Input H will hold the remaining time of the current step and disable advancing of the sequencer by operations 5 and
6 but will allow operations 1, 2, 3, and 4 to move the sequencer to the starting position of a new step.
When the last sequencer step is completed, SC will be set high (1). The sequencer cannot be moved past the last
step unless the reset input R goes high (1) forcing it to position 1. The sequencer can be moved forward only when in position 1. Network communications will allow the sequencer to be moved to a new step and the remaining time
of the current step to be changed to a new value.
When discrete groups are used and a step is desired as ‘timed only’, one discrete input should be used to prevent the
input mask from moving the sequencer to the next step. This can be accomplished by requiring a high (1) input and
then not connecting that input, since unconnected inputs will be treated as 0.
When discrete groups are used and a step is desired as ‘event only’, the TIMe parameter for the step should be set to
0.0. The Analog Output will remain at the AEP value of the previous step or, if at step 1, the Analog value will be
0.0. When the sequencer advances to the next step, the Analog Output will go to the AEP value for the completed
step.
POWER UP - During a warm start, if PU LAST is set to YES, all outputs, step number, track variable, and
remaining step time will be initialized at the last values prior to power fail. During a cold start all outputs are
initialized to 0 and the PRSEQ is in a reset condition. QHD_ function blocks enable a real value to be changed
on-line using the QUICKSET feature. The block is
identified by an 8-character name that will be displayed in
the QUICKSET mode. The block is configured with a
range entered as MIN SCALE and MAX SCALE to set a
usable range, and a Decimal Point Position parameter can
set the allowed precision. The hold value can not be
changed beyond the -10% to 110% value of these limits
and will change continuously as the pulser is turned. The
MAX value must always be set greater than the MIN value.
The block can also be forced to track input TV by asserting
input TC high (1). Firmware 1.30 added parameter QSCHANGE. It enables
the block output to either update continuously in the
Quickset mode as the pulser knob is turned or to only
update the output with the value in the numeric display
when the STORE button is pressed.
When configuring the DPP (Decimal Point Position) it is important to keep the resolution to the minimum necessary
for operation changes. It will take the operator longer turning the pulser if the resolution is too high. For example,
if only 0.1% changes are needed configure a 0-100 range as 0.0 – 100.0 and not 0.000 – 100.000.
During Hot or Warm start, the QHD will power-up in the last position during a Cold start at the -10% range value. RATIO function blocks can be used on a one per
loop basis. They provide a means of setting a ratio in
an external setpoint application, for example,
controlling a captive flow while maintaining the ratio
between a wild flow and the captive flow at the
desired value. Inputs A and E (external ratio) and the
operator set ratio R value are multiplied and become
the function block output O1.
