3BSE066485R1输入控制模块
特殊处理处理电子电路时，请遵守以下步骤：注意：在处理模块时，始终使用贝利控制现场静电套件（零件号1948385_1-包括两个腕带、接地线组件、鳄鱼夹和静电消散工作面）。该套件旨在将技术人员和静电消散工作面连接到同一接地点，以防止静电放电对模块造成损坏。1.使用防静电袋。将模块放在防静电袋中，直到准备好将其安装到系统中。保存包装以备将来使用。2.打开前的地袋。在打开装有半导体组件的袋子之前，将其接触到设备外壳或地面以均衡电荷。3.避免接触电路。通过边缘处理组件；避免接触电路。4.避免半导体的部分连接。使用前，请确认连接到模块的所有设备均正确接地。5.地面测试设备。6.使用防静电现场维修真空。必要时清除模块上的灰尘。7.使用接地腕带。将腕带连接到电源输入面板上的相应接地插头。电源输入面板上的接地插头连接到机柜机箱接地。8.请勿使用铅笔设置双列直插式开关。为避免污染油尺开关触点，从而导致不必要的电路板故障，请勿使用铅笔设置油尺开关。
引言
本节解释了在将任何INFI-NET到计算机接口模块投入运行之前必须做的事情。在操作模块之前，按照步骤出现的顺序阅读、理解并完成这些步骤。拆箱和检查1.立即检查硬件是否有运输损坏。2.将任何此类损坏通知最近的贝利控制销售办事处。3.向处理货物的运输公司提出任何损坏索赔。4.使用原包装材料和容器存放硬件。5.将硬件存放在空气质量良好、没有极端温度和湿度的环境中。INNIS01网络接口从模块配置两个INFI-NET到计算机的接口都需要一个INNIS02网络接口从模件（NIS）。按如下方式配置NIS模块。NIS模块上有四个双列直插式开关。双列直插式开关及其功能如下所述。有关双列直插式开关的位置，请参见图3-1。此双列直插式开关设置节点地址。有效节点地址为1到250。请参阅表3-1。第一极是二进制权重为128的MSB位。第八极是二进制加权为1的LSB位。在提供的空间中记录双列直插式开关SW1的设置。此双列直插式开关设置主INFI-NET环路的环路编号。有效回路编号为1到250。参考表3-2。在提供的空间中记录双列直插式开关SW2的设置。
SPECIAL HANDLING
Observe these steps when handling electronic circuitry: NOTE: Always use Bailey Controls field static kit (part number 1948385_1 - consisting of two wrist straps, ground cord assembly, alligator clip, and static dissipating work surface) when working with the modules. The kit is designed to connect the technician and the static dissipating work surface to the same ground point to prevent damage to the modules by electrostatic discharge. 1. Use Static Shielding Bag. Keep the modules in the static shielding bag until you are ready to install them in the system. Save the packaging for future use. 2. Ground Bags before Opening. Before opening a bag containing an assembly with semiconductors, touch it to the equipment housing or a ground to equalize charges. 3. Avoid Touching Circuitry. Handle assemblies by the edges; avoid touching the circuitry. 4. Avoid Partial Connection of Semiconductors. Verify that all devices connected to the module are properly grounded before using them. 5. Ground Test Equipment. 6. Use Antistatic Field Service Vacuum. Remove dust from the module if necessary. 7. Use a Grounded Wrist Strap. Connect the wrist strap to the appropriate grounding plug on the power entry panel. The grounding plug on the power entry panel is connected to the cabinet chassis ground. 8. Do Not Use Lead Pencils to Set Dipswitches. To avoid contamination of dipswitch contacts that can result in unnecessary circuit board malfunction, do not use a lead pencil to set a dipswitch.
INTRODUCTION
This section explains what must be done before placing any INFI-NET to computer interface modules into operation. Read, understand, and complete the steps in the order they appear before operating the modules.UNPACKING AND INSPECTION 1. Examine the hardware immediately for shipping damage. 2. Notify the nearest Bailey Controls sales office of any such damage. 3. File a claim for any damage with the transportation company that handled the shipment. 4. Use the original packing material and container to store the hardware. 5. Store the hardware in an environment of good air quality, free from temperature and moisture extremes. INNIS01 NETWORK INTERFACE SLAVE MODULE CONFIGURATION Both INFI-NET to computer interfaces require an INNIS01 Network Interface Slave Module (NIS). Configure the NIS module as follows.There are four dipswitches on the NIS module. The dipswitches and their functions are described below. See Figure 3-1 for dipswitch locations.This dipswitch sets the node address. Valid node addresses are one through 250. Refer to Table 3-1. Pole one is the MSB bit with a binary weight of 128. Pole eight is the LSB bit with a binary weight of one. Record the dipswitch SW1 settings in the space provided.This dipswitch sets the loop number of the loop off of the main INFI-NET loop. Valid loop numbers are one through 250. Refer to Table 3-2. Record the dipswitch SW2 setting in the space provided.
产品优势
1：国外专业的供货渠道，具有价格优势
2：产品质量保证，让您售后无忧
3：全国快递包邮
4：一对一服务
公司主营范围简介
PLC可编程控制器模块，DCS卡件，ESD系统卡件，振动监测系统卡件，汽轮机控制系统模块，燃气发电机备件等，优势品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各种进口工业零部件、欧美进口模块。
产品广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、塑胶机械、电力、水利、水处理/环保、锅炉供暖、能源、输配电等等
