DS200DSPCH1ADA燃机输出模块
在冷启动或热启动期间，每个输入变量将通电在自动模式下向上。在热启动期间，模式和手动值将等于断电前的值。每个离散输入变量可以显示在本地使用D按钮的面板。当第一次踏入循环使用循环按钮，将显示循环标记（例如DigDisp1）。按下D按钮将滚动浏览显示点标签（如SV-103）的离散点左侧输入的字母数字和值。3数字显示器（如On）和输出的位置最右边的3个位置（例如关闭）。A/M按钮将显示点模式和启用使用A/M在自动和手动之间切换点按钮手动值可以通过转动脉冲发生器并按下确认按钮。如果确认按钮为如果在4-5秒内未按下，显示屏将返回实际输出值。3.2.67 ODP-按钮的操作员显示（V2.2）ODP功能块是以下五种操作员显示器之一：可在每个循环一次的基础上用于配置本地操作员显示功能以及网络参数。请参阅下一页的i|ware PC面板示例。ODP功能块最多可提供8组两个按钮和一个选择开关。每组包括：•一个常开按钮，标识为PB1，打开本地面板。它可以有一个6字符的标记识别HMI显示器上的按钮功能。•一个常闭按钮，标识为PB2 on本地面板。
它可以有一个6字符的标记在HMI上显示。
•一个两位选择器开关，标识为A/M on本地面板。它可以有一个6字符的标记HMI上的开关位置标识。每个组还具有一组6个字符的消息与反馈信号（1/0）的状态相关联。每个按钮都有一个配置参数，用于控制：按钮功能将在按下状态下保持多长时间位置默认值为1秒，但可以从0.1（或扫描时间，如果大于0.1）至10秒。LOOP#参数用于索引对的读写Modbus和LIL网络参数。当使用LIL时，还必须配置LIL CHAN参数。看见有关网络参数的更多信息，请参见第9节。视图OD参数设置为“是”时，启用操作员显示可在本地查看和访问。在案例中其中需要查看显示或操作参数仅来自网络工作站，参数应为设置为NO。
During a cold or warm start, each input variable will power
up in the auto mode. During a hot start, the mode and
manual value will equal the value prior to power down.
Each discrete input variable can be displayed on the local
faceplate using the D button. When first stepping into a
loop using the Loop button, the loop tag will be displayed
(e.g. DigDisp1). Pressing the D button will scroll through
the discrete points displaying the point tag (e.g. SV-103) in
the alphanumeric and the value of the input on the left 3
positions of the digital display (e.g. On) and the output in
the right most 3 positions (e.g. OFF).
The A/M button will display the point mode and enable
switching the point between auto & manual using the A/M
button. The manual value can be changed by turning the
pulser and pressing the ACK button. If the ACK button is
not pressed within 4-5 seconds, the display will return to the
actual output value. 3.2.67 ODP - Operator Display for PushButtons (V2.2)
ODP function blocks are one of five operator displays that
can be used on a one per loop basis to configure local
operator display functions as well as network parameters.
See the i|ware PC faceplate example on the next page.
The ODP function block can provide up to 8 groups of two
pushbuttons and one selector switch. Each group includes:
• One normally open pushbutton, identified as PB1, on
the local faceplate. It can have a 6-character tag to
identify the button function on a HMI display.
• One normally closed pushbutton, identified as PB2 on
the local faceplate. It can have a 6-character tag for
display on an HMI.
• One two-position selector switch identified as A/M on
the local faceplate. It can have a 6-character tag for
switch position identification on an HMI.
Each group also has a set of 6-character messages
associated with the status of a feedback signal (1/0).
Each pushbutton has a configuration parameter that controls
how long the button function will be held in the pressed
position. The default value is 1 second but can be set from
0.1 (or scan time if greater than 0.1) to 10 seconds.
The LOOP # parameter is used to index reads and writes to
Modbus and LIL network parameters. When using the LIL,
the LIL CHAN parameter must also be configured. See
Section 9 for more information on network parameters.
The VIEW OD parameter, when set to YES enables the
operator display to be viewed and accessed locally. In cases
where it is desired to view display or operation parameters
only from a network workstation, the parameter should be
set to NO.
