详细信息
BIOS设置3BHE046836R0102有一个板载BIOS设置程序，可控制许多配置选项。这些选项保存在特殊的非易失性、电池支持的存储器芯片中，统称为电路板的“CMOS配置”。CMOS配置从施加功率的那一刻起控制与硬件行为有关的许多细节。3BHE046836R0102出厂时，CMOS中的硬盘驱动器类型配置设置为AUTO。附录C中包含了3BHE046836R0102 BIOS设置程序的详细信息。
前面板连接器和指示灯的标签
前/后面板连接器3BHE046836R0102提供前面板访问PMC扩展站点、VGA连接器、10/100以太网连接器、手动复位开关、COM 1和2、双USB和状态LED。3BHE046836R0102前面板的图纸如图1-3所示。前面板连接器和指示灯的标签如下：•LAN 1 10/100 Mbit以太网连接器•LAN 2 10/100 Mb以太网连接器•SVGA SVGA视频连接器•RST手动复位开关•COM 1:2两个COM端口•M/K双鼠标/键盘连接器•USB双USB连接器•RPIB状态LED 3BHE046836R0102为以下各项提供后部I/O支持：PMC、，IDE驱动器和软盘驱动器。这些信号可通过使用后面板转换板（如VMIACC-0562）访问，该转换板终止于工业标准连接器。3BHE046836R0102的前面板连接器（包括连接器引脚和方向）在附录A中定义。后面板连接在相应的后面板过渡实用板安装指南中定义。请参阅3BHE046836R0102产品规格，了解VMIC提供的兼容后面板转换实用板。
detailed information
BIOS Setup 3BHE046836R0102 has an onboard BIOS setup program that controls many configuration options. These options are stored in special nonvolatile, battery supported memory chips, and are collectively referred to as "CMOS configurations" of circuit boards. CMOS configuration controls many details related to hardware behavior from the moment power is applied. When 3BHE046836R0102 leaves the factory, the hard disk drive type configuration in CMOS is set to AUTO. Appendix C contains details of the 3BHE046836R0102 BIOS setup program.
Labels for front panel connectors and indicators
Front/rear panel connector 3BHE046836R0102 provides front panel access to PMC expansion site, VGA connector, 10/100 Ethernet connector, manual reset switch, COM 1 and 2, dual USB and status LED. The drawing of 3BHE046836R0102 front panel is shown in Figure 1-3. The labels of the front panel connectors and indicators are as follows: • LAN 1 10/100 Mbit Ethernet connector • LAN 2 10/100 Mb Ethernet connector • SVGA SVGA video connector • RST manual reset switch • COM 1:2 two COM ports • M/K dual mouse/keyboard connector • USB dual USB connector • RPIB status LED 3BHE046836R0102 provides rear I/O support for PMC, IDE drive, and floppy drive. These signals can be accessed by using the rear panel conversion board (such as VMIACC-0562), which terminates in an industry standard connector. The front panel connector (including connector pin and orientation) of 3BHE046836R0102 is defined in Appendix A. The rear panel connections are defined in the corresponding rear panel transition utility board installation guide. Please refer to the 3BHE046836R0102 product specification for the compatible rear panel conversion utility board provided by VMIC.
