1900/65A-01-01-03-00-00风机振动监测器
1900/65A通用设备监测器数据表
本特利内华达州机械状态监测说明1900/65A通用设备监测仪旨在持续监测和保护各种应用和行业中使用的设备。监测器的低成本使其成为通用机器和过程的理想解决方案，可从连续监测和保护中受益。输入1900/65A提供四个传感器输入和四个温度输入。软件可以配置每个传感器输入以支持2线和3线加速度计、速度传感器或接近传感器。每个温度输入支持E、J、K和T型热电偶以及2线或3线RTD。输出1900/65A提供六个继电器输出、四个4-20 mA记录器输出和一个专用缓冲输出。
用户使用
1900配置软件根据任何通道或通道组合的OK、Alert和Danger状态配置继电器触点打开或关闭，并在任何记录器输出上提供来自任何通道的任何变量的数据。专用缓冲器输出可以为每个换能器输入提供信号。Modbus网关选项允许监视器直接向任何Modbus客户端提供静态变量、状态、事件列表、时间和日期信息，包括分布式控制系统（DCS）、监控和数据采集（SCADA）系统、可编程逻辑控制器（PLC）或System 1软件。监视器使用内部计数器和Modbus客户端/主时间参考来生成时间和日期信息。用户可以通过订购1900/01通信升级（参见订购信息部分）来升级没有Modbus网关的监视器。1900/65A文件：173401 Rev.T 1
Data sheet of 1900/65A general equipment monitor
Bentley Nevada Machinery Condition Monitoring Instructions The 1900/65A Universal Equipment Monitor is designed to continuously monitor and protect equipment used in a variety of applications and industries. The low cost of the monitor makes it an ideal solution for general-purpose machines and processes that benefit from continuous monitoring and protection. Input 1900/65A provides four sensor inputs and four temperature inputs. The software can configure each sensor input to support 2-wire and 3-wire accelerometers, speed sensors, or proximity sensors. Each temperature input supports E, J, K and T type thermocouples and 2-wire or 3-wire RTDs. Outputs 1900/65A provide six relay outputs, four 4-20 mA recorder outputs, and a dedicated buffered output.
User use
The 1900 configuration software configures relay contacts to open or close based on the OK, Alert, and Danger states of any channel or channel combination, and provides data on any recorder output for any variable from any channel. A dedicated buffer output can provide a signal for each transducer input. The Modbus Gateway option allows the monitor to provide static variables, status, event lists, time and date information directly to any Modbus client, including Distributed Control System (DCS), Monitoring and Data Acquisition (SCADA), Programmable Logic Controller (PLC), or System 1 software. The monitor uses internal counters and Modbus client/master time references to generate time and date information. The user can upgrade the monitor without Modbus gateway by ordering the 1900/01 communication upgrade (see the ordering information section). 1900/65A Document: 173401 Rev. T 1
