3BSE008522R1工控卡件
安装蓝牙接口驱动程序
1.选择合适的蓝牙适配器，操作系统为Windows XP或更高版本，该版本带有蓝牙适配器驱动程序。2.打开打印机，在Windows XP系统中搜索蓝牙设备，然后单击“添加”。注意：选择以根据所选型号安装此驱动程序。TP830用户手册-9-3。勾选“我的设备已设置并准备就绪”选项。单击“下一步”继续。TP830用户手册-10-4.选择“TP830”，然后单击“下一步”。5.勾选“让我选择自己的密码”选项，如图所示输入“1234”，然后单击“下一步”。6.记录传出COM端口并单击“完成”，然后重新启动计算机。TP830 TP830用户手册-11-7。将打印机驱动程序打印端口设置为输出端口，安装完成。2.7以太网设置请使用Jolimark网络设置软件NetFinder设置JolimarkEthernet接口网络打印机的IP地址。NetFinder软件（NetFinder.exe）可在CD中找到或从www.jolimark下载。com 2.7.1连接打印机电源，连接已连接到LAN的以太网接口电缆，并查看以太网LED的信息，以确保打印机已进入正常连接。2.7.2设置IP地址1.运行NetFinder软件双击NetFinder。exe，它将打印机连接到同一局域网中。软件图如下所示：橙色LED绿色LED说明On Blink Online Off Off Offline注意：每个蓝牙设备都有自己的地址。更换蓝牙设备时请重新安装。注意：网络打印功能需要Windows2000及以上版本的操作系统，不支持Windows 98/ME及以下版本的操作。TP830用户手册-12-2.搜索打印机单击主界面中的“搜索”按钮，出现的对话框将自动开始搜索并显示状态，如果找到，则在主界面中列出打印机。时间在进度条中倒数计时（总共10秒），搜索将在时间结束后立即结束。
如果您需要继续搜索
请再次按“搜索”按钮。如果打印机连接正确，可以在搜索期间找到IP地址。如果在同一网络中网络连接正确时仍无法找到打印机。请检查电脑上的网络防火墙是否打开。如果有防火墙，请暂时关闭；完成搜索并完全设置打印机后，再次打开它。按钮说明：退出-退出软件搜索-搜索同一局域网中的打印机分配IP-修改指定打印机的IP地址和其他设置。TP830用户手册-13-3.设置打印机的IP地址打印机的信息列在主界面中，左侧是型号和说明，右侧是IP地址和MAC地址。更重要的是，分配模式（动态/静态）被记录在IP地址后面。1） IP地址设置的相关说明为了第一次方便地搜索和设置打印机的IP地址，出厂默认设置为动态分配IP地址的DHCP模式。如果连接的LAN中没有DHCP服务器，并且打印机也设置为DHCP模式，则它将自动使用内部预设地址（IP:10.0.0.1，子网掩码：255.255.255.0）。建议在实际使用中将打印机的IP设置为静态，这可以在打印机打开时缩短初始化以太网接口的时间，并防止IP冲突（打印机中使用的动态地址可能与另一个地址冲突）。IP地址和子网掩码的网段部分必须与连接打印机的PC相同。例如，工作PC的地址为192.168.0.1/255.255.255.0（IP/子网掩码），那么哪台打印机应设置为192.16.8.0.x/255.252.555.0（x=2~254），并应避免使用IP。NetFinder不限于搜索同一网络中的打印机，而是搜索不同的网段部分（不能跨网关）。IP地址的相关词汇可以参考相应的信息。2） 设置打印机的IP地址选择要修改的打印机信息（显示黑色框），单击“分配IP”按钮。在出现的对话框中设置IP。
Installing Bluetooth interface drivers
1. Select the appropriate Bluetooth adapter. The operating system is Windows XP or higher, which is equipped with Bluetooth adapter driver. 2. Open the printer, search for Bluetooth devices in Windows XP, and then click Add. Note: Select to install this driver based on the selected model. TP830 User Manual-9-3. Check the "My device is set and ready" option. Click Next to continue. TP830 User Manual - 10-4. Select "TP830" and click "Next". 5. Check the "Let me choose my own password" option, enter "1234" as shown in the figure, and then click "Next". 6. Record the outgoing COM port and click Finish, then restart the computer. TP830 TP830 User Manual - 11-7. Set the printer driver print port as the output port, and the installation is complete. 2.7 For Ethernet settings, please use the Jolimark network setting software NetFinder to set the IP address of the Jolimark Ethernet interface network printer. NetFinder software (NetFinder. exe) can be found on the CD or at www Jolimark download. Com 2.7.1 Connect the printer power supply, connect the Ethernet interface cable connected to the LAN, and check the Ethernet LED information to ensure that the printer has entered the normal connection. 2.7.2 Set IP address 1. Run NetFinder software and double-click NetFinder. Exe, which connects the printer to the same LAN. The software diagram is shown as follows: Orange LED Green LED means On Blink Online Off Offline Note: Each Bluetooth device has its own address. Please reinstall the Bluetooth device when replacing it. Note: The network printing function requires the operating system of Windows 2000 and above, and does not support the operation of Windows 98/ME and below. TP830 User Manual-12-2. Search for a printer Click the Search button in the main interface, and the dialog box will automatically start searching and display the status. If it is found, the printer will be listed in the main interface. The time is counted down in the progress bar (10 seconds in total), and the search will end immediately after the time.
If you need to continue searching
Press the Search button again. If the printer is connected correctly, you can find the IP address during the search. If the network connection is correct in the same network, the printer cannot be found. Check that the network firewall on your computer is turned on. If there is a firewall, please close it temporarily; Once the search is complete and the printer is completely set up, open it again. Button description: Exit - Exit software search - Search for printers in the same LAN to assign IP - Modify the IP address and other settings of the specified printer. TP830 User Manual-13-3. Set the IP address of the printer The printer information is listed in the main interface. The model and description are on the left, and the IP address and MAC address are on the right. More importantly, the allocation mode (dynamic/static) is recorded after the IP address. 1) Description of IP address setting In order to search and set the printer's IP address for the first time, the factory default setting is DHCP mode of dynamically assigning IP addresses. If there is no DHCP server in the connected LAN and the printer is also set to DHCP mode, it will automatically use the internal preset address (IP: 10.0.0.1, subnet mask: 255.255.255.0). It is recommended to set the printer's IP to static in actual use, which can shorten the time for initializing the Ethernet interface when the printer is turned on, and prevent IP conflicts (the dynamic address used in the printer may conflict with another address). The segment portion of the IP address and subnet mask must be the same as the PC connecting the printer. For example, if the address of the working PC is 192.168.0.1/255.255.255.0 (IP/subnet mask), which printer should be set to 192.16.8.0. x/255.252.555.0 (x=2~254), and IP should be avoided. NetFinder is not limited to searching printers in the same network, but searching different network segments (not across gateways). Please refer to the corresponding information for IP address related terms. 2) Set the IP address of the printer Select the printer information to be modified (a black box is displayed), and click Assign IP. Set the IP in the dialog box that appears.
