RELIANCE 813.23.20 G 813.23.20DQY输入控制卡
串行接口COM1规格有关如何连接控制器和其他类型设备的信息，请参阅屏幕编辑软件的相应设备驱动程序手册。串行端口未隔离。SG（信号接地）和FG（机架接地）端子连接在面板内。有关如何连接控制器和其他类型设备的信息，请参阅屏幕编辑软件的相应设备驱动程序手册。串行端口未隔离。SG（信号接地）和FG（机架接地）端子连接在面板内。串行接口COM2 HMIGTO6310/HMIGTO6.315：通过RS-485电缆的RJ45连接器。注：设置RS-485通信时，某些设备的电缆图可能需要在终端侧极化。该终端不需要任何特殊设置，因为它可以自动处理极化。安装面板时需要安装紧固件。将面板安装在提供清洁、干燥、坚固和受控环境的外壳中： HMIGTO（HMIGTO2315/HMIGTO5315/HMIGTO6315除外）：IP65、1型、4X型[仅限室内使用]或13型外壳。 HMIGTO2315/HMIGTO5315/HMIGTO6315:IP66k，类型1，类型4X[仅限室内使用]或类型13外壳。检查安装壁或机柜表面是否平整、状况良好，且无锯齿状边缘。金属加固条可连接到墙壁内侧靠近面板切割处，以增加其刚度。根据要求的强度水平，确定外壳壁的厚度：1.6…5 mm（0.06…0.2 in）。确保周围空气温度和环境湿度在其指定范围内。周围空气温度：0…50°C（32…122°F）或0…55°C（32-131°F）（请参阅HMIGTO的环境规范）；环境湿度：10至90%RH；湿球温度：最高39°C[102°F]。在机柜或外壳中安装面板时，周围空气温度是机柜或外壳的内部温度。
直流电源线准备
确保接地线的规格与电源线相同或更大。 请勿在电源的电源线中使用铝线。 如果个别导线的端部没有正确绞合，导线可能会产生短路。 尽可能使用0.75至2.5 mm2（AWG 18-13）的电线作为电源线，并在连接端子之前扭转电线末端。 导线类型为实心或绞合线。 电线类型的现场接线端子标记（仅限75°C[167°F]铜导线）。直流电源连接器（插头）规格：弹簧夹接线盒HMIGTO1300/1310/HMIGTO2300/2310/2315/HMIGTO 3510/4310过度电磁干扰 连接功能接地（FG）端子时，确保导线接地。HMIGTO不接地会导致过度电磁干扰（EMI）。需要接地以满足EMC级别的抗扰度。 在连接HMIGTO的电源端子之前，先断开电源。 直流型号仅使用24 Vdc电源。使用任何其他级别的电源都可能损坏电源和HMIGTO。 由于HMIGTO未配备电源开关，请确保将电源开关连接到电源。 确保HMIGTO的FG端子接地。 在向HMIGTO通电之前，更换并固定系统的所有元件
Specifications of Serial Interface COM1
For information on how to connect controllers and other types of equipment, refer to the corresponding device driver manual of your screen editing software.The serial port is not isolated. The SG (signal ground) and FG (frame ground) terminals are connected inside the panel.For information on how to connect controllers and other types of equipment, refer to the corresponding device driver manual of your screen editing software. The serial port is not isolated. The SG (signal ground) and FG (frame ground) terminals are connected inside the panel. Serial Interface COM2 HMIGTO6310 / HMIGTO6315: RJ45 connector via a RS-485 cable. NOTE: When setting up RS-485 communication, the cable diagram for some equipment may require polarization on the terminal side. This terminal does not require any special setting as it handles polarization automatically The installation fasteners are required when installing the panel. Mount the panel in an enclosure that provides a clean, dry, robust, and controlled environment: HMIGTO (except HMIGTO2315 / HMIGTO5315 / HMIGTO6315): IP65, Type 1, Type 4X [Indoor Use Only] or Type 13 enclosure. HMIGTO2315 / HMIGTO5315 / HMIGTO6315: IP66k, Type 1, Type 4X [Indoor Use Only] or Type 13 enclosure.Check that the installation wall or cabinet’s surface is flat, in good condition and has no jagged edges. Metal reinforcing strips may be attached to the inside of the wall, near the panel-cut, to increase its rigidity. Decide on the thickness of the enclosure wall, based on the level of strength required: 1.6...5 mm (0.06...0.2 in). Be sure that the surrounding air temperature and the ambient humidity are within their designated ranges. Surrounding air temperature: 0...50 °C (32...122 °F) or 0...55 °C (32...131 °F) (see the Environment Specifications for your HMIGTO); ambient humidity: 10 to 90%RH; wet bulb temperature: maximum 39 °C [102 °F]. When installing the panel in a cabinet or enclosure, the surrounding air temperature is the cabinet's or enclosure's internal temperature.
DC Power Cord Preparation
Make sure that the ground wire is either the same or heavier gauge than the power wires. Do not use aluminum wires in the power supply's power cord. If the ends of the individual wires are not twisted correctly, the wires may create a short circuit. Wherever possible, use wires that are 0.75 to 2.5 mm2 (AWG 18 - 13) for the power cord, and twist the wire ends before attaching the terminals. The conductor type is solid or stranded wire. Field wiring terminal marking for wire type (75 °C [167 °F] copper conductors only). DC Power Supply Connector (Plug) Specifications: Spring Clamp Terminal Blocks HMIGTO1300/1310 / HMIGTO2300/2310/2315 / HMIGTO3510/4310
EXCESSIVE ELECTROMAGNETIC INTERFERENCE When the functional ground (FG) terminal is connected, be sure the wire is grounded. Not grounding the HMIGTO can result in excessive Electromagnetic Interference (EMI). Grounding is required to meet EMC level immunity. Remove power before wiring the HMIGTO’s power terminals. The DC model uses only 24 Vdc power. Using any other level of power can damage both the power supply and the HMIGTO. Since the HMIGTO is not equipped with a power switch, be sure to connect a power switch to the power supply. Be sure to ground the HMIGTO's FG terminal. Replace and secure all elements of the system before applying power to the HMIGTO
