FSK INPUTS (FIELD BUS MODE)
IMFEC11 ONLY For IMFEC11 modules in the field bus mode, all data and communication are FSK encoded digital signals on a shared bus and require decoding. The microprocessor can read any input by specifying the bus address of the device. The signal enters the FSK communication circuitry through a transmit/receive gate that works with the multiplexer and communication circuitry. Figure 2-3 shows the FSK input circuit with the FSK multiplexer and FSK transmit/receive gate. After decoding the digital input, the FEC module can store that data in memory or send it directly to the controlling module (MFP/MFC) through the I/O expander bus interface.The FEC module can digitize analog values within the range of -10 to +10 volts. Figure 2-4 shows the analog-to-digital conversion circuitry. The analog-to-digital control chip provides the logic needed to control the dual slope integrator. The analog-to-digital conversion takes place in three stages: input integration, de-integration with a +10 or -10 volts reference and zeroing the integrator/de-integrator.The microprocessor signals the ADC circuitry to begin converting inputs. The ADC circuitry selects the input, reference voltage and conversion operation through the select multiplexer. The input signal from the select multiplexer passes through buffers and a differential amplifier that converts the input signal to a single ended voltage. Then the signal goes to the input of the integrator/de-integrator stage.
I/O Expander Bus Interface Circuitry
The FEC module uses a semicustom gate array for the I/O expander bus interface. An integrated circuit (IC) holds all the control logic and communication protocol. This IC circuit provides the following functions: • Address comparison and detection. • Function code latching and decoding. • Read strobe generation. • Data line filtering of bus signals. • On-board bus drivers.The ADC circuitry selects a positive or negative reference voltage for this stage. Once the integrator is set to zero, the ADC circuitry allows the integrator to run until its output reaches the reference voltage. At this point, the ADC circuitry selects the de-integration operation and begins a count until the zero crossing circuit detects the signal at zero. A feedback and zeroing amplifier sets the integrator to zero and the process repeats with the opposite polarity of the input and reference voltage. The count that the ADC circuitry takes during the de-integration operation is the digital equivalent of the input. It sends that information and the polarity to the microprocessor. The microprocessor places it into memory and signals the ADC circuitry to begin the next conversion.
