3PHE022287R0001热电偶输入模块
IMMPI01多功能处理器接口模块
IMMPI01多功能处理器接口模块（MPI）为INICT03 INFI-NET到计算机传输模块（ICT）提供通信端口。它包含ICT模块可以使用的I/O端口（即RS-232-C、SCSI）。MPI模块是一种接口设备，用于处理与ICT模块之间的I/O。ICT模块的控制和数据信号通过60针带状电缆传输至MPI模块。MPI模块连接到NTMP01多功能处理器终端单元或NIMP01多函数处理器终端模块。输入和输出信号通过NKTU01、NKTU02、NKTU11或NKTU12电缆进入或离开MPI电路板至终端设备。SCSI连接从面板出来，用于连接到主机。INFI-NET到计算机的接口具有以下功能：•使用INFI-NET，它提供工厂范围的通信网络。•INFI-NET时间同步整个工厂的控制过程。•每个INFI-NET节点可以独立于其他INFI-NET节点运行。•计算机接口模块在电源故障时提供局部启动和关闭，无需操作员干预。•10兆波特的响应速率提供了及时的信息交换。•信息和通信技术模块将处理信息打包，以实现最大传输效率计算机接口模块处理四种消息类型：广播、时间同步、多播和NIS轮询。•所有消息都包含循环冗余校验码（CRC）和校验和，以确保数据完整性。
指令内容
本手册由八节和六个附录组成。简介概述计算机接口。它包含模块描述、功能和规范。说明和操作说明模块操作。安装包括操作指南，并解释如何在将模块投入运行之前配置模块。操作程序提供有关正常模块操作的信息。故障排除说明如何使用错误代码对模块进行故障排除，并列出纠正措施。维护包含模块的维护计划。维修/更换程序说明如何更换模块。支持服务解释贝利控制公司提供的客户培训以及有关订购更换零件的信息。附录提供有关终端装置和模块配置的信息。按顺序阅读本手册。在使用模块之前，必须熟悉本手册的全部内容。本手册旨在实现快速信息检索。1.阅读并执行第3.2节中的所有步骤。在给计算机接口通电之前，彻底阅读第4节。3.如果出现问题，请参阅第5节。本节将帮助诊断和纠正问题。4.有关计划维护要求，请参阅第6节。
IMMPI01 Multi-Function Processor Interface Module
The IMMPI01 Multi-Function Processor Interface Module (MPI) provides the INICT03 INFI-NET to Computer Transfer Module (ICT) with communication ports. It contains I/O ports (i.e., RS-232-C, SCSI) that the ICT module can use. The MPI module is an interface device that handles I/O to and from the ICT module. Control and data signals from the ICT module travel through a 60-pin ribbon cable to the MPI module. The MPI module connects to an NTMP01 Multi-Function Processor Termination Unit or NIMP01 Multi-Function Processor Termination Module. Input and output signals enter or leave the MPI circuit board through a NKTU01, NKTU02, NKTU11, or NKTU12 cable to the termination device. The SCSI connection comes out of the faceplate for connection to a host computer.The INFI-NET to computer interfaces have the following features: • INFI-NET, which provides a plantwide communication network, is used. • INFI-NET time synchronizes the control process plantwide. • Each INFI-NET node can operate independently of other INFI-NET nodes. • Computer interface modules provide localized start-up and shutdown on power failure without operator intervention. • The 10-megabaud response rate gives timely information exchange. • The ICT modules package process information for maximum transmission efficiency.• The computer interface modules handle four message types: broadcast, time synchronization, multicast and NIS poll. • All messages contain cyclic redundancy check codes (CRC) and checksums to ensure data integrity.
INSTRUCTION CONTENT
This manual consists of eight sections and six appendices. Introduction Provides an overview of the computer interfaces. It contains module descriptions, features, and specifications. Description and Operation Explains module operation. Installation Covers handling guidelines and explains how to configure the modules before placing them into operation. Operating Procedures Provides information about normal module operation. Troubleshooting Explains how to troubleshoot the modules using error codes and lists the corrective action. Maintenance Contains a maintenance schedule for the modules. Repair/Replacement Procedures Explains how to replace the modules. Support Services Explains the customer training Bailey Controls Company provides and information about ordering replacement parts. Appendices Provides information on termination unit and module configuration.Read this manual in sequence. It is important to become familiar with the entire contents of this manual before using the modules. This manual is organized to enable quick information retrieval. 1. Read and perform all steps in Section 3. 2. Thoroughly read Section 4 before applying power to the computer interfaces. 3. Refer to Section 5 if a problem occurs. This section will help to diagnose and correct a problem. 4. Refer to Section 6 for scheduled maintenance requirements.
