CI810V1工控备件模块
数字输入模块
DI810 16通道，2组8通道，24 V直流，电流吸收器。DI811 16通道，2组8通道，48 V直流，电流吸收器。DI814 16通道，2组8通道，24 V直流，电流源。DI818 32通道，2组16通道，24 V直流，电流吸收器。DI820 8通道，单独回路，110 V直流，120 V交流DI821 8通道，独立回路，220 V直流，230 V交流DI835带时间标签，8通道，分开回路，125 V直流DI828 16通道，单独返回，110 V交流，120 V交流电/直流DI830带时间标签。16通道，2组8通道，24 V直流，电流吸收器。分辨率：<0.5 ms。DI831带时间标记。16通道，2组8通道，48 V直流，电流吸收器。分辨率：<0.5 ms。DI885带有时间标记和电线故障检测。8通道，公共回路，24-48 V直流，电流吸收器。分辨率：1 ms。脉冲输入模块DP820 2通道，独立回路，0.25 Hz-1.5 MHz，信号电压：5/12 V直流，DP840 8通道，扩展诊断，导线故障检测，限流传感器电源，0.5-20 kHz，12/24 V直流或NAMUR，公共回路。数字输出模块DO810 16通道，2组8通道，24 V，最大0.5 A直流，晶体管，电流源，短路保护。DO814 16通道，2组8通道，24 V直流，最大0.5 A，晶体管，电流吸收器，短路保护。DO815 8通道，2组4通道，24 V直流，最大2 A，晶体管，电流源，短路保护，电线故障检测。DO818 32通道，2组16通道，24 V，最大0.5 A直流，晶体管，电流源，短路保护。DO820 8通道，独立回路，5-250 V，最大3 A交流/直流，继电器（常开）。DO821 8通道，独立回路，5-250 V，最大3 A交流/直流，继电器（N.c.）。DO828 16通道，独立回路，5-250 V交流/5-125 V直流，最大2 a交流/直流，继电器（常开）。模拟输入模块AI810 8通道，单端，0（4）-20 mA，0（2）-10 V，12位。带有HART的AI815 8通道。0（4）..20 mA，0（1）..5 V，12位，单端，限流变送器电源。AI820差分输入，4个通道，0（1）-5 V，±0（2）-10 V，？0（4）-20 mA，14位+符号。AI835A TC输入，8通道，（7+参考接点），独立回路。
TC类型B
模拟输出模块AO810V2 8通道，公共回路，0（4）-20 mA，14位，负载：850欧姆（短路保护）。带HART的AO815 8通道。4..20 mA，12位，负载：750欧姆，公共回路，防短路。AO820 4通道，单独电流隔离，单独回路，测量范围：±0（2）-10 V，±0（4）-20 mA，分辨率：12位+符号，负载：500欧姆（电流）/5千欧姆（电压），短路保护。本安模块DI890 8通道，独立回路，接近传感器（NAMUR）或无电压触点。，电流吸收器、电线故障检测。DO890 4通道，独立回路，负载150-5000欧姆，11 V@40 mA，电流源，电线故障检测，短路保护。AI890 8通道，单端，0（4）-20 mA，12位，变送器电源。AI893 8通道，TC:7+参考连接，sep.返回。TC类型B、C、E、J、K、L、N、R、S、T、U、-10…80 mV。RTD：Pt50-1000、Ni100-500、Cu 10-100，电阻器0-4000 W，3线。15位+符号。AI895 8通道，单端，4-20 mA，12位，变送器电源，HART直通。AO890 8通道，公共回路，0（4）-20 mA，12位，负载：725欧姆短路保护。AO895 8通道，公共回路，4-20 mA，12位，负载：725欧姆短路保护，HART直通。冗余模块DI840 16通道，公共回路，24 V直流，电流吸收器，扩展诊断，时间标记，限流传感器电源。DP840 8通道，公共回路，0.5-20 kHz，12/24 V直流或NAMUR，扩展诊断，电线故障检测。DO840 16通道，公共回路，24 V直流，最大0.5 A，晶体管，电流源，短路保护，扩展诊断。AI843 TC输入，8通道+参考接头。TC类型：B、C、E、J、K、L、N、R、S、T、U、-30…75 mV，16位，扩展诊断。AI845 8通道，12位，0（4）-20 mA 0（1）-5 V，扩展诊断，HART直通，限流变送器电源，单端。AO845 8通道，12位，公共回路，4-20 mA，扩展诊断，HART直通，750欧姆。高完整性模块AI880A 4..20 mA，8通道，12位，SIL3，限流变送器电源，也0-20 mA，单端，扩展诊断，HART通信。DI880 24 V直流，16通道，24 V直流输入，SIL3，时间标记，限流传感器电源，公共回路，电流汇，扩展诊断。DO880 24 V直流，16通道，0,5 A输出，SIL3，线路故障检测，24 V，晶体管，电流源短路保护，公共回路，扩展诊断。
Digital input module
DI810 16 channels, 2 groups of 8 channels, 24 V DC, current absorber. DI811 16 channels, 2 groups of 8 channels, 48 V DC, current absorber. DI814 16 channel, 2 groups of 8 channels, 24 V DC, current source. DI818 32 channels, 2 groups of 16 channels, 24 V DC, current absorber. DI820 8-channel, separate circuit, 110 V DC, 120 V AC DI821 8-channel, independent circuit, 220 V DC, 230 V AC DI835 with time tag, 8-channel, separate circuit, 125 V DC DI828 16 channel, separate return, 110 V AC, 120 V AC/DC DI830 with time tag. 16 channels, 2 groups of 8 channels, 24 V DC, current absorber. Resolution:<0.5 ms. DI831 with time stamp. 16 channels, 2 groups of 8 channels, 48 V DC, current absorber. Resolution:<0.5 ms. DI885 is provided with time mark and wire fault detection. 8-channel, common circuit, 24-48 V DC, current absorber. Resolution: 1 ms. Pulse input module DP820 2-channel, independent loop, 0.25 Hz - 1.5 MHz, signal voltage: 5/12 V DC, DP840 8-channel, extended diagnosis, wire fault detection, current limiting sensor power supply, 0.5-20 kHz, 12/24 V DC or NAMUR, common loop. Digital output module DO810 16 channels, 2 groups of 8 channels, 24V, maximum 0.5 A DC, transistor, current source, short circuit protection. DO814 16 channels, 2 groups of 8 channels, 24 V DC, maximum 0.5 A, transistor, current absorber, short circuit protection. DO815 8-channel, 2 groups of 4-channel, 24 V DC, maximum 2 A, transistor, current source, short circuit protection, wire fault detection. DO818 32 channels, 2 groups of 16 channels, 24 V, maximum 0.5 A DC, transistor, current source, short circuit protection. DO820 8-channel, independent loop, 5-250 V, maximum 3 A AC/DC, relay (normally open). DO821 8-channel, independent loop, 5-250 V, maximum 3 A AC/DC, relay (N.c.). DO828 16 channel, independent loop, 5-250 V AC/5-125 V DC, maximum 2 a AC/DC, relay (normally open). Analog input module AI810 8-channel, single ended, 0 (4) - 20 mA, 0 (2) - 10 V, 12 bit. AI815 8-channel with HART. 0 (4).. 20 mA, 0 (1).. 5 V, 12 bit, single ended, current limiting transmitter power supply. AI820 differential input, 4 channels, 0 (1) - 5 V, ± 0 (2) - 10 V,? 0 (4) - 20 mA, 14 bit+symbol. AI835A TC input, 8-channel, (7+reference contact), independent loop.
TC Type B
