3HAC025562-001工控备件机器人模块
一般信息产品ID
ABB类型名称：-目录描述：OPTIC-TO-ELECT TERM UNIT长描述：OPDIC-TO-EELCT TERM UNIT附加信息ABB产品系列：Harmony rack HW ABB型号名称：-核心信用证：0.00原产国：意大利（IT）印度（IN）海关税号：8517700000毛重：5.2 kg发票描述：INFI净光电TU定制：无最大订单数量：0 EA中等描述：OPTIC-TO-ELECT终端单元最小订单数量：1 EA处理器数量：0订单倍数：1 EA包装级别1总重量：5.2 kg包装级别1单元：1 EA零件类型：新产品名称：-产品净高：8.9英寸产品净长：6.3英寸产品净重：0千克产品净宽：8.3英寸产品类型：仅硬件报价：无销售计量单位：每个简短描述：光纤通信系统OPTIC-T库存（仓库）：中央库存美国ITABB004EXPU USABB012EXPU CNABB001EXPU技术信息：INFI Net Optical to Electric TU产品控制系统Symphony Harmony INFI 90 I/O ASI Analog Slave Inputs IMASI23预制电缆-TU846系统800xA硬件选择器数据表TU846是模块终端单元（MTU），用于现场通信接口CI840/CI840A和冗余I/O的冗余配置。MTU是一个无源单元，具有电源连接、两个电气模块总线、两个CI840/CI840A和两个用于站地址（0至99）设置的旋转开关。A模块总线光端口TB842可以通过TB846连接到TU846。四个机械键（每个位置两个）用于为正确类型的模块配置MTU。每个键有六个位置，总共有36种不同的配置。用于双CI840/CI840A、冗余I/O的模块终端装置。TU846用于冗余I/O模块，TU847用于单个I/O模块。从TU846到ModuleBus终端的最大ModuleBus长度为2.5米。TU846/TU847需要左侧空间才能拆卸。通电后无法更换。功能和优点•电源连接。•两个PROFIBUS连接。•两个维修工具连接。•用于站地址设置的两个旋转开关。•两个模块总线的连接。•ModuleBus光纤端口连接器。
DIN导轨锁紧装置
•机械键控可防止插入错误的模块类型。•用于锁定和接地的DIN导轨锁紧装置。•DIN导轨安装。一般信息协议PROFIBUS DP-V1产品编号3BSE022460R1主设备或从设备不适用线路冗余是模块冗余是热插拔否类型冗余CI840/CI840A，冗余I/O电源输入24V直流（19.2-30 V）安装垂直或水平数据表TU846 | 2019-05-27 |版权所有©2019 ABB 1详细数据连接器PROFIBUS:DSUB9连接器服务端口：RJ45连接器模块总线电流分布最大5 V 1.5 A最大24v1.5 A机械键36种不同组合可接受的导线尺寸0.25-2.5mm2，24-14AWG推荐扭矩：0.5-0.6 Nm剥离长度：6-7.5 mm，0.24-0.30 in额定绝缘电压50 V辩证试验电压500 V a.c环境和认证温度，工作温度55°c（131°F）水平安装。40°C（104°F）垂直安装温度，储存-25°C（-13°F）至+70°C（158°F，根据IEC60536，设备等级为1级；（接地保护）防护等级IP20，符合IEC 529，（IEC 144）CE标志是电气安全cULus危险位置cULus 1级危险位置2区，ATEX 2区RoHS符合指令/2011/65/EU（EN 50581:2012）WEEE符合指令/2012/19/EU尺寸高度186 mm（7.32”），包括插销宽度124 mm（4.88”）深度47 mm（1.85”）重量0.5 kg（1.1磅）2数据表TU846 | 2019-05-27 |版权所有©2019 ABB-www.ABB。网址：www.abb。com/controlsystems 800xA是ABB的注册商标或未决商标。其他商标的所有权利归其各自所有者所有。我们保留对产品进行技术更改或修改本文件内容的权利，恕不另行通知。关于采购订单，应以商定的细节为准。ABB不对本文件中的任何错误或不完整信息承担任何责任。我们保留对本文档及其包含的项目和图像的所有权利。未经ABB事先书面许可，禁止复制、向第三方披露或使用本文件的内容（包括部分内容）。版权©2019 ABB保留所有权利数据表| 2019-05-27 |版权©2018 ABB 3
General Information Product ID
ABB Type Name: - Directory Description: OPTIM-TO-ELECT TERM UNIT Long Description: OPTIM-TO-ELECT TERM UNIT Additional Information ABB Product Series: Harmony rack HW ABB Model Name: - Core Letter of Credit: 0.00 Country of Origin: Italy (IT) India (IN) Customs Duty No.: 8517700000 Gross Weight: 5.2 kg Invoice Description: INFI Net Photoelectric TU Customization: No Maximum Order Quantity: 0 EA Medium Description: OPTIM-TO-ELECT Terminal Unit Minimum Order Quantity: 1 EA Processor Quantity: 0 Order Multiple: 1 EA Packaging Level 1 Total Weight: 5.2 kg Packaging Level 1 Unit: 1 EA Part Type: New Product Name: - Product Net Height: 8.9 inch Product Net Length: 6.3 inch Product Net Weight: 0 kg Product Net Width: 8.3 inch Production Product type: hardware quotation only: no sales unit of measurement: each short description: optical fiber communication system OPTIC-T inventory (warehouse): central inventory USA ITABB004EXPU USABB012EXPU CNABB001EXPU Technical information: INFI Net Optical to Electric TU Product control system Symphony Harmony INFI 90 I/O ASI Analog Slave Inputs IMASI23 Prefabricated cable TU846 System 800xA Hardware Selector Data Sheet TU846 is the module terminal unit (MTU), It is used for redundant configuration of field communication interface CI840/CI840A and redundant I/O. MTU is a passive unit with power connection, two electrical module buses, two CI840/CI840A and two rotary switches for setting station addresses (0 to 99). A module bus optical port TB842 can be connected to TU846 through TB846. Four mechanical keys (two in each position) are used to configure the MTU for the correct type of module. Each key has six positions and a total of 36 different configurations. Module terminal device for dual CI840/CI840A, redundant I/O. TU846 is used for redundant I/O modules and TU847 is used for single I/O modules. The maximum ModuleBus length from TU846 to ModuleBus terminal is 2.5 meters. The TU846/TU847 requires space on the left side for disassembly. It cannot be replaced after power on. Features and Benefits • Power Connections. • Two PROFIBUS connections. • Two service tools are connected. • Two rotary switches for station address setting. • Connection of two module buses. • ModuleBus fiber port connector.
DIN rail locking device
