DSCL110A控制模块ABB
使用说明及参数
说明57520001-BC是一款完全可编程的Native BACnet®楼宇控制器，可使用以太网上的BACnet IP和BACnet在双绞线以太网10 BaseT上进行通信，或使用BACnet MS/TP协议在RS-485 LAN上进行通信。57520001-BC专为具有中等本地I/O要求的广泛应用而设计。它还支持BACstat®和其他Delta LINKnet设备。应用57520001-BC适用于控制具有中等I/O要求的各种成套装置和设备，如多室再热阀或小型空气处理装置、锅炉和冷却器。完全可编程的57520001-BC可以通过创建和修改BACnet对象和GCL+程序来定制特定应用。功能在GCL+超级电容器中完全可编程，用于实时时钟和SRAM备份（无需维护）支持LINKnet上的12个BACstat网络传感器，用于室内传感和控制，或LINKnet中的2个Delta现场模块，
用于I/O扩展每个模拟输出的执行器电源端子（24 VAC）（可由内部或辅助变压器供电）固件升级和数据库加载/通过网络保存可选的Modbus®RTU现场升级，带硬件键服务端口螺钉或DIN导轨安装LED指示灯，用于输出、电源、，CPU和SCAN状态规格BACnet设备配置文件BACnet楼宇控制器（B-BC）输入11个通用输入（10位），支持：0-5 VDC 0-10 VDC 10 kΩ热敏电阻干触点（使用10 kΩ热敏电阻跳线设置）4-20 mA输出8个模拟输出（0-10 VDC）设备寻址设置，通过DIP开关和跳线，或软件设置连接器可拆卸螺钉型端子连接器布线类别2/SELV
Instructions and parameters
Description: 57520001-BC is a fully programmable Native BACnet ® Building controller can use BACnet IP and BACnet on Ethernet to communicate on twisted pair Ethernet 10 BaseT, or BACnet MS/TP protocol to communicate on RS-485 LAN. The 57520001-BC is designed for a wide range of applications with moderate local I/O requirements. It also supports BACstat ® And other Delta LINKnet devices. Application 57520001-BC is suitable for controlling various complete sets of devices and equipment with medium I/O requirements, such as multi chamber reheat valves or small air handling devices, boilers and coolers. The fully programmable 57520001-BC can customize specific applications by creating and modifying BACnet objects and GCL+programs. The function is fully programmable in GCL+supercapacitor, used for real-time clock and SRAM backup (maintenance free) Support 12 BACstat network sensors on LINKnet, used for indoor sensing and control, or 2 Delta field modules in LINKnet,
Actuator power terminal (24 VAC) for I/O expansion of each analog output (can be powered by internal or auxiliary transformer) Firmware upgrade and database loading/optional Modbus saved via network ® RTU field upgrade, with hardware key service port screw or DIN rail mounted LED indicator, for output, power, CPU and SCAN status specifications, BACnet device configuration file, BACnet building controller (B-BC), input 11 universal inputs (10 bits), support: 0-5 VDC 0-10 VDC 10 k Ω thermistor dry contact (set with 10 k Ω thermistor jumper), 4-20 mA output, 8 analog outputs (0-10 VDC), device addressing setting, Connector detachable screw type terminal connector wiring category 2/SELV via DIP switches and jumpers, or software settings
