3BHB017688R0001机器人备件
交流伺服电机
控制箱/伺服电机控制箱/电机M51（交流伺服电机）SC-510（控制箱）大功率电机M51精密控制箱SC-510 控制箱SC-510允许设置自动反向缝纫和多层缝纫，以及仅从安装在控制箱正面的控制面板建立缝纫程序，而不使用操作面板。 通过采用不易受电压变化影响的开关电源系统和加强保护电路，可靠性进一步提高。 CP-160C或IP-100E操作面板可用作选件。卓越的可操作性 一次可以运行四个不同的程序。一个程序可以输入20个操作步骤。 通过建立许多不同的程序，控制盒可以用于附加功能，例如添加堆垛机功能。控制箱具有简化的编程功能。控制箱具有响应外部信号的功能。 控制箱配有八个*输入和输出端口，可供客户根据需要使用，一个IPOP板（用于IP-100E）连接端口和一个CP-160C连接端口。*输入/输出端口的数量受客户使用的机头限制。 通过安装支持各种控制和规格的IPOP板（可选），可提供额外的八个输入端口和八个输出端口。更高可靠性操作面板（可选）控制箱正面的面板。 采用了输出功率为750W的高转矩交流伺服电机。 该机具有优异的高速缝纫性能和强大的织物穿透力。因此，该机器的适用范围更广，从普通织物到超重型材料。 要订购，请联系您最近的JUKI经销商。规格适用型号下单时请注意，型号名称应写如下： PSC箱 SC电机 操作面板（可选）交流伺服电机750W单相100~120V，200~240V三相200~240V取决于操作条件和安装的机头。
8个用于可选输入+1个用于回缩输入
13（8个可选输出+5个用于磁体输出）4 20步/1程序控制箱或操作面板（可选）型号名称电机类型电机输出功率要求功耗输入端口数量输出端口数量程序步数程序输入操作面板IP-100E*CP-160C代码IP-100E CP-160C-SC510□S控制箱标准代码S*JUS：北美和中南美洲。用于JUS（LA）的PSC箱*用于JUS*，用于欧盟（CE）的一般出口，用于中国单相三相单相单相100～120V 200～240V 200～240 V 200～24 V 200～40 V代码S D K N U M51营销和销售总部。✽ 规格和外观如有更改，恕不另行通知。✽ 在机器投入使用前，请阅读使用手册，以确保安全。✽ 这个目录是用回收纸印刷的。2005年2月在日本印刷（TN）8-2-1，KOKURYO-CHO，CHOFU-SHI，TOKYO 182-8655，日本电话：（81）3-3480-23572358传真：（81）3-3430-49094914http://www.juki.com 通过安装CP-160C，进一步增加了可用功能，提高了可操作性。 花样缝纫可以通过针数控制功能进行。 有四种不同的花样缝纫：自动反向缝纫、恒定尺寸缝纫，矩形缝纫和多层缝纫。自动反向缝合（单针或双针）可设置的最大针数为19针。 CP-160C配有底线计数器。CP-160C型 IP-100E具有比CP-160C提供的功能更多的功能，并提高了可操作性。 操作面板配备了一个用户友好的大型LCD。象形图和设定值显示在同一屏幕上，这保证了面板的可操作性。 操作面板具有多种通信和维护控制功能，能够在SmartMedia或个人计算机上存储数据。 无需更换PWB/ROM即可更新操作面板的功能。IP-100E当您订购操作面板（选件）DLN-6390-7 MO-6000系列MF-7700系列MF-7800系列MH-480系列MH-1410 LU-1500N系列LU-2200N系列DSC-240系列DSU-140系列PLC-1600系列DU-141H-7、DNU-1541-7 LS-1342-7、LZH-1290-7单针、，锁缝机超长/安全缝纫机覆缝机重材料双链缝机*IP-100E配备了IPOP板。
AC servo motor
The control box/servo motor control box/motor M51 (AC servo motor) SC-510 (control box) high-power motor M51 precision control box SC-510 control box SC-510 allows the setting of automatic reverse sewing and multi-layer sewing, and the establishment of sewing procedures only from the control panel installed on the front of the control box, without using the operation panel. The reliability is further improved by adopting a switching power supply system that is not easily affected by voltage changes and strengthening the protection circuit. CP-160C or IP-100E operation panel can be used as an option. Excellent operability can run four different programs at a time. One program can input 20 operation steps. By establishing many different programs, the control box can be used for additional functions, such as adding stacker functions. The control box has simplified programming functions. The control box has the function of responding to external signals. The control box is equipped with eight * input and output ports, which can be used by customers as required, one IPOP board (for IP-100E) connection port and one CP-160C connection port* The number of I/O ports is limited by the head used by the customer. By installing IPOP boards (optional) supporting various controls and specifications, additional eight input ports and eight output ports can be provided. Higher reliability operation panel (optional) The panel on the front of the control box. High torque AC servo motor with output power of 750W is adopted. The machine has excellent high speed sewing performance and strong fabric penetration. Therefore, the machine can be used in a wider range, from ordinary fabrics to super heavy materials. To order, please contact your nearest JUKI dealer. When placing an order, please note that the model name should be written as follows: PSC box SC motor operation panel (optional) AC servo motor 750W single-phase 100~120V, 200~240V three-phase 200~240V depending on the operating conditions and the installed head.
8 for optional inputs+1 for retracted inputs
13 (8 optional outputs+5 for magnet output) 4 20 step/1 program control box or operation panel (optional) model name motor type motor output power requirement power consumption input port number output port number program step program input operation panel IP-100E * CP-160C code IP-100E CP-160C-SC510 □ S control box standard code S * JUS: North America and Central and South America. PSC box for JUS (LA) * for JUS *, for general export of European Union (CE), for China's single-phase, three-phase, single-phase, single-phase, 100 ～ 120V, 200 ～ 240V, 200 ～ 240V, 200 ～ 24V, 200 ～ 40V code S D K N U M51 marketing and sales headquarters. ✽ Specifications and appearance are subject to change without notice. ✽ Before putting the machine into use, please read the user manual to ensure safety. ✽ This catalog is printed with recycled paper. Printed in Japan in February 2005 (TN) 8-2-1, KOKURYO-CHO, CHOFU-SHI, TOKYO 182-8655, Japan Tel: (81) 3-3480-23572358 Fax: (81) 3-3430-49094914 http://www.juki.com By installing CP-160C, the available functions are further increased and the operability is improved. Pattern sewing can be performed through the stitch number control function. There are four different pattern sewing: automatic reverse sewing, constant size sewing, rectangle sewing and multi-layer sewing. The maximum number of stitches that can be set for automatic reverse stitching (single needle or double needle) is 19. CP-160C is equipped with bobbin thread counter. CP-160C type IP-100E has more functions than CP-160C and improves operability. The operation panel is equipped with a large user-friendly LCD. The pictogram and the set value are displayed on the same screen, which ensures the operability of the panel. The operation panel has a variety of communication and maintenance control functions, and can store data on SmartMedia or personal computers. The function of the operation panel can be updated without replacing the PWB/ROM. IP-100E When you order the operation panel (option) DLN-6390-7 MO-6000 series MF-7700 series MF-7800 series MH-480 series MH-1410 LU-1500N series LU-2200N series DSC-240 series DSU-140 series PLC-1600 series DU-141H-7, DNU-1541-7 LS-1342-7, LZH-1290-7 single needle, the overlock sewing machine/safety sewing machine Heavy material double chain sewing machine * IP-100E is equipped with IPOP board.
