安装规范
符合6U板的VME物理规范。可用于系统控制或作为外围板。它们可以直接插入任何标准机箱，接受任何类型的板。以下步骤描述了GE Fanuc嵌入式系统推荐的的安装和通电方法：1.如果要使用PMC模块，请在板安装之前将其连接到（如第29页图1-2所示）。有关配置和设置，请参阅PMC模块的产品手册。注：散热器输出侧测得的气流要求大于450LFM。2.将插入VME机箱系统控制器或外围插槽。在确保电路板在支撑电路板导轨中正确对齐和定向的同时，将电路板平稳向前滑动，紧靠配合连接器。使用顶出器手柄牢固地固定电路板。3.可以从前面板或后I/O VMIACC-0586/ACC-0586RC或VMIACC-0.590/ACC-0590RC后转换模块（RTM）访问所有需要的外围设备。每个连接器在前面板上都有清晰的标签，详细的引脚在附录A中。4.如果系统之前没有配置，请连接键盘和鼠标。5.具有板上驻留的可选CompactFlash磁盘。有关设置详细信息，请参阅第3章。6.如果安装了外部驱动器模块，则必须使用BIOS设置程序来配置驱动器类型。请参阅附录B以正确配置系统。7.如果存在驱动器模块，请按照制造商的说明安装操作系统。BIOS设置有一个板载BIOS设置程序，可控制许多配置选项。这些选项保存在一个特殊的非易失性、电池支持的存储芯片中，统称为电路板的“CMOS配置”。CMOS配置从施加电源的那一刻起就控制与硬件行为有关的许多细节。 BIOS设置程序的详细信息见附录B
前/后面板连接器
为PMC扩展站点提供前面板访问、一个可选千兆以太网端口、一个10/100 RJ45连接器、一个串行端口、SVGA、键盘/鼠标、手动复位开关和状态LED。前面板的图纸如图1-5所示。前面板连接器和指示灯的标签如下：•10/100 10/100 Mbit以太网连接器•G1 10/100/1000 Mbit Ethernet连接器1（或LED）端口1•G2 10/100/1000 Mbit LED端口2•M/K鼠标/键盘连接器•COM1串行端口•RST手动复位开关•S状态LED•SVGA模拟视频连接器提供后部I/O支持用于：数字视频、串行ATA、COM2、3和4、IDE驱动器和两个USB端口。通过使用RTM（如VMIACC-0586/ACC-0586RC和VMIACC-0.590/ACC-0590RC）访问这些信号，RTM终止于工业标准连接器。的前面板连接器（包括连接器引脚和方向）在附录A中定义。后面板连接在相应的RTM安装指南中定义。有关GE Fanuc嵌入式系统提供的兼容RTM，请联系销售人员。
Installation specifications
Comply with VME physical specifications of 6U board. It can be used for system control or as a peripheral board. They can be directly plugged into any standard chassis and accept any type of board. The following steps describe the installation and power on methods recommended by GE Fanuc embedded system: 1. If you want to use the PMC module, please connect it to the before board installation (as shown in Figure 1-2 on page 29). For configuration and settings, refer to the product manual for the PMC module. Note: The air flow measured at the radiator output side is more than 450LFM. 2. Insert into the VME chassis system controller or peripheral slot. While ensuring that the circuit board is correctly aligned and oriented in the guide rail of the supporting circuit board, slide the circuit board forward smoothly and firmly against the mating connector. Use the ejector handle to firmly secure the circuit board. 3. All required peripherals can be accessed from the front panel or rear I/O VMIACC-0586/ACC-0586RC or VMIACC-0.590/ACC-0590RC rear conversion module (RTM). Each connector has a clear label on the front panel, and the detailed pins are in Appendix A. 4. If the system has not been configured before, please connect the keyboard and mouse. 5. It has an optional CompactFlash disk that resides on the board. See Chapter 3 for setting details. 6. If an external drive module is installed, you must use the BIOS setup program to configure the drive type. Refer to Appendix B to properly configure the system. 7. If a drive module is present, install the operating system according to the manufacturer's instructions. BIOS Setup has an onboard BIOS setup program that controls many configuration options. These options are stored in a special nonvolatile, battery supported memory chip, and are collectively referred to as the "CMOS configuration" of the circuit board. CMOS configuration controls many details related to hardware behavior from the moment the power is applied. See Appendix B for details of BIOS setup program
Front/rear panel connector
Provides front panel access, an optional Gigabit Ethernet port, a 10/100 RJ45 connector, a serial port, SVGA, keyboard/mouse, manual reset switch, and status LEDs for the PMC expansion site. The drawing of the front panel is shown in Figure 1-5. The labels of the front panel connectors and indicators are as follows: • 10/100 10/100 Mbit Ethernet connector • G1 10/100/1000 Mbit Ethernet connector 1 (or LED) port 1 • G2 10/100/1000 Mbit LED port 2 • M/K mouse/keyboard connector • COM1 serial port • RST manual reset switch • S status LED • SVGA analog video connector provides rear I/O support for: digital video, serial ATA, COM2, 3 and 4, IDE driver, and two USB ports. By accessing these signals using RTMs such as VMIACC-0586/ACC-0586RC and VMIACC-0.590/ACC-0590RC, the RTM terminates at the industry standard connector. The front panel connector of (including connector pin and orientation) is defined in Appendix A. Rear panel connections are defined in the appropriate RTM installation guide. For compatible RTM from GE Fanuc embedded systems, contact sales.
