CI871K01通信单元
CI871K01通信单元和DC/DC转换器通过CEX总线从+24 V电源获得所需电压。功能和优点通过以太网连接PROFINETIO设备一般信息物品编号3 se056767r1通信协议人员生命周期状态班集成电路或从控主人变速箱速10/100Mbit/s线路冗余不模块冗余对热插拔对与HI控制器一起使用对详细数据CEX总线上的最大单位12连接器RJ-45内螺纹（8针）24V消耗标准。典型160mA1.数据表CI871 Classic | 2022-10-26 |版权所有©2022 ABBE环境与认证工作55°C防护等级符合EN60529、IEC 529的IP20CE标志对危险场所UL 60079-15，cULus 1级，2区，AEx nA IIC T4，ExnA IIC-T4Gc X海事证书ABS、BV、DNV-GL、LR符合RoHS标准指令/2011/65/EU（EN 50581:2012）WEEE合规性指令/2012/19/EU尺寸宽度59毫米（2.3英寸）身高185毫米（7.3英寸）深度127.5毫米（5.0英寸）重量（包括底座）700克（1.5磅）2.CI871 Classic数据表
CI871K01 communication unit
CI871K01 communication unit and DC/DC converter obtain the required voltage from+24V power supply through CEX bus. Functions and advantages Connect PROFINETIO equipment via Ethernet General information Item No. 3 se056767r1 Communication protocol Personnel life cycle status shift Integrated circuit or slave master gearbox speed 10/100Mbit/s Line redundancy No module redundancy Hot plug pair Used with HI controller Maximum unit 12 connector RJ-45 internal thread (8-pin) 24V consumption standard on CEX bus. Typical 160mA1. Data Sheet CI871 Classic | 2022-10-26 | All rights reserved © 2022 ABB environment and certification work 55 ° C protection level complies with IP20CE mark of EN60529 and IEC 529. For hazardous places, UL 60079-15, cULus Class 1, Zone 2, AEx nA IIC T4, ExnA IIC-T4Gc X maritime certificates ABS, BV, DNV-GL LR complies with RoHS standard directive/2011/65/EU (EN 50581:2012) WEEE compliance directive/2012/19/EU dimension width 59 mm (2.3 inches) height 185 mm (7.3 inches) depth 127.5 mm (5.0 inches) weight (including base) 700 g (1.5 pounds) 2. CI871 Classic data sheet
