AEG MODICON D984-385（984-385D）可编程控制器 PDF资料
1.产 品 资 料 介 绍：
AEG MODICON D984-385（984-385D）可编程控制器
这是一款属于 Modicon 984 系列的可编程逻辑控制器（PLC），用于工业自动化系统的逻辑运算、信号采集与过程控制。该系列以高可靠性和模块化设计著称，广泛应用于制造业、能源、电力、化工及过程控制领域。
产品特点：
高性能处理能力：具备较快的逻辑扫描速度，可高效执行复杂控制任务。
模块化结构：可与 800 系列机架及 I/O 模块组合使用，方便扩展与维护。
通信功能完善：内置 Modbus 或 Modbus Plus 通信接口，可实现远程监控与编程。
多电源兼容：支持 AC 115V/230V 或 DC 125V 电源输入（具体依版本而定）。
状态监控直观：面板上设有多组指示灯，如电源状态、运行状态、通信状态及电池报警等。
内存容量适中：逻辑程序存储容量约 16K 字，用户状态内存约 2K 字，可满足中大型控制系统需求。
稳定性与抗干扰性强：适应工业环境下的高温、湿度及电磁干扰条件。
技术参数概要：
型号：D984-385 / 984-385D
控制类型：可编程逻辑控制器（CPU 模块）
程序存储容量：约 16K 字
用户状态 RAM：约 2K 字
最大 I/O 点数：512 点离散 I/O
通信方式：Modbus / Modbus Plus
电源输入：AC 115V / 230V 或 DC 125V
扫描速度：约 0.75–5 毫秒/千逻辑节点
状态显示：PWR OK、RUN、READY、COMM、BATTERY LOW 等
安装方式：兼容 Modicon 800 系列机架
AEG MODICON D984-385（984-385D）可编程控制器 英文介绍
AEG MODICON D984-385 (984-385D) Programmable Controller
This is a programmable logic controller (PLC) belonging to the Modicon 984 series, used for logic operations, signal acquisition, and process control in industrial automation systems. This series is known for its high reliability and modular design, and is widely used in manufacturing, energy, power, chemical, and process control fields.
Product Features:
High performance processing capability: With fast logical scanning speed, it can efficiently execute complex control tasks.
Modular structure: Can be combined with 800 series racks and I/O modules for easy expansion and maintenance.
Complete communication function: Built in Modbus or Modbus Plus communication interface, capable of remote monitoring and programming.
Multi power compatibility: Supports AC 115V/230V or DC 125V power input (depending on the version).
Intuitive status monitoring: The panel is equipped with multiple sets of indicator lights, such as power status, operating status, communication status, and battery alarm.
Moderate memory capacity: The logical program storage capacity is about 16K words, and the user state memory is about 2K words, which can meet the needs of medium and large control systems.
Strong stability and anti-interference ability: suitable for high temperature, humidity, and electromagnetic interference conditions in industrial environments.
Technical parameter summary:
Model: D984-385/984-385D
Control type: Programmable Logic Controller (CPU module)
Program storage capacity: approximately 16K words
User Status RAM: Approximately 2K words
Maximum I/O points: 512 discrete I/O points
Communication method: Modbus/Modbus Plus
Power input: AC 115V/230V or DC 125V
Scanning speed: approximately 0.75-5 milliseconds per thousand logical nodes
Status display: PWR OK, RUN, READY, COMM, BATTERY LOW, etc
Installation method: Compatible with Modicon 800 series rack
AEG MODICON D984-385（984-385D）可编程控制器 产品展示
