公司主营产品图展示
产品优势
1：国外专业的供货渠道，具有价格优势
2：产品质量保证，让您售后无忧
3：全国快递包邮
4：一对一服务
公司主营产品文字介绍
PLC可编程控制器模块，DCS卡件，ESD系统卡件，振动监测系统卡件，汽轮机控制系统模块，燃气发电机备件等，优势品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各种进口工业零部件、欧美进口模块。
产品广泛应用于冶金、石油天然气、玻璃制造业、铝业、石油化工、煤矿、造纸印刷、纺织印染、机械、电子制造、汽车制造、塑胶机械、电力、水利、水处理/环保、锅炉供暖、能源、输配电等等
产品详情内容介绍
C4C11CENELEC控制输入模拟量驱动器
一般特征B802–008 115 Vac输出模块转换PLC内使用的逻辑信号八个独立的115 Vac输出。每个输出都能够驱动一个继电器，指示灯、电机起动器、电磁阀或任何其他负载高达2.0 A。
B802–008能够处理12 a的总持续电流。模块使用双向可控硅开关控制连接到外部电源的负载。这些开关设计用于承受典型的工业高浪涌电流荷载。
简化示意图模块的八个输出分为四组，每组两个输出。一LED指示灯在输出打开时亮起。
以下是B802–008 115 Vac输出模块的简化示意图。
用户连接到标准螺钉端子排。刚性接线系统允许在不干扰接线的情况下插入或移除模块。
端子编号和输出连接下图显示了终端编号和输出连接B802–008模块。B803–008 115 Vac输入模块检测并转换开关输入信号将PLC使用的逻辑电压电平转换为8个独立的115 Vac输出。
这个该模块允许多达八个独立感应输入。
这些输入可以是从按钮、限位开关和接近开关以及其他115 Vac接收来源。
现场连接用户连接到标准螺钉端子排。刚性接线系统允许在不干扰接线的情况下插入或移除模块。
端子编号和输入连接下图显示了终端编号和输入连接B803–008模块。一般特征B804–116 115 Vac输出模块将PLC中使用的逻辑信号转换为16个独立115 Vac输出。每个输出都能够驱动继电器、导向器灯、电机起动器、螺线管或任何其他负载高达2.0 A。
B804–116能够处理6 a/8组的总持续电流点和12 A/模块。模块使用双向可控硅开关控制连接的负载外部电源。这些开关设计用于承受典型的工业负荷浪涌电流。
简化示意图以下是B804–116 115 Vac输出模块的简化示意图。用户连接到标准螺钉端子排。刚性接线系统允许在不干扰接线的情况下插入或移除模块。
端子编号和输出连接下图显示了终端编号和输出连接B804-116模块。
General Characteristics
The B802–008 115 Vac output module converts logic signals used within the PLC into eight independent 115 Vac outputs. Each output is capable of driving a relay, pilot lamp, motor starter, solenoid, or any other load up to 2.0 A. The B802–008 is capable of handling a total continuous current of 12 A. The module uses triac switches to control loads connected to an external power source. These switches are designed to withstand the high surge currents typical of industrial loads. Simplified Schematic The module’s eight outputs are separated into four groups of two outputs each. An LED indicator lights when an output is on. Following is a simplified schematic of the B802–008 115 Vac output module.User connections are made to a standard screw terminal strip.The rigid wiring system permits module insertion or removal without disturbing the wiring. Terminal Numbering and Output Connections The following diagram shows terminal numbering and output connections for the the B802–008 module.The B803–008 115 Vac input module senses and converts switched input signals into logic voltage levels used by the PLC into 8 independent 115 Vac outputs. The module allows for up to eight independently sensed inputs. These inputs can be received from push buttons, limit and proximity switches, as well as other 115 Vac sources.
Field Connections
User connections are made to a standard screw terminal strip.The rigid wiring system permits module insertion or removal without disturbing the wiring. Terminal Numbering and Input Connections The following diagram shows terminal numbering and input connections for the B803–008 module.
General Characteristics The B804–116 115 Vacoutput module converts logic signals used in the PLC into 16 independent 115 Vac outputs. Each output is capable of driving a relay, pilot lamp, motor starter, solenoid, or any other load up to 2.0 A. The B804–116 is capable of handling a total continuous current of 6 A/group of eight points and 12 A/module. The module uses triac switches to control loads connected to an external power source. These switches are designed to withstand the high surge currents typical of industrial loads. Simplified Schematic Following is a simplified schematic of the B804–116 115 Vac output module.
User connections are made to a standard screw terminal strip.The rigid wiring system permits module insertion or removal without disturbing the wiring. Terminal Numbering and Output Connections The following diagram shows terminal numbering and output connections for the the B804-116 module.
