自动关闭油门
对于其他机车来说，扬声器外壳不需要花哨，可以用苯乙烯板、低音木甚至是硬纸板制成！一个35毫米的薄膜罐通常能产生很好的效果，纸巾卷的纸板管中心也是如此。数字声音解码器最适合在投标中安装，尽管它将适用于大型机车的锅炉。锅炉安装的优点是，需要在发动机和投标方之间布线的电线要少得多。这通常会以一些锅炉重量和牵引力的可能降低为代价。DSD在长时间运行后变热是正常的，其内置的热过载保护将在过热时自动关闭油门和音频放大器。因此，将DSD安装在能够散热最多的位置非常重要。避免将DSD放置在热源（如电机或灯）附近。您还需要决定如何同步排气。DSD提供两种同步方式。第一种方法是使用机械凸轮，它通过打开和关闭与机车车轮或车轴的开关触点来工作。
驱动轮内表面接触
排气凸轮开关最好安装在与驱动轮内表面接触的位置。这将提供最精确的同步，甚至在机车加速过快时产生车轮打滑效应！在紧急情况下，排气凸轮可以与软车轴一起使用，尽管同步效果并不精确，除非软车轴直径是机车司机直径的精确倍数。排气同步的另一种方法是DSD的自动排气功能，它产生与节气门设置成比例的爆震。对于机械凸轮难以安装的机车，如N型和较小HO型机车，建议采用这种方法。当与可编程速度曲线一起使用时，除了最慢的速度外，很难区分自动排气和排气凸轮之间的差异。接下来，您需要考虑将使用哪些灯光效果。DSD提供四个辅助功能输出，可用于控制微型灯或LED。两个输出通常用于车头
Auto throttle off
For other locomotives, the speaker shell does not need to be fancy, and can be made of styrene board, bass wood or even cardboard! A 35mm film can usually produce good results, as does the center of the cardboard tube of the tissue roll. The digital voice decoder is most suitable for installation in the tender, although it will be suitable for large locomotive boilers. The advantage of boiler installation is that there are much fewer wires between the engine and the Bidder. This usually comes at the expense of some possible reduction in boiler weight and traction. It is normal for DSD to become hot after a long time of operation, and its built-in thermal overload protection will automatically close the accelerator and audio amplifier in case of overheating. Therefore, it is very important to install the DSDs where they can dissipate the most heat. Avoid placing DSDs near heat sources such as motors or lamps. You also need to decide how to synchronize the exhaust. DSD provides two synchronization modes. The first method is to use a mechanical cam, which works by opening and closing the switch contacts with the locomotive wheels or axles.
Drive wheel inner surface contact
The exhaust cam switch should preferably be installed in contact with the inner surface of the drive wheel. This will provide the most accurate synchronization, even when the locomotive accelerates too fast, resulting in wheel slip effect! In an emergency, the exhaust cam can be used with the flexible axle, although the synchronization effect is not accurate, unless the flexible axle diameter is an accurate multiple of the locomotive driver's diameter. Another way of synchronizing the exhaust is the automatic exhaust function of the DSD, which generates detonation in proportion to the throttle setting. For locomotives that are difficult to install mechanical cams, such as N type and smaller HO type locomotives, this method is recommended. When used with a programmable speed curve, it is difficult to distinguish between automatic exhaust and exhaust cams except for the slowest speed. Next, you need to consider which light effects will be used. The DSD provides four auxiliary function outputs that can be used to control micro lamps or LEDs. Two outputs are usually used for the vehicle head
