57160001-ACX控制模块
单击连接选项卡并配置RPI
最低支持RPI为3ms。4.单击OK(确定)。从属设备现在已配置。用户参考指南 48 Slave Functionality©2014 Molex股份有限公司工业产品业务部,集成产品部文件版本:1.0,文件#:715-0109,模板版本:1.1,模板ţ:QMS-06-045本文件或其中包含的任何信息的使用、复制或披露受本文件第二页的限制。用户参考指南技术规范49©2014 Molex股份有限公司工业产品业务部,综合产品部文件版本:1.0,文件#:715-0109,模板版本:1.1,模板35;:QMS-06-045使用、复制或披露本文件或其中包含的任何信息受本文件第二页的限制。A技术规范附录章节:•技术规范用户参考指南 50技术规范©2014 Molex股份有限公司工业产品事业部,综合产品部文件版本:1.0,文件#:715-0109,模板版本:1.1,模板35;:QMS-06-045使用,复制或披露本文件或其中包含的任何信息均受本文件第ii页的限制。A、 1技术规格表23:、SST-PB3-CLX-RLL-CC、SST-PB3S-CLXT-RLL模块的技术规格零件号SST-PB3CLX-RLL,用于PROFIBUS网络的SST-PB3S-CLXT-RLL功能CLX-5000从机说明•Freescale MCF5272处理器•8 MB MCF5272-本地RAM•512 KB板载共享存储器•512 MB扇区闪存,用于存储程序和配置数据•ASPC2 LAN控制器CLX接口SST-PB3-CLX-RLL支持最多122字的输入数据和122字的输出数据。可用状态信息。
支持多达244字节的总数据交换
250字状态环境存储温度-40°C至85°C工作温度:0°C至60°C 0°C到60°C,非冷凝污染等级1-无污染或仅为非导电或非腐蚀性污染背板电流消耗850 mA@5 VDC 1.75mA@24VDC 用户参考指南监管合规51©2014 Molex股份有限公司工业产品业务部,综合产品部文件版本:1.0,文件#:715-0109,模板版本:1.1,模板ţ:QMS-06-045使用、复制或披露本文件或其中包含的任何信息受本文件第二页的限制。B法规遵从性附录章节:•CE Compliance•Rep.of Korea Compliance User Reference Guide 52 Rigulation Compliance©2014 Molex股份有限公司工业产品业务部,综合产品部文件版本:1.0,文件#:715-0109,模板版本:1.1,模板35;:QMS-06-045使用,复制或披露本文件或其中包含的任何信息均受本文件第ii页的限制。B、 1本设备的CE符合性标记和符号表示符合欧洲理事会指令2004/108/EC。警告这是a类产品。在家庭环境中,本产品可能会造成无线电干扰,在这种情况下,您可能需要采取适当的措施。警告:本设备既不适用于也不适用于承受危险电压和危险电流的装置。注意:为了遵守EMC指令的限制和要求,在连接到此设备时,需要使用高质量的接口电缆和连接器。有关电缆类型的选择,请参阅《硬件指南》中的电缆规格。注:该设备的背板电压电源必须作为分离超低电压(SELV)交付。
Click the Connections tab and configure RPI
The minimum RPI supported is 3ms. 4. Click OK. The slave device is now configured. User Reference Guide 48 Slave Functionality © 2014 Molex Co., Ltd. Industrial Products Business Department, Integrated Products Department Document version: 1.0, Document #: 715-0109, Template version: 1.1, Template ţ: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is restricted by the second page of this document. User Reference Guide Technical Specifications 49 © 2014 Molex Co., Ltd. Industrial Products Business Department, Integrated Products Department Document version: 1.0, Document #: 715-0109, Template version: 1.1, Template 35;: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is restricted by the second page of this document. A Technical Specification Appendix Section: • Technical Specification User Reference Guide 50 Technical Specification © 2014 Molex Co., Ltd. Industrial Products Division, Integrated Products Division Document version: 1.0, Document #: 715-0109, Template version: 1.1, Template 35;: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is subject to the restrictions of page ii of this document. A. 1 Technical specification table 23: Technical specifications of SST-PB3-CLX-RLL-CC and SST-PB3S-CLXT-RLL modules Part number SST-PB3CLX-RLL, description of SST-PB3S-CLXT-RLL function CLX-5000 slave for PROFIBUS network • Freescale MCF5272 processor • 8 MB MCF5272 local RAM • 512 KB on-board shared memory • 512 MB sector flash memory, Used to store program and configuration data • The ASPC2 LAN controller CLX interface SST-PB3-CLX-RLL supports up to 122 words of input data and 122 words of output data. Available status information.
Supports up to 244 bytes of total data exchange
250 word status Ambient storage temperature - 40 ° C to 85 ° C Operating temperature: 0 ° C to 60 ° C 0 ° C to 60 ° C Non condensing pollution level 1 - No pollution or only non-conductive or non corrosive pollution Backplane current consumption 850 mA@5 VDC 1.75mA@24VDC User Reference Guide Regulatory Compliance 51 © 2014 Molex Co., Ltd. Industrial Products Business Department, Integrated Products Department Document version: 1.0, Document #: 715-0109, Template version: 1.1, Template ţ: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is restricted by the second page of this document. B Compliance Appendix Chapter: • CE Compliance • Rep. of Korea Compliance User Reference Guide 52 Rigulation Compliance © 2014 Molex Co., Ltd. Industrial Products Business Department, Integrated Products Department Document version: 1.0, Document #: 715-0109, Template version: 1.1, Template 35;: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is subject to the restrictions of page ii of this document. B. 1 The CE conformity mark and symbol of this equipment indicate that it complies with the European Council Directive 2004/108/EC. Warning this is a class a product. In a home environment, this product may cause radio interference, in which case you may need to take appropriate measures. WARNING: This equipment is neither suitable for nor suitable for devices subject to hazardous voltages and currents. Note: In order to comply with the restrictions and requirements of EMC directives, high-quality interface cables and connectors are required when connecting to this equipment. For cable type selection, refer to the cable specifications in the Hardware Guide. Note: The backplane voltage power supply of this equipment must be delivered as a separate ultra-low voltage (SELV).
