The function block can also provide a pulse output to drive a remote counter. The pulse output function integrates
the input signal using the same time base and output pulses at a rate determined by the PUL SCAL configuration
parameter. This parameter determines the change to the integrator total that must occur to cause a new output pulse.
In the above example, if PUL SCAL equals 10, a total of 30 pulses will have occurred in the same time period. The
PUL SCAL value is also the multiplier that would be used to read the exact value of gallons to a remote counter.
The pulse output function operates on the absolute value of the analog input. When both negative and positive
values are to be totalized, a CoMParator block can be used to sense the polarity of the analog input and the CMP
output can then indicate a direction to the counter.
Be sure that the PUL SCAL setting does not require a pulse rate output greater than the scan cycle time of the
controller under the maximum input conditions. Using the same example, if the maximum A input is 60.0 and the
cycle time is 0.1 sec, the maximum required pulse rate is 0.1/sec. The condition is satisfied since the maximum output requirement is less than the maximum pulse rate of 5/sec available with a 0.1 sec cycle time. The
requirement would also be satisfied if a PUL SCAL of 1 was selected which would have required a maximum pulse
rate of 1/sec.
POWER UP - During a warm start, if the configuration parameter PU LAST was set to YES, the integrator function
will initialize with the last value prior to power down and all outputs will be initialized to the last value prior to
power down. If set to NO, or during a cold start, the integrator and all outputs will initialize to 0.
Input EC allows the batch totalizer block to be used with another function block, such as the DINU that provides a
count signal. When input A is not configured it will be set to (0.0). The EC input is summed with the initial value
for use as the total. This value will now be displayed as the total on the operator faceplate and the presets will act
on this value to provide outputs A1 and A2. BATSW function blocks can be used on a one per loop
basis. Each is used with a PID function block to eliminate
overshoot during startup conditions. When placed in the
feedback path of the controller it causes the reset
component of the controller to be reduced (if controller
action is Rev). Without the use of a batch switch during
startup, the controller output (O1 = GE + R) will equal
full output since the reset will wind up. This requires the
process to overshoot the setpoint in order to bring the
controller output back down. With a batch switch in the
feedback path, a lower reset value will be present when
crossover occurs, thus reducing or eliminating overshoot.
