CI854AK01机器人模块
光纤端口
TB811 Modulebus光纤端口，G2兼容，与CI810、CI820、CI830一起使用。与ABB Drives设备一起使用。（5 Mbits驱动器）。3BSE008568R1 TB842模块总线光端口与CI801和CI840一起使用，通过TB806或TB846连接。（10 Mbits驱动器）。3BSE022464R1 TU807终端单元，用于TB840/TB840A，支持单模块总线I/O。包括：1个TB807.3BSE039025R1 TU840终端单元，用于1+1 TB840。支持冗余I/O。包括：1个电源连接器2个TB807 Modulebus终端器3BSE020846R1 62 S800 I/O | System 800xA产品目录Modulebus通信部件Modulebus通讯部件产品编号TU841 1+1 TB840终端单元支持非冗余I/O。包括：1个电源连接器1个TB807模块总线终端器3BSE020848R1 TU848，MTU，带红色独立电源。TB840/TB840A支持双模块总线。包括：2个TB807 3BSE042558R1 TU849，MTU，带红色独立电源。TB840/TB840A支持单模块总线。包括：1根TB807 3BSE042560R1 TK811V015 POF电缆，1.5 m，双工。L=1.5 m锁定双工连接器双工塑料纤维。3BSC950107R1 TK811V050 POF电缆，5 m，双工。L=5 m锁定双工连接器双工塑料纤维。3BSC950107R2 TK811V150 POF电缆，15米，双工。L=15 m锁定双工连接器双工塑料纤维。3BSC950107R3 TK812V015 POF电缆，1.5 m，单工。L=1.5 m闭锁连接器单工塑料纤维。3BSC950118R1 TK812V050 POF电缆，5 m，单工。L=5.0 m闭锁连接器单工塑料纤维。
锁连接器
..3BSC950118R2 TK812V150 POF电缆，15 m，单工。L=15 m闭锁连接器单工塑料纤维。3BSC950118R3系统800xA产品目录| S800 I/O 63电源电源产品编号SD822Z电源设备输入115/230 V交流开关可选，输出24 V直流，5 a。如果需要冗余电源应用，请连接到SS822Z表决单元。宽度=65 mm。DIN导轨安装。3BSC610054R1 SS822Z功率表决装置，双24 V直流20 A输入，单24 V直流20A输出。监控每个电源输入。如果需要冗余电源，则使用。与电源SD822Z一起使用。宽度=50 mm。DIN导轨安装。3BSC610055R1 SD831电源装置，符合G2标准，输入交流100-240 V或直流110-300 V，输出直流24 V 3 a。如果需要冗余电源应用，请连接到SS8XX表决装置。宽度=35 mm。DIN导轨安装。3BSC610064R1 SD832电源设备，G2兼容输入交流100-120/200-240 V，输出直流24 V 5 a，自动选择输入。如果需要冗余电源应用，请连接到SD8XX表决单元。宽度=35 mm。DIN导轨安装。3BSC610065R1 SD833电源设备，G2兼容输入交流100-120/200-240 V，自动选择输入。输出直流24 V 10 A。如果需要冗余电源，请连接到SD8XX表决装置。宽度=60 mm。DIN导轨安装。3BSC610066R1 SD834电源设备，符合G2标准，输入交流100-240 V或直流110-300 V，输出直流24 V 20 a。如果需要冗余电源应用，请连接到SS8XX表决装置。宽度=85 mm。DIN导轨安装。3BSC610067R1 SS832表决装置，G2兼容输入直流24 V，双24 V至单24 V，2 x 10 A。宽度=35 mm。DIN导轨安装。3BSC610068R1型
Optical port
TB811 Modulebus fiber port, G2 compatible, used with CI810, CI820, and CI830. Used with ABB Drives. (5 Mbits drive). 3BSE008568R1 TB842 module bus optical port is used together with CI801 and CI840, and connected through TB806 or TB846. (10 Mbits drive). 3BSE022464R1 TU807 terminal unit, used for TB840/TB840A, supports single module bus I/O. Including: 1 TB807.3BSE039025R1 TU840 terminal unit for 1+1 TB840. Support redundant I/O. Including: 1 power connector, 2 TB807 Modulebus terminals 3BSE020846R1 62 S800 I/O | System 800xA product catalog Modulebus communication parts Modulebus communication parts product number TU841 1+1 TB840 terminal unit supports non redundant I/O. Including: 1 power connector, 1 TB807 module bus terminal 3BSE020848R1 TU848, MTU, with red independent power supply. The TB840/TB840A supports dual module bus. Including: 2 TB807 3BSE042558R1 TU849, MTU, with red independent power supply. The TB840/TB840A supports a single module bus. Including: 1 TB807 3BSE042560R1 TK811V015 POF cable, 1.5m, duplex. L=1.5 m locking duplex connector duplex plastic fiber. 3BSC950107R1 TK811V050 POF cable, 5 m, duplex. L=5 m locking duplex connector duplex plastic fiber. 3BSC950,107R2 TK811V150 POF cable, 15m, duplex. L=15m locking duplex connector duplex plastic fiber. 3BSC950107R3 TK812V015 POF cable, 1.5m, simplex. L=1.5m locking connector simplex plastic fiber. 3BSC950118R1 TK812V050 POF cable, 5 m, simplex. L=5.0 m locking connector simplex plastic fiber.
Lock connector
.. 3BSC950118R2 TK812V150 POF cable, 15 m, simplex. L=15m locking connector simplex plastic fiber. 3BSC950118R3 system 800xA product catalog | S800 I/O 63 power supply product number SD822Z power supply input 115/230 V AC switch is optional, output 24 V DC, 5 a. If redundant power applications are required, connect to the SS822Z voting unit. Width=65 mm. DIN rail mounting. 3BSC610,054R1 SS822Z power voting device, dual 24 V DC 20 A input,吖single 24 V DC 20 A output. Monitor each power input. Use if redundant power is required. Used with power supply SD822Z. Width=50 mm. DIN rail mounting. 3BSC610055R1 SD831 power supply unit, meeting G2 standard, input AC 100-240 V or DC 110-300 V, output DC 24 V 3 a. If redundant power applications are required, connect to the SS8XX voting device. Width=35 mm. DIN rail mounting. 3BSC610064R1 SD832 power supply device, G2 compatible input AC 100-120/200-240 V, output DC 24 V 5 a, automatic input selection. If redundant power applications are required, connect to the SD8XX voting unit. Width=35 mm. DIN rail mounting. 3BSC610065R1 SD833 power supply device, G2 compatible input AC 100-120/200-240 V, automatic selection input. Output DC 24 V 10 A. If a redundant power supply is required, please connect it to the SD8XX voting device. Width=60 mm. DIN rail mounting. The 3BSC610066R1 SD834 power supply device complies with the G2 standard, with the input of AC 100-240 V or DC 110-300 V and the output of DC 24 V 20 a. If redundant power applications are required, connect to the SS8XX voting device. Width=85 mm. DIN rail mounting. 3BSC610067R1 SS832 voting device, G2 compatible input DC 24V, dual 24V to single 24V, 2 x 10 A. Width=35 mm. DIN rail mounting. 3BSC610068R1
