产品内容介绍
FISHER CL6821X1-A5输出模块
接线板要在I/O模块和现场设备之间布线，请在I/O模块上安装一个压力夹端子或KS电缆接口适配器。当使用压力钳端子时，I/O模块可以直接与现场设备连接。使用KS电缆接口适配器时，I/O模块通过端子板与现场设备连接。有两种类型的压力钳接线端子：单冗余型和双冗余型。使用双冗余类型，可以在接线板上配置双冗余I/O模块。此外，MIL连接器电缆可以直接连接到输入/输出模块，而无需将接线板安装到输入/输入模块。MIL连接器电缆由客户提供。提供了一个电缆连接器盖（ACCC01），以防止MIL连接器电缆松动。标题为“I/O模块和接线板组合”的表格列出了I/O模块、接线板和连接器电缆之间的连接。本质安全区域和非本质安全区域之间的距离应大于等于50 mm。带有内置屏障的模块应安装在一个节点单元中与其他模块区域分开的区域。如果是AN10, 必须在带有内置屏障的模块区域和其他模块区域之间安装绝缘隔板（零件号T9083NA）。如果是AFV10 和AFV30, 必须安装绝缘隔断套件（零件号T9083ND），以保持本安区和非本安区之间的距离。示例：隔离an中的两个区域时10D，其中“（S）”表示单冗余，“（D）”表示双冗余。示例：在an中安装模块时10D，其中“（S）”表示单冗余，“（D）”表示双冗余。
机柜内安装
如果机柜上部空间中有风扇，请将模块安装在比风扇低3个单元（1个单元=44.45 mm）的位置。环境工作温度条件下的安装限制当节点（-20至70℃-可选温度环境）在温度环境（60至70℃）下使用时，请遵循以下限制：ANT10U可以在60至70°C的温度下使用，与在-20至50°C的温度下使用相同，无任何附加限制。•可安装输入/输出模块（IOM）的最大数量：每个节点最多可安装4个模块。•在SB401、ANT401、ANT411、ANT502、ANT512、EB501和IOM之间制作一个空插槽（一个或多个）。安装带有内置屏障的模块时，必须在插槽8中安装绝缘隔板（零件号T9083NA）。•安装IOM时，在IOM和IOM之间留出一个空插槽（一个或多个）。安装双面IOM时，为每个双面IOM制作一个空插槽（至少两个插槽）。•最多可以使用8个继电器输出模块（ADR541）。为了保持参考结补偿精度，请确保满足以下条件。压力钳端子不应受到辐射热的影响。有关参考结补偿精度的详细信息，请参阅“模拟I/O模块”（GS33K50F60-50E）。仅适用于节点的规格•请勿在AAT141安装的节点下方安装散热装置。•不要将AAT141安装在气流直接影响的地方。•不要在CP461和CP451旁边安装AAT141。•不要在总线接口模块SB401、ANT502、ANT512和EB501旁边安装AAT141。•AAT141旁边的可安装模块如下。安装IOM以外的其他IOM时，请在每侧制作一个空插槽（一个或多个）。
Terminal Blocks
To wire between I/O Module and field devices, install a pressure clamp terminal or KS cable interface adapter on the I/O Module. When a pressure clamp terminal is used, the I/O Module can be wired directly with the field devices. When the KS cable interface adapter is used, the I/O Module is wired with the field devices via terminal boards. Two types of pressure clamp terminal blocks are available: single and dual-redundant types. Using the dual-redundant type, dual-redundant I/O Modules can be configured on the terminal block. In addition, a MIL connector cable can be connected directly to an I/O Module without installing a terminal block to the I/O Module. The MIL connector cable are furnished by the customer. A cable connector cover (ACCC01) is provided in order to prevent the MIL connector cable from coming loose. The table entitled “Combinations of I/O Modules and Terminal Blocks” lists connections among I/O Modules, terminal blocks and connector cables.Please keep a distance of 50 mm or more between the intrinsically safe area and the non-intrinsically safe area. Modules with built-in barriers should be installed in an area separate from the area of other modules in one node unit. In case of AN10, an insulating partition (Part No. T9083NA) must be installed between the area of Modules with Built-in Barrier and the area of other Modules. In case of AFV10 and AFV30, an insulating partition kit (Part No. T9083ND) must be installed to keep a distance between the intrinsically safe area and the non-intrinsically safe area. Example: When isolating the two areas in an AN10D as follows where “(S)” indicates Single and “(D)” indicates Dual-Redundant.Example: When installing modules in an AN10D as follows where “(S)” indicates Single and “(D)” indicates Dual-Redundant.
Installation in Cabinet
If there is a fan in the upper space of the cabinet, install the module in a position that is 3 units (1 unit = 44.45 mm) lower than the fan. Limitations of Installation under the Ambient Operating Temperature Conditions When the node (-20 to 70 ˚C - optional temperature environment) is to be used under the temperature environment (60 to 70 ˚C), please follow the restrictions below: ANT10U can be used at temperatures from 60 to 70°C without any additional restrictions in the same way as at temperatures from -20 to 50°C. • Max. number of installable input/output modules (IOM): Up to 4 modules can be installed per node. • Make an empty slot (one or more) between SB401, ANT401, ANT411, ANT502, ANT512, EB501 and IOM. When installing modules with built-in barriers, insulating partition (Part No. T9083NA) must be installed in slot No. 8. • When installing IOM, make an empty slot (one or more) between IOM and IOM. When installing duplexed IOM, make an empty slot (at least two slots) for each duplexed IOM. • Up to 8 relay output modules (ADR541) can be used.To keep the reference junction compensation accuracy, make sure to meet the following conditions. The pressure clamp terminal should not be affected by radiated heat, For details of the reference junction compensation accuracy, refer to “Analog I/O Modules” (GS33K50F60-50E). Specifications for node only • Do not install a heat-radiating unit beneath the AAT141 installed node. • Do not install AAT141 in the place where airflow affects directly. • Do not install an AAT141 next to the CP461 and CP451. • Do not install AAT141 next to the bus interface modules, SB401,ANT502,ANT512 and EB501. • The installable modules in the next to AAT141 are as follows. When installing other than following IOM, make an empty slot (one or more ) in each side.
