十六进制转储打印此功能允许您检查打印机与计算机或终端设备之间的连接是否正常工作。方法是在打开打印机的同时按住FEED按钮，ERROR LED闪烁两次并发出两声蜂鸣声，然后松开按钮。关闭打印机并重新启动以退出此打印模式。3.4恢复出厂默认设置该功能用于清除打印机中存储的设置，并恢复相关参数的出厂默认设置。方法是在打开打印机的同时按住FEED按钮，ERROR LED闪烁五次并发出五声蜂鸣声，然后松开按钮，此时功能生效并关闭打印机。3.5在线智能参数设置TP830支持参数设置功能，可在安装了驱动程序的PC中进行设置。具体设置步骤如下：1.确保计算机和打印机已通过USB电缆连接，并且计算机和打印机均已打开，打印机也应处于正常工作状态。2.在WIN 2000/WIN XP/VISTA/WIN 7操作系统下，单击“开始”→ “设置”→ “打印机”，然后打开“打印机”窗口。在Windows 8操作系统下，首先单击主面板中的“桌面”，然后在进入“桌面”窗口后双击“控制面板”，单击“硬件和声音”找到“设备和打印机”，最后打开“设备和打印”窗口。3.在“打印机”窗口中右键单击“TP830”，然后选择“属性”。4.单击“属性”页面中的“打印机设置”，打开“打印机设置“窗口。TP830用户手册-34-5。
参数设置
窗口中，菜单设置左侧的每个项目都是参数图标。右上方的项目是参数，右下方的项目是当前设置。当您打开参数设置窗口时，计算机将自动加载打印机的当前设置。如果打印机脱机或打印机端口设置不正确，当前设置将为空。然后您需要将打印机设置为联机模式或正确设置打印机端口。TP830用户手册-35-6。要设置参数，首先单击参数图标，然后打开参数设置窗口。窗口中有参数项、描述和控制按钮。选择相应参数，点击“设置”；打印机将在收到命令时更改设置。单击“取消”返回上部窗口，单击“默认”可显示此菜单项的默认设置。7.如果要设置多个参数，请参考上一点，逐个设置参数。8.设置完成后，单击“设置”退出“属性”窗口。9.重新启动打印机，新设置生效。TP830用户手册-36-第4章安装卷筒纸打印机可以方便地使用宽度为79.5±0.5mm、69.5±0.5mmm和57.5±0.5 mm的纸张。本章将详细解释如何处理该论文。4.1热敏纸安装步骤1.按盖打开按钮打开前盖。如果要使用57.5/69.5毫米的纸张进行打印，必须首先安装卷纸导板。
terminal equipment
Hexadecimal dump printThis function allows you to check whether the connection between the printer and the computer or terminal device is working properly. The method is to press and hold the FEED button while turning on the printer, the ERROR LED flashes twice and emits two beeps, and then release the button. Close the printer and restart to exit this print mode. 3.4 Restore factory default settings This function is used to clear the settings stored in the printer and restore the factory default settings of related parameters. The method is to press and hold the FEED button while turning on the printer, the ERROR LED flashes five times and emits five beeps, and then release the button. At this time, the function takes effect and the printer is turned off. 3.5 Online intelligent parameter setting TP830 supports parameter setting function, which can be set in the PC with driver installed. The specific setting steps are as follows: 1. Make sure that the computer and printer are connected through USB cable, and that the computer and printer are turned on, and the printer should also be in normal working state. 2. Under WIN 2000/WIN XP/VISTA/WIN 7 operating system, click Start → Settings → Printer, and then open the Printer window. Under Windows 8 operating system, first click Desktop in the main panel, then double-click Control Panel after entering the Desktop window, click Hardware and Sound to find Devices and Printers, and finally open the Devices and Printers window. 3. Right click TP830 in the Printer window and select Properties. 4. Click "Printer Settings" on the "Properties" page to open the "Printer Settings" window. TP830 User's Manual - 34-5.
Parameter setting
In the window, each item on the left side of the menu setting is a parameter icon. The items on the upper right are parameters, and the items on the lower right are current settings. When you open the parameter setting window, the computer will automatically load the current settings of the printer. If the printer is offline or the printer port is set incorrectly, the current setting will be empty. Then you need to set the printer to online mode or set the printer port correctly. TP830 User Manual-35-6. To set parameters, first click the parameter icon, and then open the parameter setting window. There are parameter items, descriptions and control buttons in the window. Select the corresponding parameters and click "Set"; The printer will change the settings when it receives the command. Click Cancel to return to the upper window, and click Default to display the default settings for this menu item. 7. If you want to set multiple parameters, please refer to the previous point and set the parameters one by one. 8. After setting, click "Setting" to exit the "Properties" window. 9. Restart the printer, and the new settings will take effect. TP830 User's Manual - 36 - Chapter 4 Installing the Web Printer makes it easy to use 79.5 ± 0.5mm, 69.5 ± 0.5mm and 57.5 ± 0.5mm wide paper. This chapter will explain in detail how to deal with this paper. 4.1 Thermal paper installation steps 1. Press the cover open button to open the front cover. If you want to print on 57.5/69.5 mm paper, you must first install the roll guide.
