BENTLY 125840-02监测器模块
•脉冲发生器旋钮-旋转脉冲发生器以改变数字显示中的值（例如，设定点、阀门或其他配置用于正常操作员显示变化（例如比率、偏差）的变量。脉冲发生器旋钮也用于：配置以更改字母数字显示中的值。
包括加速器。将旋钮旋转得越快，显示参数的变化率越大。较大的值变化则需要较少的旋钮旋转。
•V条形图-该水平条形图显示有源回路中控制器输出的缩放范围。这个
输出/阀门信号显示为量程值的%。工程单位的数值可通过以下方式查看：
按下D按钮以显示点V参数（例如TC2053.V）。9.2配置模式配置按钮位于面板下四分之一的翻转门后面。注意其中许多按钮用于正常操作模式和配置模式，如下所述。
•进入/退出配置-当工作站处于在正常操作模式下，或在配置模式。
•报警/降压-具有双重用途。
在正常情况下操作模式下，按下按钮将滚动浏览报警
配置参数（如果报警功能块已在有源环路中配置。报警设置显示在中工程单位和范围值的百分比也将显示在
通过闪烁等于范围%的单个段，设定点条形图价值如果满足安全许可，参数也可以是改变。有关的详细信息，请参见报警功能块说明参数。按ENTER/EXIT CONFIG（进入/退出配置）按钮返回联机显示。在配置模式下，此按钮将跳转到下一个配置级别。请参阅本节的配置概述部分
有关配置模式典型级别的详细信息，请参阅手册。
•调谐/升压-具有双重目的。正常运行时模式下，按下按钮将滚动控制器调谐
参数并允许激活自动调谐算法，如果为环路控制器配置。如果满足安全许可，则参数也可以改变。按下进入/退出配置按钮以返回到联机显示。
当处于配置模式时，此按钮将升级到下一个配置级别。
•标签/<----具有双重用途。在正常操作模式下，按下按钮将滚动
字母数字显示中活动循环的完整标记名。标签将一次滚动一个字符
从右侧开始（例如-------T，--TI，--TIC）。
• Pulser Knob - rotate the Pulser to change the value in the numeric display (e.g. Setpoint, Valve, or other
variable configured for normal operator display changes such as Ratio, Bias). The Pulser knob is also used in
configuration to change values in the alphanumeric display.
An accelerator is included. Turning the knob faster multiplies the rate of change of the displayed parameter.
Large value changes then require fewer knob rotations.
• V Bargraph - this horizontal bargraph displays the scaled range of the controller output in the Active Loop. The
output/valve signal is shown as the % of range value. The value in engineering units can be viewed by
pressing the D button to display the dot V parameter (e.g. TC2053.V). 9.2 CONFIGURATION MODE
Configuration pushbuttons are located behind the flip-down door on the lower quarter of the faceplate. Note that
many of these buttons are used in both the normal operation mode and configuration mode, as described below.
• ENTER/EXIT CONF - press to enter configuration when the station is
in the normal operation mode or to exit configuration when in the
configuration mode.
• ALARM/STEP DOWN - has a dual purpose. When in the normal
operation mode, pressing the button will scroll through the alarm
configuration parameters if the ALARM function block has been
configured in the Active Loop. The alarm setting is displayed in
engineering units and the % of range value will also be displayed on the
setpoint bargraph by flashing a single segment equal to the % of range
value. If security clearance is satisfied, the parameters can also be
changed. See the ALARM function block description for details on the
parameters. Press the ENTER/EXIT CONFIG button to return to the online displays.
When in the configuration mode, this button will step down to the next
configuration level. See the Configuration Overview section of this
manual for details on typical levels of the configuration mode.
• TUNE/STEP UP - has a dual purpose. When in the normal operation
mode, pressing the button will scroll through the controller tuning
parameters and allow activating the AUTOTUNE algorithm, if
configured for the loop controller. If security clearance is satisfied, the
parameters can also be changed. Press the ENTER/EXIT CONFIG button
to return to the on-line displays.
When in the configuration mode, this button will step up to the next configuration level.
• TAG/<--- - has a dual purpose. When in the normal operation mode, pressing the button will scroll the
complete tag name of the Active Loop in the alphanumeric display. The tag will scroll one character at a time
starting on the right (e.g. -------T, -----TI, ----TIC).
