI810, AI815, AI820, AI830, AI820A, AI835, AI835A, AI843, AI845, AO810, AO810V2, AO815, AO820, AO845, AO845A, DI810, DI811, DI814, DI818, DI830, DI831, DI840, DI880, DI825, DO814, DO815, DO825 8. DO840, DO880, DP820 and DP840 process connection 56 single/redundant I/O single 1 data sheet TU830V1 | 2022-11-10 | All rights reserved © 2022 ABB detailed data Maximum current per I/O channel 2 A Maximum current Process connection 5 A Acceptable wire size Solid: 0.2-4mm ² Stranding: 0.2-2.5 mm ²， 24-12 AWG Recommended torque: 0.5-0.6 Nm Peel length: 7 mm Insulation test voltage 500 V A.c
