可编程ABB可控板57120001-FG全系列机械保护装置
工具和材料
您将需要的工具和材料除了大多数建模师工作台上常见的手动工具外，您还应该拥有：低瓦数（低于25瓦！）烙铁松香芯焊锡X-acto刀微型螺丝刀组对角线切割机高速电机工具（如Dremel）欧姆表双面胶带硅胶RTV我们还推荐以下项目，以便于安装：微型连接器，便于从机车上轻松分离扬声器等项目。油门开大！销售P.N.810012 2针微连接器、P.N.820063 3针微连接器，P.N.830064 6针微连接器和P.N.840058，10组微型连接器引脚
扬声器
其包含适合于此目的的各种热缩管和提供一定长度的特氟隆管的P.N.810036。电工胶带会随着时间而散开，不建议使用！如果您打算利用特殊的照明效果，并希望为此使用1.5伏微型灯泡，请加速！提供两种尺寸；P.N.810022的直径为1.3mm。P.N.810024的直径为2.5mm，用于更大的比例尺。你也可以购买这些灯的经济六包。参见附录A。油门开大！还提供各种适合与DSD一起使用的8欧姆扬声器。选择适合机车的最大扬声器。尺寸越大，音质和音量越好。有关订购信息。
Tools and materials
The tools and materials you will need, in addition to the common hand tools on most modelers' workbenches, you should also have: low wattage (less than 25 watts!) Soldering iron, rosin core, soldering tin, X-acto knife, micro screwdriver set, diagonal cutting machine, high-speed motor tools (such as Dremel), ohmmeter, double-sided tape, silicone RTV, we also recommend the following items for easy installation: micro connector, easy to separate speaker and other items from the locomotive. Open the throttle! Sales of P.N.810012 2-pin micro connector, P.N.820063 3-pin micro connector, P.N.830064 6-pin micro connector and P.N.840058, 10 sets of micro connector pins
speaker
It includes various heat shrinkable tubes suitable for this purpose and P.N.810036 which provides Teflon tubes of certain length. The electrical tape will disperse over time, not recommended! If you intend to use special lighting effects and want to use a 1.5V miniature bulb for this purpose, please accelerate! Two sizes are available; P. The diameter of N.810022 is 1.3 mm. P. The diameter of N.810024 is 2.5mm for larger scale. You can also buy these lights for an economical six pack. See Appendix A. Open the throttle! A variety of 8 ohm speakers are also available for use with DSDs. Select the largest speaker suitable for the locomotive. The larger the size, the better the sound quality and volume. For ordering information.
