REF615C_E触摸显示面板
ABB的DCS 400变频器提供了这种可能性通过参数编程通过交互式对话进行指导调试。
可以保证驱动器设置正确并且被优化。
本节介绍了指导调试与面板一起。必要的对话，也小组命令序列使用名为的向导
如下所示。参数条目
指导调试程序期间所需的输入分为选择参数以及值参数。
从预定义的文本列表中选择并确认选择参数。
控制面板显示仅显示其中一行一次一个文本列表。因此，列表必须滚动一行一行，使用键。确认选择后，按（17（5）。第1行：参数编号和参数名称。
第2行：文本列表中当前选定的行。
在调试说明中
文本列表以灰色阴影背景显示。
使用键选择所需的行。
按（17（5）确认您的选择。
是/否决策的处理方式与参数的选择
值参数是带有数值的参数内容，其值可以通过按键递增或递减。每一键将增加或减少所选参数由1。
按下其中一个键将导致相关参数值增加或减少迅速地按下（17（5）确认所需值。
第1行：参数编号和参数名称。
第2行：参数值。
在指导调试过程中，所有可更改的值都显示为强调使用键更改值
并按（17（5）确认输入您将进入调试程序的下一步。
中断指导调试程序按0（18）可中断指导调试程序。有三种可能性：用于继续该过程的选择。
返回上一调试步骤。
继续执行相同步骤。
退出由委员会程序指导。
按确认您的选择。在引导调试期间，意外故障可以轻松排除。发现在以下各章中，阐述了原因和采取的措施。对于故障、警报和诊断消息，参见第6.4章故障排除。
The DCS 400 converters of ABB offer the possibility
to have a guided commissioning by means of interactive dialogue through the parameter programming.
One guarantees with it, that the drive is set up right
and is optimized.
This section describes the guided commissioning
with the panel. The necessary dialogue, also Panel
Wizard named, is used by the command sequence
shown below.Parameter entries
The entries required during the guided commissioning procedure are divided into selection parameters
and value parameters.
Selection parameters are selected from a predefined text list and confirmed.
The control panel display only shows one line of this
text list at a time. Therefore, the list must be scrolled
line by line, using the keys. To confirm a
selection, press (17(5 .
Line 1: Parameter number and parameter name.
Line 2: Line currently selected in the text list.
In the commissioning instructions, alternative lines of
a text list are displayed against a grey-shaded background.
Select the desired line using the keys.
Confirm your selection by pressing (17(5 .
Yes/No decisions are treated in the same manner as
selection parameters.
Value parameters are parameters with numerical
contents, whose values can be incremented or decremented by pressing the keys. Each key stroke
will increment or decrement the selected parameter
by 1.
Holding down one of these keys will cause the parameter value concerned to be increased or decreased
rapidly.
Confirm the desired values by pressing (17(5 .
Line 1: Parameter number and parameter name.
Line 2: Parameter value.
During the guided commissioning procedure, all values which can be changed are displayed with an
underline. Use the keys to change the values
and confirm the entry by pressing (17(5 . This will take
you to the next step of the commissioning procedure.
Interrupting the guided commissioning procedure
The guided commissioning procedure can be interrupted by pressing 0(18 . There are three posibilities for
selection for going on the process.
Back to the previous commissioning step.
Continue with the same step.
Exit guided commission procedure.
Confirm your selection by pressing Unexpected trouble during guided commissioning can be eliminated easily. Find
in the following chapters the reason and carry out the measures described there.
For faults, alarms and diagnosis messages,
see chapter 6.4 Troubleshooting.
