标准软盘驱动器控制器
集成外设3BHE013940R0002集成了国家半导体超级I/O（SIO）芯片。SIO为3BHE013940R0002提供标准软盘驱动器控制器、两个16550 UART兼容串行端口、键盘和鼠标端口以及用于系统监控功能的通用I/O。两个串行端口信号都可从前面板获得。软盘信号可通过VME背板连接器获得，并可通过适当的转换实用程序板（VMIACC-0562）访问。IDE接口由Intel I/O控制器集线器（ICH2）芯片提供。IDE接口支持两个通道，即主通道和辅助通道。辅助通道在板上路由到可选的紧凑型闪存插槽。主通道从VME背板路由至VMIACC-0562转换实用程序板，该板终止于标准的40针接头。此通道可以支持两个驱动器，一个主驱动器和一个从驱动器。3BHE013940R0002上的IDE接口支持ATA-33、ATA-66和ATA-100驱动器，并根据使用的驱动器类型自动确定正确的操作模式。为了在ATA-100模式下正常工作，必须使用特殊的80芯电缆，而不是标准的40芯电缆。此电缆通常可从ATA-100驱动器制造商处获得。
以太网控制器双网络功能
以太网控制器双网络功能由外部Intel 82559ER以太网控制器和Intel ICH2芯片内部的MAC提供。两个以太网控制器都是基于PCI的，并且是软件可配置的。3BHE013940R0002支持双10BaseT和100BaseTx以太网。10BaseT基于10BaseT标准的网络使用非屏蔽双绞线电缆，通过允许使用现有电话线路和连接器，为网络提供了经济的解决方案。RJ-45连接器与10BaseT标准一起使用。10BaseT的最大长度为100米。100BaseTx 3BHE013940R0002还支持100BaseTx以太网。基于100BaseTx标准的网络使用非屏蔽双绞线电缆和RJ-45连接器。100BaseTx的最大长度为100米。
Standard Floppy Drive Controller
The integrated peripheral 3BHE013940R0002 integrates the National Semiconductor Super I/O (SIO) chip. SIO provides 3BHE013940R0002 with a standard floppy disk drive controller, two 16550 UART compatible serial ports, keyboard and mouse ports, and general I/O for system monitoring functions. Both serial port signals are available from the front panel. The floppy disk signal is available through the VME backplane connector and is accessed through the appropriate conversion utility board (VMIACC-0562). The IDE interface is provided by the Intel I/O Controller Hub (ICH2) chip. The IDE interface supports two channels, namely the primary channel and the secondary channel. The secondary channel is routed on the board to the optional compact flash slot. The primary channel is routed from the VME backplane to the VMIACC-0562 conversion utility board, which terminates at the standard 40 pin connector. This channel can support two drives, one master drive and one slave drive. The IDE interface on 3BHE013940R0002 supports ATA-33, ATA-66, and ATA-100 drives, and automatically determines the correct operation mode according to the drive type used. In order to work properly in the ATA-100 mode, a special 80 core cable must be used instead of the standard 40 core cable. This cable is usually available from the ATA-100 drive manufacturer.
Dual network function of Ethernet controller
The dual network function of Ethernet controller is provided by the external Intel 82559ER Ethernet controller and the internal MAC of Intel ICH2 chip. Both Ethernet controllers are PCI based and software configurable. 3BHE013940R0002 supports dual 10BaseT and 100BaseTx Ethernet. 10BaseT network based on 10BaseT standard uses unshielded twisted pair cable, which provides an economical solution for the network by allowing the use of existing telephone lines and connectors. RJ-45 connector is used with 10BaseT standard. The maximum length of 10BaseT is 100 meters. 100BaseTx 3BHE013940R0002 also supports 100BaseTx Ethernet. The network based on 100BaseTx standard uses unshielded twisted pair cables and RJ-45 connectors. The maximum length of 100BaseTx is 100 meters.
