3HNA024871-001控制器模块
接线模块
PROFIBUS接线模块包含一个标准DB9连接器，可连接到PROFIBU总线端子。该模块没有内置终端。如果需要终端，可以使用内置可选终端的总线终端。表2:DB9说明引脚#引脚描述DB9线路*使用SST-PB3S-CLX-RLL 1机箱接地2保留3数据+将此引脚连接到引脚8（数据-），带220欧姆电阻器4 TX启用5隔离接地将此引脚与引脚8（数字-）连接，带390欧姆电阻器6隔离+5V将此引脚连到引脚3（数据+），带3900欧姆电阻器7保留8数据-9保留*对于线路A电缆（135-165欧姆阻抗）注意不要将设备连接到+5V线路。它仅用于终止目的。用户参考指南SST-PB3S-CLX-RLL 24安装SST-PB3S-CLX-RLL从机©2014 Molex股份有限公司工业产品业务部，综合产品部文件版本：1.0，文件#：715-0109，模板版本：1.1，模板35；：QMS-06-045使用，复制或披露本文件或其中包含的任何信息均受本文件第ii页的限制。4.2.1选择合适的线型使用此表确定哪种线型最适合您的系统要求。表3：线路类型波特率（比特/秒）线路A距离（最大值）线路B距离（最大）寄存器值9k6、19.2k、45.45k和93.75k 1200 m**1200 m**0、1、11、2 187.5k 1000 m**600 m**3 500k 400 m**200 m**4 1.5M 200 m**NA 6 3、6和12M 100 m**NA 7、8、9 NA=不适用*如果使用两种线路类型的组合，请将显示的长度除以2**这是所有总线段和引入电缆长度的总和。注意PROFIBUS网络的两个物理端应终止。网络上应该只有两个终端。SST-PB3S-CLX-RLL用户参考指南安装SST-PB3S-CLX-RLL Slave 25©2014 Molex股份有限公司工业产品业务部门，综合产品部文件版本：1.0，文件#：715-0109，模板版本：1.1，模板35；：QMS-06-045使用，复制或披露本文件或其中包含的任何信息均受本文件第ii页的限制。4.2.2 PROFIBUS连接器板卡每个通道有一个标准PROFIBUS-DB9母连接器。
引脚编号
ROFIBUS DB9母接头注：推荐的公接头为Brad Harrison PA9D01-42诊断D-Sub接头。建议使用Belden3079A电缆。示例包括：•Brad Harrison 85-001 PVR2导体带屏蔽，UL认证的PROFIBUS电缆•Bosch Comnet DP#913 548柔性PROFIBU电缆•Boch Comnet DP#917 201拖尾PROFIBUS电缆•Bosh Comnet DP#917 202大型PROFIBU斯电缆注：不建议使用阻抗为78欧姆的Allen Bradley蓝色软管。用户参考指南SST-PB3S-CLX-RLL 26安装SST-PB3S-CLX-RLL从机©2014 Molex股份有限公司工业产品业务部，综合产品部文件版本：1.0，文件#：715-0109，模板版本：1.1，模板35；：QMS-06-045使用，复制或披露本文件或其中包含的任何信息均受本文件第ii页的限制。4.3 PROFIBUS LED和显示器状态下表显示了LED和显示器如何协同工作，以提供从机操作的详细信息。表4:COMM LED行为LED状态描述呈红色，当COMM和SYS LED同时呈红色时，发生了可恢复或不可恢复的致命错误。关闭Profibus从站处于离线或在线状态。闪烁红色当将Profibus从设备联机时可能会发生这种情况，但在联机后，COMM LED应熄灭并保持熄灭。表5:OK LED Behavior LED State Description（正常LED行为LED状态描述）固态绿色初始化完成，模块就绪固态红色硬件错误表6:SYS LED Behaveor LED States Description固态绿色DP Master（DP主控器）正在运行模式下扫描Profibus从机。实心红色Profibus从设备在线，但未被DP主设备扫描琥珀色Profibus从属设备在线，并由DP主设备在清除模式下扫描。关闭Profibus从站处于脱机状态。注意：从机运行时，COMM LED始终熄灭。SST-PB3S-CLX-RLL用户参考指南安装SST-PB3S-CLX-RLL Slave 27©2014 Molex股份有限公司工业产品业务部门，综合产品部文件版本：1.0，文件#：715-0109，模板版本：1.1，模板35；：QMS-06-045使用，复制或披露本文件或其中包含的任何信息均受本文件第ii页的限制。4.4 LED和显示器组合当连接打开时，COPN显示在LCD显示器上。从左到右，LED为COMM、SYS和OK。当从设备首次联机时，COM LED可能变为红色，但当板卡联机时，它将保持熄灭。表1
wiring module
The PROFIBUS wiring module contains a standard DB9 connector that can be connected to the PROFIBUS bus terminals. The module has no built-in terminal. If a terminal is required, the bus terminal with built-in optional terminal can be used. Table 2: DB9 description Pin # Pin description DB9 line * Use SST-PB3S-CLX-RLL 1 chassis grounding 2 to retain 3 data+connect this pin to pin 8 (data -), with 220 ohm resistor 4 TX enable 5 isolated grounding connect this pin to pin 8 (digital -), with 390 ohm resistor 6 isolated+5V connect this pin to pin 3 (data+), With 3900 ohm resistor 7, reserve 8 data - 9 reserve * For line A cable (135-165 ohm impedance), be careful not to connect the device to the+5V line. It is for termination purposes only. User Reference Guide SST-PB3S-CLX-RLL 24 Installing SST-PB3S-CLX-RLL Slave © 2014 Molex Co., Ltd. Industrial Products Business Department, Integrated Products Department Document version: 1.0, Document #: 715-0109, Template version: 1.1, Template 35;: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is subject to the restrictions of page ii of this document. 