Determining the distance zones
Before it is possible to determine the reaches of the distance
zones, the impedances and phase-angles of the line sections
during faults must be known. Typical settings for the various
zone reaches along the line are given below:Typical settings for the reaches of distance relay
zones (grading table)Calculating the secondary line impedances
The primary values calculated from the grading table for the line
impedances have to be converted to secondary values. These
are obtained by applying the following relationship:primary positive-sequence line impedanceThe impedance characteristic is defined independently for each
of the four distance zones (Zone 4 is used alternatively for the
overreaching zone) by the following parameters (i = 1 to 4):The reactance and resistance of the line or cable are set in the
proper units using the parameters ‘R’ and ‘X’ (see Fig. 3.5.31.4).At a rated current of 1 or 2 A, the impedance parameters ‘X’, ‘R’,
‘RR’ and ‘RRE’ have setting ranges of -300 to +300 /ph in
steps of 0.01 (-30 to +30 /ph in steps of 0.001 for a rated current of 5 A).
A zone is disabled when ‘X’ is set to zero regardless of the settings of the other parameters. In this case, the other zones are
also blocked with the exception of the last one. Zone 1 can only
be disabled by the parameter ‘Block Z1’ or the binary input
‘ExtBlock Z1’.
The direction of measurement is reversed for negative values of
‘X’, ‘R’, ‘RR’ and ‘RRE’.Provision is made with parameters ‘RRE’ and ‘RR’ for allowing
for the fault resistance in an E/F loop and in a phase-to-phase
loop. The setting takes the E/F resistance comprising the resistance of the arc and the pylon footing resistance in relation to
the line resistance into account.Since the unit is /ph, the fault resistance appears differently in
the impedance plane according to the type of fault. Where the
value of the fault resistance RF is known in (see Fig. 3.5.31.5),
it has to be entered in the R/X diagram as follows:
E/F: R=RF/(1+k0)
phase-to-phase fault: R=RF/2
three-phase fault: R=RF/ 3 .
It is for this reason that fault resistance is compensated separately for E/F and phase-to-phase loops using the parameters
‘RRE’ and ‘RR’. The parameter ‘RR’ will generally be set lower
than ‘RRE’, because the phase-to-phase fault resistance is normally very low.The load area defined by the underimpedance parameters
‘RLoad’ and ‘AngleLoad’ is taken into account be starting and
measuring characteristics. It follows from this that the relay can
only trip, if the fault impedance measured lies within the
underimpedance starting characteristic.
