AEG MODICON AS-B809-016输入模块 PDF资料
1.产 品 资 料 介 绍：
AEG MODICON AS-B809-016 输入模块
这是一款用于 Modicon 800 系列可编程控制系统的数字量输入模块，负责将现场开关、传感器等输入信号传递给控制器，实现工业自动化系统的信号采集与处理。
产品特点：
输入通道丰富：提供 16 点数字量输入，可采集开关量信号、干接点或继电器触点信号。
电气隔离：每一路输入均具备光电隔离，增强系统抗干扰能力，提高安全性。
状态指示：模块前面板配有 LED 指示灯，可实时显示各输入通道的工作状态，方便故障检测与维护。
模块化设计：插拔式结构，方便安装、更换及系统扩展。
高可靠性：工业级设计，适应高温、湿度及电磁干扰环境下的长期稳定运行。
通信兼容性：与 Modicon 主控 CPU 模块及总线系统完全兼容，支持高速数据交换。
技术参数概要：
型号：AS-B809-016
输入点数：16 点数字量输入
输入电压：DC 24V（典型）
电气隔离：光电隔离设计
状态指示：每点 LED 状态灯
安装方式：插入式模块，适配 800 系列机架
工作温度：0～60℃
储存温度：–40～85℃
AEG MODICON AS-B809-016输入模块 英文介绍
AEG MODICON AS-B809-016 Input Module
This is a digital input module for Modicon 800 series programmable control systems, responsible for transmitting input signals from field switches, sensors, etc. to the controller to achieve signal acquisition and processing in industrial automation systems.
Product Features:
Rich input channels: Provides 16 point digital input, which can collect switch signals, dry contact or relay contact signals.
Electrical isolation: Each input has photoelectric isolation, enhancing the system's anti-interference ability and improving safety.
Status indication: The module front panel is equipped with LED indicator lights, which can display the working status of each input channel in real time, facilitating fault detection and maintenance.
Modular design: Plug in structure, convenient for installation, replacement, and system expansion.
High reliability: Industrial grade design, suitable for long-term stable operation in high temperature, humidity, and electromagnetic interference environments.
Communication compatibility: Fully compatible with Modicon main control CPU module and bus system, supporting high-speed data exchange.
Technical parameter summary:
Model: AS-B809-016
Input points: 16 numerical input points
Input voltage: DC 24V (typical)
Electrical isolation: optoelectronic isolation design
Status indicator: LED status light at each point
Installation method: Plug in module, compatible with 800 series rack
Working temperature: 0-60 ℃
Storage temperature: -40~85 ℃
AEG MODICON AS-B809-016输入模块 产品展示
