以太网适配器驱动程序磁盘准备
1.插入空白软盘。磁盘将被格式化并将文件复制到其中。2.如果还没有，请插入Windows驱动程序CD-ROM。单击“开始”、“运行”、“浏览”。在“查找范围”下拉选择菜单中，选择“Win_drivers”CD-ROM。双击“Win98”文件夹。双击“Lan1”文件夹。双击“Makedisk”。单击“确定”。3.按照屏幕提示操作。取出软盘并将其标记为“LAN1:Intel（R）GD82559ER快速以太网适配器”。4.当MS-DOS窗口标题更改为“Finished–Makedisk”时，单击“X”关闭窗口。5.插入另一张空白软盘。单击“开始”、“运行”、“浏览”。在“查找范围”下拉选择菜单中，选择“Win_drivers”CD-ROM。双击“Win98”文件夹。双击“Lan2”文件夹。双击“Makedisk”。单击“确定”。6.按照屏幕提示操作。取出软盘并将其标记为“LAN2:Intel（R）PRO Adapter Driver for Windows 9x”。7.当MS-DOS窗口标题更改为“Finished–Makedisk”时，单击“X”关闭窗口。8.取出CD-ROM。
以太网适配器驱动程序安装
1.插入Windows 98SE安装CD-ROM。插入“LAN1:Intel（R）GD82259ER快速以太网适配器”软盘。2.右键单击“我的电脑”并选择“属性”。单击“设备管理器”选项卡。3.选择第一个“PCI以太网控制器”（位于“其他设备”下），然后单击“属性”。4.在“PCI以太网控制器属性”窗口中，单击“驱动程序”选项卡。单击“更新驱动程序”。单击“下一步”两次。确保“软盘驱动器”是唯一选择的搜索位置，然后单击“下一步”。5.确认“更新设备驱动程序向导”显示“Windows驱动程序文件搜索设备：Intel（R）GD82559ER PCI适配器”。单击“下一步”。如果出现“复制文件”窗口，询问Windows 98SE CD-ROM的位置，请指定CD-ROM的路径（即d:\），然后单击“确定”。复制文件后，单击“完成”并取出软盘。6.在“System Settings Change”（系统设置更改）窗口中，显示“Do you want to restart your computer now？”（你想现在重新启动计算机吗？），单击“否”。单击“关闭”。7.插入“LAN2:Intel（R）PRO Adapter Driver for Windows 9x”软盘。8.在“系统属性”窗口中，选择剩余的“PCI以太网控制器”并单击“属性”。9.在“PCI以太网控制器属性”窗口中，单击“驱动程序”选项卡。单击“更新驱动程序”。单击“下一步”。选择“显示所有驱动程序的列表…”并单击“下一步”。10.在“更新设备驱动程序向导”窗口中，选择“网络适配器”并单击“下一步”。11.单击“拥有磁盘”。确保在“复制制造商文件”字段中输入了“A:\”，然后单击“确定”。12.在“选择设备”窗口中，选择“Intel（R）PRO/100 VE桌面适配器”并单击“确定”。13.单击“下一步”。复制文件后，单击“完成”并取出软盘。14.在“System Settings Change”（系统设置更改）窗口中，显示“Do you want restart your computer now？”（你想现在重新启动计算机吗？），单击“是”。15.当计算机重新启动时，可以根据需要更改显示器和网络配置。
Ethernet Adapter Driver Disk Preparation
1. Insert a blank floppy disk. The disk is formatted and the files are copied to it. 2. If not, insert the Windows driver CD-ROM. Click Start, Run, Browse. From the Look in drop-down selection menu, select the Win_drivers CD-ROM. Double click the "Win98" folder. Double click the Lan1 folder. Double click Makedisk. Click OK. 3. Follow the prompts on the screen. Remove the floppy disk and mark it as "LAN1: Intel (R) GD82559ER Fast Ethernet Adapter". 4. When the MS-DOS window title changes to "Finished – Makedisk", click "X" to close the window. 5. Insert another blank floppy disk. Click Start, Run, Browse. From the Look in drop-down selection menu, select the Win_drivers CD-ROM. Double click the "Win98" folder. Double click the Lan2 folder. Double click Makedisk. Click OK. 6. Follow the prompts on the screen. Remove the diskette and label it "LAN2: Intel (R) PRO Adapter Driver for Windows 9x". 7. When the MS-DOS window title changes to "Finished – Makedisk", click "X" to close the window. 8. Remove the CD-ROM.
Ethernet Adapter Drivers Installation
1. Insert the Windows 98SE installation CD-ROM. Insert the ‘LAN1: Intel(R) GD82259ER Fast Ethernet Adapter’ floppy disk. 2. Right-click on ‘My Computer’ and select ‘Properties’. Click on the ‘Device Manager’ tab. 3. Select the first ‘PCI Ethernet Controller’ (found under ‘Other devices’) and click ‘Properties’. 4. In the ‘PCI Ethernet Controller Properties’ window, click on the ‘Driver’ tab. Click ‘Update Driver’. Click ‘Next’ twice. Ensure ‘Floppy disk drives’ is the only search location selected and click ‘Next’. 5. Confirm the ‘Update Device Driver Wizard’ displays ‘Windows driver file search for the device: Intel(R) GD82559ER PCI Adapter’. Click ‘Next’. If a ‘Copying Files’ window appears asking for the location of the Windows 98SE CD-ROM, specify the path to the CD-ROM (i.e. d:\) and click ‘OK’. After files have been copied, click ‘Finish’ and remove the floppy disk. 6. At the ‘System Settings Change’ window that says ‘Do you want to restart your computer now?’, click ‘No’. Click ‘Close’. 7. Insert the ‘LAN2: Intel(R) PRO Adapter Driver for Windows 9x’ floppy disk. 8. In the ‘System Properties’ window, select the remaining ‘PCI Ethernet Controller’ and click ‘Properties’. 9. In the ‘PCI Ethernet Controller Properties’ window, click on the ‘Driver’ tab. Click ‘Update Driver’. Click ‘Next’. Select ‘Display a list of all the drivers...’ and click ‘Next’. 10. In the ‘Update Device Driver Wizard’ window, select ‘Network adapters’ and click ‘Next’. 11. Click ‘Have Disk’. Ensure ‘A:\’ is entered in the ‘Copy manufacturer’s files from’ field, and click ‘OK’. 12. At the ‘Select Device’ window, select ‘Intel(R) PRO/100 VE Desktop Adapter’ and click ‘OK’. 13. Click ‘Next’. After files have been copied, click ‘Finish’ and remove the floppy disk. 14. At the ‘System Settings Change’ window that says ‘Do you want to restart your computer now?’, click ‘Yes’. 15. When the computer reboots, changes can be made to the display and network configurations as desired.