4.2.1 Select a suitable line type Use this table to determine which line type best suits your system requirements. Table 3: Line Type Baud Rate (bits/s) Line A Distance (maximum) Line B Distance (maximum) register values 9k6, 19.2k, 45.45k and 93.75k 1200 m * * 1200 m * * 0, 1, 11, 2 187.5k 1000 m * * 600 m * * 3 500k 400 m * * 200 m * * 4 1.5M 200 m * * NA 6, 6 and 12M 100 m * * NA 7, 8, 9 NA=N/A * If a combination of the two line types is used, Please divide the displayed length by 2 * * This is the sum of all bus sections and incoming cable lengths. Note that the two physical ends of the PROFIBUS network should be terminated. There should be only two terminals on the network. SST-PB3S-CLX-RLL User Reference Guide Installing SST-PB3S-CLX-RLL Slave 25 © 2014 Molex Co., Ltd. Industrial Products Business Department, Integrated Products Department Document Version: 1.0, Document #: 715-0109, Template Version: 1.1, Template 35;: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is subject to the restrictions of page ii of this document. 4.2.2 Each channel of the PROFIBUS connector board has a standard PROFIBUS-DB9 female connector.
Pin number
ROFIBUS DB9 female connector Note: The recommended male connector is Brad Harrison PA9D01-42 diagnostic D-Sub connector. Belden 3079A cable is recommended. Examples include: • Brad Harrison 85-001 PVR2 conductor with shield, UL certified PROFIBUS cable • Bosch Comnet DP # 913 548 flexible PROFIBUS cable • Boch Comnet DP # 917 201 trailing PROFIBUS cable • Bosh Comnet DP # 917 202 large PROFIBUS cable Note: Allen Bradley blue hose with an impedance of 78 ohms is not recommended. User Reference Guide SST-PB3S-CLX-RLL 26 Installing the SST-PB3S-CLX-RLL Slave © 2014 Molex Co., Ltd. Industrial Products Business Department, Integrated Products Department Document version: 1.0, Document #: 715-0109, Template version: 1.1, Template 35;: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is subject to the restrictions of page ii of this document. 4.3 The following table of PROFIBUS LED and display status shows how LED and display work together to provide detailed information of slave operation. Table 4: COMM LED behavior LED status description is red. When COMM and SYS LEDs are red at the same time, a recoverable or unrecoverable fatal error occurs. Close the Profibus slave station and it is offline or online. Flashing red This may happen when the Profibus slave is online, but the COMM LED should go off and remain off after it is online. Table 5: OK LED Behavior LED State Description Solid state green initialization is completed and the module is ready Solid state red hardware error Table 6: SYS LED Behavior LED States Description Solid state green DP Master scans Profibus slave in the running mode. The solid red Profibus slave is online, but not scanned by the DP master. The amber Profibus slave is online and scanned by the DP master in clear mode. Close the Profibus slave station and it is offline. Note: The COMM LED is always off when the slave is running. SST-PB3S-CLX-RLL User Reference Guide Installing SST-PB3S-CLX-RLL Slave 27 © 2014 Molex Co., Ltd. Industrial Products Business Department, Integrated Products Department Document Version: 1.0, Document #: 715-0109, Template Version: 1.1, Template 35;: QMS-06-045 The use, reproduction or disclosure of this document or any information contained therein is subject to the restrictions of page ii of this document. 4.4 LED and display combination When the connection is turned on, COPN is displayed on the LCD display. From left to right, the LEDs are COMM, SYS, and OK. The COM LED may turn red when the slave is first online, but it will remain off when the board is online. Table 1
