Panel 800操作员面板
Panel 800操作员面板旨在满足人机通信的需求。包括显示和控制文本、动态指示、时间通道、报警和配方处理等内置功能。操作面板大部分以面向对象的方式工作，使其易于理解和使用。使用配置工具panel Builder 800在个人计算机中进行面板的配置操作。然后将项目传输并存储在操作员面板中。操作员面板可以连接到许多类型的自动化设备，如PLC、伺服或驱动器。在本手册中，“控制器”一词用作连接设备的通用术语。本手册解释了如何安装操作面板。请参阅手册《面板生成器800，编程和安装》 了解更多信息。面板800的发布历史如下所示。版本说明用户文档4.1 Panel 800的初始版本和固件版本1.0.3BSE043449R101（MA00795）5.0固件版本2.0的版本，支持MMS报警和事件以及PROFIBUS-DP从机接口（CB801）。 固件版本3.0的发布。 （MA00795A）警告、注意、信息和提示图标 8 3BSE0043449R501警告、注意和提示图标本出版物包括警告、注意及信息（如适用），以指出安全相关或其他重要信息。它还包括向读者指出有用提示的提示。相应的符号应解释如下：尽管警告危险与人身伤害有关，警告危险与设备或财产损坏有关，但应理解，在某些操作条件下，损坏设备的操作可能导致工艺性能下降，导致人身伤害或死亡。因此，请完全遵守所有警告和注意事项。5.1固件版本4.0.3BSE043449R401 5.1/3 PP836A 3BSE044449R501的发布电气警告图标表示存在可能导致电击的危险。警告图标表示存在可能导致人身伤害的危险。警告图标表示与文本中讨论的概念相关的重要信息或警告。它可能表示存在可能导致软件损坏或设备/财产损坏的危险。信息图标提醒读者相关事实和条件。提示图标表示关于如何设计项目或如何使用特定功能的建议
Panel 800 operator panel
The Panel 800 operator panel is designed to meet the needs of man-machine communication. It includes built-in functions such as display and control text, dynamic indication, time channel, alarm and formula processing. Most of the operation panels work in an object-oriented way, making them easy to understand and use. Use the configuration tool panel builder 800 to configure the panel in a personal computer. The items are then transferred and stored in the operator panel. The operator panel can be connected to many types of automation equipment, such as PLC, servo or driver. In this manual, the term "controller" is used as a general term for connecting equipment. This manual explains how to install the operation panel. Refer to the manual Panel Generator 800, Programming and Installation for more information. The release history of panel 800 is shown below. Version Description User document 4.1 Initial version of Panel 800 and firmware version 1.0.3BSE043449R101 (MA00795) 5.0 firmware version 2.0 support MMS alarms and events and PROFIBUS-DP slave interface (CB801). Release of firmware version 3.0. (MA00795A) Warning, caution, information and prompt icon 8 3BSE0043449R501 Warning, caution and prompt icon This publication includes warnings, cautions and information (if applicable) to indicate safety related or other important information. It also includes tips that point out useful tips to the reader. The corresponding symbols shall be explained as follows: although the warning danger is related to personal injury and the warning danger is related to equipment or property damage, it should be understood that under certain operating conditions, the operation of damaged equipment may lead to the decline of process performance, resulting in personal injury or death. Therefore, please fully observe all warnings and precautions. 5.1 Firmware version 4.0.3BSE043449R401 5.1/3 The released electrical warning icon of PP836A 3BSE044449R501 indicates that there is a danger that may cause electric shock. The warning icon indicates that there is a danger that may cause personal injury. Warning icons represent important information or warnings related to the concepts discussed in the text. It may indicate a risk that may result in software damage or equipment/property damage. Information icons remind readers of relevant facts and conditions. Prompt icons represent suggestions on how to design a project or how to use specific features
