RELIANCE 813.26.00B模拟量输入控制卡
有关如何连接控制器的信息以及其他类型的设备，请参阅屏幕编辑软件的相应设备驱动程序手册。串行端口未隔离。SG（信号接地）和FG（机架接地）端子连接在面板内。串行接口COM2 HMIGTO3510/HMIGTO4310:通过RS-485电缆的RJ45连接器。注：设置RS-485通信时，某些设备的电缆图可能需要在终端侧极化。该终端不需要任何特殊设置，因为它可以自动处理极化。安装在实心面板中的HMIGTO的正面已经使用与规范中所示标准等效的条件进行了测试。尽管HMIGTO的阻力水平与这些标准相当，但对HMIGTO没有影响的油可能会损害面板。这可能发生在存在汽化油的区域，或允许低粘度切削油长时间粘附在面板上的区域。如果面板正面保护板脱落，这些情况可能导致油进入面板，建议采取单独的保护措施。此外，如果存在未经批准的机油，它们可能会导致前面板塑料罩变形或腐蚀。因此，在安装HMIGTO之前，确保确认面板操作环境中存在的条件类型。如果长期使用安装垫片，或者从面板上拆下HMIGTO及其垫片，则无法保持原有的防护等级。为了保持原有的保护水平，请确保定期更换安装垫片*2在面板中安装HMIGTO时，可能无法将HMIGTO与面板平齐安装。这是由于垫片的厚度造成的。HMIGTO和面板之间的液位差取决于垫片被压缩的程度。HMIGTO5315的电路板上有保形涂层。
尺寸公差
所有+1/-0 mm（+0.04/-0 in）和R（角度）均低于R3（R0.12 in）*4即使安装壁厚在“面板切割尺寸”的建议范围内，取决于壁的材料、尺寸和面板和其他设备的安装位置，安装壁也可能翘曲。为了防止翘曲，可能需要加强安装表面。根据面板的工作温度和使用年限，时钟可以从-380秒/月偏离到+90秒/月。对于这种精度水平不足的系统，用户应进行监控，并在需要时进行调整。有关如何连接控制器和其他类型设备的信息，请参阅屏幕编辑软件的相应设备驱动程序手册。串行端口未隔离。SG（信号接地）和FG（机架接地）端子连接在面板内电击当使用SG端子将外部设备连接到面板时： 设置系统时，请确认没有创建短路回路。 当主机（PLC）单元未隔离时，将#5 SG终端连接到远程设备。将#5 SG端子连接至已知可靠的接地连接，以降低损坏电路的风险。不遵守这些说明将导致死亡或重伤。失去通信 通信端口的所有连接不得对端口施加过大压力。 将通信电缆牢固地连接到面板壁或机柜上。 只能使用状态良好的带锁片的D-Sub 9针电缆。
For information on how to connect controllers
and other types of equipment, refer to the corresponding device driver manual of your screen editing software. The serial port is not isolated. The SG (signal ground) and FG (frame ground) terminals are connected inside the panel. Serial Interface COM2 HMIGTO3510 / HMIGTO4310: RJ45 connector via an RS-485 cable. NOTE: When setting up RS-485 communication, the cable diagram for some equipment may require polarization on the terminal side. This terminal does not require any special setting as it handles polarization automatically.The front face of the HMIGTO, installed in a solid panel, has been tested using conditions equivalent to the standards shown in the specification. Even though the HMIGTO's level of resistance is equivalent to these standards, oils that should have no effect on the HMIGTO can possibly harm the panel. This can occur in areas where either vaporized oils are present, or where low viscosity cutting oils are allowed to adhere to the panel for long periods of time. If the panel's front face protection sheet peels off, these conditions can lead to the ingress of oil into the panel and separate protection measures are suggested. Also, if non-approved oils are present, they may cause deformation or corrosion of the front panel's plastic cover. Therefore, prior to installing the HMIGTO, be sure to confirm the type of conditions that will be present in the panel' operating environment. If the installation gasket is used for a long period of time, or if the HMIGTO and its gasket are removed from the panel, the original level of protection cannot be kept. To maintain the original protection level, be sure to replace the installation gasket regularly. *2 When installing the HMIGTO in a panel, you may not be able to mount the HMIGTO flush with the panel. This occurs due to the thickness of the gasket. The difference in level between the HMIGTO and panel depends on how much the gasket is compressed. There is a conformal coating on circuit boards for HMIGTO5315.
For dimensional tolerance
everything +1/-0 mm (+0.04/-0 in), and R in angle are below R3 (R0.12 in) *4 Even if the installation wall thickness is within the recommended range for the “Panel Cut Dimensions”, depending on wall’s material, size, and installation location of the panel and other devices, the installation wall could warp. To prevent warping, the installation surface may need to be strengthened.Depending on the operating temperature and age of panel, the clock can deviate from -380 to +90 sec/month. For systems where this level of precision is insufficient, the user should monitor and make adjustments when required.For information on how to connect controllers and other types of equipment, refer to the corresponding device driver manual of your screen editing software. The serial port is not isolated. The SG (signal ground) and FG (frame ground) terminals are connected inside the panel ELECTRIC SHOCK When using the SG terminal to connect an external device to the panel: Verify that a short-circuit loop is not created when you set up the system. Connect the #5 SG terminal to remote equipment when the host (PLC) unit is not isolated. Connect the #5 SG terminal to a known reliable ground connection to reduce the risk of damaging the circuit. Failure to follow these instructions will result in death or serious injury.LOSS OF COMMUNICATION All connections to the communication ports must not put excessive stress on the ports. Securely attach communication cables to the panel wall or cabinet. Use only D-Sub 9 pin cables with a locking tab in good condition.
产品优势
1：国外专业的供货渠道，具有价格优势
2：产品质量保证，让您售后无忧
3：全国快递包邮
4：一对一服务
公司主营范围简介
PLC可编程控制器模块，DCS卡件，ESD系统卡件，振动监测系统卡件，汽轮机控制系统模块，燃气发电机备件等，优势品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各种进口工业零部件、欧美进口模块。
产品广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、塑胶机械、电力、水利、水处理/环保、锅炉供暖、能源、输配电等等
