物理安装注意事项
通电时请勿安装或卸下电路板。包含PMC站点的主机系统在外观和板安装程序上差异很大。GE建议在安装此板之前检查主机系统安装程序。以下程序概述了将安装到具有可用PMC站点的合适PCI总线主板上的过程。1.从机箱上卸下主板。2.确保上的所有跳线都安装了所需的操作模式。“跳线配置和位置”。3.将牢固地安装到PMC连接器上。安装将固定至主板的螺钉。4.将主板重新安装在机箱中，接通电源。
Physical Installation Considerations
Do not install or remove the circuit board when it is powered on. The host systems containing PMC sites vary greatly in appearance and board installer. GE recommends checking the host system installer before installing this board. The following procedure outlines the procedure that will be installed on a suitable PCI bus motherboard with available PMC sites. 1. Remove the motherboard from the chassis. 2. Make sure that all jumpers on are installed with the desired operating mode. "Jumper configuration and location". 3. Install it firmly on PMC connector. Install the screws that secure to the system board. 4. Reinstall the motherboard in the chassis and turn on the power.
光收发器
前面板说明在前面板上有一个光收发器。 是前面板的图示。反光内存板的前面板上有三个LED指示灯。 概述了前面板LED。标签“RX”下方的端口为接收器，“TX”上方的端口为发射器。使用“LC”型光纤电缆小心：未连接光纤电缆时，需要安装提供的防尘帽，以防止灰尘和污垢进入光纤。如果未安装光纤电缆，请勿为通电。这可能导致眼睛受伤。状态LED的通电默认状态为“ON”。LED是用户定义的板状态指示器。通过写入控制和状态寄存器的第31位，状态LED可以切换为“ON”或“OFF”。如果接收器检测到光，信号检测LED将“开启”，并可作为检查光网络是否正确连接到接收器的简单方法。当电路板检测到自己的数据通过网络返回时，“自己的数据”LED将“打开”。LED颜色描述状态红色用户定义的板状态指示器。信号。DET.黄色表示光纤网络连接。自己的数据绿色检测何时接收到自己的数据。探测数据“RX”接收器连接“TX”发射器连接状态（红色）信号。DET（黄色）（绿色）自有数据工匠技术集团-质量仪器…带中断电缆配置的超高速光纤反射存储器具有多模或单模光纤接口。型多模或单模光纤连接器的示意图。
Optical transceiver
The front panel indicates that there is an optical transceiver on the front panel. Is an illustration of the front panel. There are three LED indicators on the front panel of the reflective memory panel. Provides an overview of the front panel LEDs. The port below the label "RX" is the receiver, and the port above "TX" is the transmitter. Caution when using "LC" type fiber optic cable: When the fiber optic cable is not connected, the provided dust cap shall be installed to prevent dust and dirt from entering the fiber. Do not power on the if the fiber optic cable is not installed. This can cause eye injuries. The power on default state of the status LED is "ON". The LED is a user-defined board status indicator. The status LED can be switched to "ON" or "OFF" by writing bit 31 of the control and status registers. If the receiver detects light, the signal detection LED will "turn on" and can be used as a simple way to check whether the optical network is correctly connected to the receiver. When the circuit board detects that its own data is returned through the network, the "own data" LED will "turn on". LED color describes the status Red user-defined board status indicator. Signal. DET. Yellow indicates optical network connection. Your own data green detects when your own data is received. Detect data "RX" receiver connection "TX" transmitter connection status (red) signal. DET (yellow) (green) Self owned Data Craftsman Technology Group - Quality Instruments... Ultra high speed fiber reflective memory with interrupted cable configuration has multi-mode or single-mode fiber interfaces. Schematic diagram of the Model A multimode or single-mode optical fiber connector.
