BENTLY 149992-01位移监测器
产品支持可从客户服务中心（即北美的技术支持小组或
亚洲或欧洲的技术信息中心（TIC）。每个地区都有一个客户服务中心，提供：
就与产品功能、应用和集成相关的技术问题提供直接电话支持。
区域联系信息如下。您的区域技术支持小组或TIC是第一个：
寻求产品支持信息时请致电。打电话时，准备好以下信息很有帮助：
•产品零件号或型号和版本
•如果产品操作有问题：
-故障是否为间歇性故障
-问题发生前执行的步骤
-显示任何状态消息、错误消息或LED指示
-安装环境、设备交付和搬运
1.4.1工厂装运
装运前，对控制器进行全面测试和检查，以确保其正常运行。然后将其包装为：
运输大多数配件单独装运。
1.4.2货物的接收
在交付时检查每个纸箱是否存在可能的外部损坏。任何可见的损坏应立即修复记录在承运人的交货单副本上。
仔细打开每个纸箱的包装，并对照随附的装箱单检查内容。检查每个项目是否存在任何
可能或可能未伴随外部纸箱损坏的隐藏损坏。
如果发现某些项目已损坏或丢失，通知工艺仪表部门
西门子能源和自动化立即提供详细信息。此外，必须向承运人要求对受损物品及其装运纸箱进行现场检查。
1.4.3储存
如果控制器要在安装前储存一段时间，请查看第14节中的环境规范型号名称和规格。
装运时，MPU控制器板实时时钟跳线（W7或W8）设置为最大限度延长电池寿命。如果跳线已设置为启用热/热启动，或确认跳线设置正确，请参阅第11节
维护并将跳线设置为存储。典型装运内容
下面列出的项目通常包括在装运中，可能会发生变化。
1.摩尔353过程自动化控制器，每个订单的型号，数量。1.
2.功率输入和量程电阻器套件，PN 16354-30，数量。1.
描述数量
电阻器，250Ω, 0.1%，3W，WW3套管3
接头6上的压接
套件安装说明1
3.安装夹套件，无零件号，数量。1.
内容：2个安装夹和2个8-32 x 1螺钉（零件号见本手册后面的零件清单）
4.I/O扩展器板套件
PN16353-52 I/O扩展器板套件-当摩尔353与已订购扩展板选项1。
PRODUCT SUPPORT
Product support can be obtained from a customer service center (i.e. Technical Support Group in North America or
a Technical Information Center (TIC) in Asia or Europe). Each region has a customer service center that provides
direct telephone support on technical issues related to the functionality, application, and integration of the product.
Regional contact information is provided below. Your regional Technical Support Group or TIC is the first place to
call when seeking product support information. When calling, it is helpful to have the following information ready:
• Product part number or model number and version
• If there is a problem with product operation:
- Whether or not the problem is intermittent
- The steps performed before the problem occurred
- Any status message, error messages, or LED indications displayed
- Installation environment EQUIPMENT DELIVERY AND HANDLING
1.4.1 Factory Shipment
Prior to shipment, a controller is fully tested and inspected to ensure proper operation. It is then packaged for
shipment. Most accessories are shipped separately.
1.4.2 Receipt of Shipment
Inspect each carton at the time of delivery for possible external damage. Any visible damage should be immediately
recorded on the carrier’s copy of the delivery slip.
Carefully unpack each carton and check the contents against the enclosed packing list. Inspect each item for any
hidden damage that may or may not have been accompanied by exterior carton damage.
If it is found that some items have been damaged or are missing, notify the Process Instrumentation Division of
Siemens Energy and Automation immediately and provide full details. In addition, damages must be reported to the
carrier with a request for their on-site inspection of the damaged item and its shipping carton.
1.4.3 Storage
If a controller is to be stored for a period prior to installation, review the environmental specifications in Section 14
Model Designation and Specifications.
As shipped, the MPU Controller board Real Time Clock Jumper (W7 or W8) is set to maximize battery life. If the
jumper has been set to enable Hot/Warm Start, or to confirm that the jumper is properly set, refer to Section 11
Maintenance and set the jumper for storage. Typical Shipment Contents
The items listed below are those typically included in a shipment and are subject to change.
1. Moore 353 Process Automation Controller, model number per order, qty. 1
2. Power Input and Range Resistor Kit, PN 16354-30, qty. 1
DESCRIPTION QUANTITY
Resistor, 250Ω, 0.1%, 3W, WW 3
Sleeving 3
Crimp-On Connector 6
Kit Installation Instruction 1
3. Mounting Clip Kit, no part number, qty. 1
Contents: 2 Mounting Clips and 2, 8-32 x 1 Screws (see the Parts List at back of this manual for part numbers)
4. I/O Expander Board Kits
PN16353-52 I/O Expander Board Kit - The I/O Expander Board is factory installed when a Moore 353 with
Expansion Board option 1 is ordered.
