CI856机器人模块卡件
模拟输出
隔离− 致动器输出信号0/4…20 mA− 短路和断路检测− 输出/总线和输出/电源之间的电气隔离− 通道间的电气隔离− 4通道，EEx ia II C名称简短描述文章编号AO920S模拟输出，隔离（AO4I Ex）输出0/4…20 mA。逐个通道隔离输出。3KDE175531L9200 AO920B模拟输出，隔离（AO4I-B）输出0/4…20 mA。逐个通道隔离输出。3KDE175532L9200 AO920N模拟输出，隔离（AO4I）输出0/4…20 mA。逐个通道隔离输出。3KDE175533L9200模拟输出模拟输出，HART− 致动器输出信号0/4…20 mA− 短路和断路检测− 输出/总线和输出/电源之间的电气隔离− 带公共接地的输出− 4通道，EEx ia II C− 通过现场总线传输HART帧名称简短描述文章编号：AO930S模拟输出、HART（AO4H Ex）输出0/4…20 mA。3KDE175531L9300 AO930B模拟输出，HART（AO4H-B）输出0/4…20 mA。3KDE275532L9300 A0930N模拟输出、HART（AO4 H）输出0/0…20 mA.3KDE175 533L9300系统800xA产品目录| S900 I/O 73现场外壳− 扩展终端装置的不锈钢现场外壳− 准备用于墙壁安装− 可选隔离屏蔽条或端子− 安装在1区或2区名称简短描述物品编号FH660S-0000空现场外壳，无系统证书3KDE175804L FH660 S-0100
现场外壳包括以下组件：
终端单元（背板）TU921S 1电源滤波器BP901S。3KDE175804V0100 FH660S-1100现场外壳包括以下组件：终端单元（背板）TU921S 2端子（UK10N）1电源滤波器BP901S。3KDE175804V1100 FH660S-1110现场外壳包括以下组件：终端单元（底板）TU921S 2端子（UK10N）1电源滤波器BP901S 1开关。3KDE175804V1110 FH660S-0200现场外壳包括以下组件：终端单元（背板）TU921S 2电源滤波器BP901S。3KDE175804V0200 FH660S-2200现场外壳包括以下组件：终端单元（背板）TU921S 4端子（UK10N）2电源滤波器BP901S。3KDE175804V2200 FH660S-2220现场外壳包括以下组件：终端单元（底板）TU921S 4端子（UK10N）2电源滤波器BP901S 2开关。3KDE175804V2220 600 300 275仰视图FH660S 600侧视图FF660S 540 600 635正面（内部）视图FH660现场外壳74 S900 I/O |系统800xA产品目录现场外壳名称简短描述物品编号FH680S-0000空现场外壳，无系统证书3KDE175811L FH680S-0100现场外壳包括以下组件：终端单元（背板）TU921S 1电源滤波器BP901S。3KDE175811V0100 FH680S-0110现场外壳包括以下组件：终端单元（背板）TU921S 1电源滤波器BP901S 1开关。3KDE175811V0110 FH680S-0200现场外壳包括以下组件：终端单元（背板）TU921S 2电源滤波器BP901S。3KDE175811V0200 FH680S-0220现场外壳包括以下组件：终端单元（背板）TU921S 2电源滤波器BP901S 2开关。3KDE175811V0220附件名称简短描述物品编号S900-BI100现场外壳屋顶防风雨。适用于所有现场外壳。3 kde175831l1000
Analog Output
Isolation − actuator output signal 0/4... 20 mA − short circuit and open circuit detection − electrical isolation between output/bus and output/power supply − electrical isolation between channels − 4 channels, EEx ia II C name Short description Article No. AO920S analog output, isolated (AO4I Ex) output 0/4... 20 mA. Isolate the output channel by channel. 3KDE175531L9200 AO920B analog output, isolated (AO4I-B) output 0/4... 20 mA. Isolate the output channel by channel. 3KDE175532L9200 AO920N analog output, isolated (AO4I) output 0/4... 20 mA. Isolate the output channel by channel. 3KDE175533L9200 analog output analog output, HART − actuator output signal 0/4... 20 mA − short circuit and open circuit detection − electrical isolation between output/bus and output/power supply − output − 4 channels with common grounding, EEx ia II C − HART frame name transmitted via field bus Short description Article No.: AO930S analog output, HART (AO4H Ex) output 0/4... 20 mA. 3KDE175531L9300 AO930B analog output, HART (AO4H-B) output 0/4... 20 mA. 3KDE275532L9300 A0930N analog output, HART (AO4 H) output 0/0... 20 mA. 3KDE175 533L9300 system 800xA product catalog | S900 I/O 73 field enclosure − stainless steel field enclosure for expansion terminal device − ready for wall mounting − optional isolation shield strip or terminal − installed in Zone 1 or Zone 2 name Short description Article No. FH660S-0000 Empty field enclosure, no system certificate 3KDE175804L FH660 S-0100
The field enclosure includes the following components:
Terminal unit (backplane) TU921S 1 power filter BP901S. The 3KDE175804V0100 FH660S-1100 field enclosure includes the following components: terminal unit (backplane) TU921S 2 terminal (UK10N) 1 power filter BP901S. The 3KDE175804V1100 FH660S-1110 field enclosure includes the following components: terminal unit (backplane) TU921S 2 terminal (UK10N) 1 power filter BP901S 1 switch. The 3KDE175804V1110 FH660S-0200 field enclosure includes the following components: terminal unit (backplane) TU921S 2 power filter BP901S. The 3KDE175804V0200 FH660S-2200 field enclosure includes the following components: terminal unit (backplane) TU921S 4 terminal (UK10N) 2 power filter BP901S. The 3KDE175,804V2200 FH660S-2220 field enclosure includes the following components: terminal unit (backplane) TU921S 4 terminal (UK10N) 2 power filter BP901S 2 switch. 3KDE175804V2220 600 300 275 front view FH660S 600 side view FF660S 540 600 635 front (interior) view FH660 field enclosure 74 S900 I/O | system 800xA product catalog field enclosure name short description article number FH680S-0000 empty field enclosure, no system certificate 3KDE175811L FH680S-0100 field enclosure includes the following components: terminal unit (backplane) TU921S 1 power filter BP901S. The 3KDE175811V0100 FH680S-0110 field enclosure includes the following components: terminal unit (backplane) TU921S 1 power filter BP901S 1 switch. The 3KDE175,811V0110 FH680S-0200 field enclosure includes the following components: terminal unit (backplane) TU921S 2 power filter BP901S. The 3KDE175811V0200 FH680S-0220 field enclosure includes the following components: terminal unit (backplane) TU921S 2 power filter BP901S 2 switch. 3KDE175811V0220 Attachment Name Short Description Item No. S900-BI100 Site Shell Roof Weatherproof. Suitable for all field enclosures. 3 kde175831l1000
