PM864AK01 3BSE018161R1控制处理器

PM864AK01 3BSE018161R1控制处理器

产品内容介绍PM864AK01 3BSE018161R1控制处理器B872-100 4通道模拟(D/A)输出模块转换数字数据范围从0000到4095,电流范围从4到20 mA(12位分辨率)。该模块设计为允许您控制每个输出通道的状态当可编程控制器复位或停止时。通道的输出可以保持最后一个值(HOLD)或转到0.0 mA(返回默认值:零:RTZ)。您可以使用四个位置为四个隔离输出中的每一个选择此选项D...

  • 功能特性
  • 参数规格
  • 视频
  • 应用案例
  • 下载

PM864AK01 3BSE018161R1控制处理器

    产品内容介绍

    PM864AK01 3BSE018161R1控制处理器

    B872-100 4通道模拟(D/A)输出模块转换数字数据

    范围从0000到4095,电流范围从4到20 mA(12位分辨率)。该模块设计为允许您控制每个输出通道的状态当可编程控制器复位或停止时。

    通道的输出可以保持最后一个值(HOLD)或转到0.0 mA(返回默认值:零:RTZ)。

    您可以使用四个位置为四个隔离输出中的每一个选择此选项DIP开关。开关与每个输出关联(开关1用于输出1,等等)。

    这个HOLD或RTZ功能由您选择,以满足您的特定应用。

    RTZ功能允许您将输出归零作为一项安全功能。

    HOLD公司函数允许您在OURBUS丢失后保持最后一个有效输出值表达该模块有四个独立的模拟输出,并且能够更新所有四个通道每1毫秒。12位分辨率和绝对精度为+/-0.1%25°C可精确控制您的应用。

    下图显示了B872-100模块的简化示意图。B872接受0000到4095之间的数据值并将其转换输出电流为4至20 mA。输出电流与数据值加上4 mA。有关要输出的数据值,请参阅下图转换图表。

    交换机位置和位置四位DIP开关位于模块后部。此开关控制系统复位或停止时每个通道的状态。

    输出通道可以保持最后一个值(保持)或转到0.0 mA归零(RTZ)。

    在安装模块之前,将开关设置为保持或RTZ。

    每个四个开关控制其相关输出的操作模式(即开关1输出1等)。

    开关设置下图显示了B872-100模块的DIP开关设置。

    而且请参阅模块左侧的标签。模拟输出模块在出厂前进行校准。

    为了确保为了保证模块的精度,您应该定期校准每个输出的微调罐。

    对于25-45°C之间的操作,建议每隔12个月进行一次校准以及0-60°C之间的6个月间隔。

    校准模拟输出模块需要以下工具:

    1) 编程面板

    2) 精密电压表,精度为+/-0.0001伏,10伏刻度

    3) 一把1/4英寸十字螺丝刀

    4) 一把1/8英寸标准螺丝刀

    The B872-100 4-Channel Analog (D/A) Output Module

    converts numerical data ranging from 0000 to 4095 into current ranging from 4 to 20 mA (12-bit resolution). The module is designed to allow you to control the state of each output channel when the programmable controller is reset or stopped. The output of the channel can either remain at the last value (HOLD) or go to 0.0 mA (return to default: zero: RTZ). You can select this option for each of the four isolated outputs using a four-position DIP switch. A switch is associated with each output (switch 1 for output 1, etc.). The HOLD or RTZ function is selected by you to meet your specific application. The RTZ function allows you to bring the outputs to zero as a safety feature. The HOLD function allows you to maintain the last valid output value after the loss of OURBUS communication. The module has four isolated analog outputs, and is capable of updates to all four channels every 1 mS. The 12-bit resolution and the absolute accuracy of +/-0.1% at 25 °C provides precise control of your application. The following figure shows the simplified schematic of the B872-100 module.The B872 accepts data values ranging from 0000 to 4095 and converts them into output currents of 4 to 20 mA. The output current is directly proportional to the data value plus 4 mA. Refer to the figure below for a data value to output conversion chart.

    Switch location and position

    The four position DIP-switch is located on the rear of the module. This switch controls the state of each channel when the system is reset or stopped. The output to the channel can either remain at the last value (Hold) or go to 0.0 mA Return-ToZero (RTZ). Set the switch for either hold or RTZ prior to installation of the module. Each of the four switches control the mode of operation for its associated output (i.e., switch 1 for output 1, etc.). Switch Settings The following figure presents DIP switch settings for the B872-100 module. Also, refer to the label located on the left side of the module itself.The Analog Output module is calibrated at the factory prior to shipment. To ensure the module's accuracy you should calibrate the trim-pots for each output regularly. Calibration is recommended at 12 month intervals for operation between 25-45 °C and at 6 month intervals between 0-60 °C.
