AEG MODICON ASP890300通信模块 PDF资料
1.产 品 资 料 介 绍：
AEG MODICON ASP890300 通信模块
这是一款用于 Modicon 800 系列系统的远程 I/O 通信模块，属于高性能数据传输与接口单元，能够在主控制器与远程 I/O 机架之间实现高速稳定的通信。
产品特点：
远程通信能力强：采用同轴电缆通信方式，支持长距离数据传输，通信速率约为 1.544 MHz。
高速数据处理：I/O 扫描速度快，在 256 点输入输出条件下响应时间小于 5 毫秒。
电源供给灵活：支持 AC 115V / 230V 或 24V DC 输入，为模块及 I/O 设备提供稳定电源。
多路输出能力：可输出 +5.0VDC、+4.3VDC、-5.0VDC，不同电压输出满足多类 I/O 模块供电需求。
双通道通信设计：支持主备通信线路，提高系统可靠性和抗干扰能力。
兼容性强：适配 800 系列机架系统，如 H810-208、H819-209、H827-209 等，向下兼容部分旧型号模块。
指示与诊断功能：配有状态指示灯，如电源状态、通信活动、错误状态等，便于故障检测。
技术参数概要：
型号：ASP890300（也称 AS-P890-300）
类型：远程 I/O 通信模块
通信介质：75 欧姆同轴电缆
通信速率：1.544 MHz
输入电源：AC 115V / 230V 或 24V DC
输出电源：+5VDC 7A、+4.3VDC 6A、-5VDC 0.5A（+5V 与 +4.3V 总输出不超过 7A）
状态显示：PWR OK、READY、COMM ACTIVE、COMM ERROR
安装方式：机架式（Modicon 800 系列兼容槽架）
AEG MODICON ASP890300通信模块 英文介绍
AEG MODICON ASP890300 Communication Module
This is a remote I/O communication module for Modicon 800 series systems, belonging to high-performance data transmission and interface units, capable of achieving high-speed and stable communication between the main controller and the remote I/O rack.
Product Features:
Strong remote communication capability: using coaxial cable communication method, supporting long-distance data transmission, with a communication rate of about 1.544 MHz.
High speed data processing: The I/O scanning speed is fast, and the response time is less than 5 milliseconds under 256 point input-output conditions.
Flexible power supply: Supports AC 115V/230V or 24V DC input, providing stable power for modules and I/O devices.
Multi output capability: capable of outputting+5.0VDC,+4.3VDC, and -5.0VDC, with different voltage outputs to meet the power supply needs of various types of I/O modules.
Dual channel communication design: supports primary and backup communication lines to improve system reliability and anti-interference capability.
Strong compatibility: Suitable for 800 series rack systems such as H810-208, H819-209, H827-209, etc., and backward compatible with some old model modules.
Indication and diagnostic function: equipped with status indicator lights, such as power status, communication activity, error status, etc., for easy fault detection.
Technical parameter summary:
Model: ASP890300 (also known as AS-P890-300)
Type: Remote I/O Communication Module
Communication medium: 75 ohm coaxial cable
Communication speed: 1.544 MHz
Input power supply: AC 115V/230V or 24V DC
Output power supply:+5VDC 7A,+4.3VDC 6A, -5VDC 0.5A (total output of+5V and+4.3V does not exceed 7A)
Status display: PWR OK, READY, COMM ACTION, COMM ERROR
Installation method: Rack mounted (Modicon 800 series compatible slot rack)
AEG MODICON ASP890300通信模块 产品展示
