SANYO DENKI PY0A100J0C77B0伺服放大器 PDF资料
1.产 品 资 料 介 绍：
概况
型号：PY0A100J0C77B0
系列：PY 系列伺服放大器（“BL Super / SANMOTION”系列中的一员）
类型：交流伺服驱动器／放大器，用于控制伺服电机的电流、速度、位置等参数
主要特性
适用于驱动中功率等级伺服电机，具备较强的输出能力。
支持位置控制、速度控制、转矩控制等多种模式，适应多样化控制需求。
采用成熟的伺服控制算法（电流环、速度环、位置环），可提升系统响应速度与精度。
内置多重保护功能，包括但不限于：过流保护、过压保护、过热保护、短路保护等，以保障设备和系统安全。
与 SANYO DENKI 的伺服电机、电气反馈器（编码器等）高度兼容，便于整机系统匹配。
支持多种输入接口（如脉冲信号、模拟信号、数字信号等），可灵活连接上位机或运动控制系统。
结构设计较为紧凑，便于安装于工业控制机柜或设备空间中。
散热与耐用设计良好，可满足工业环境连续运行的需求。
提供状态监测和故障报警输出接口，有助于维护、故障诊断与系统监控。
抗电磁干扰能力较强，适合工业现场布线复杂、噪声多的环境。
在选型及集成中可提升自动化系统整体性能与可靠性。
典型应用于数控设备、装配线、机器人系统等对运动性能要求较高的场景。
使用建议
在选型时，应确认该型号的额定输入电压／电流／输出功率是否与所配伺服电机及现场电源系统匹配。
安装时要保证良好的通风散热、合适的安装空间、可靠的接地与屏蔽布线。
接线前应仔细对应编码器反馈、驱动输出、控制信号接口，并按规格进行配置。
在调试阶段需设定合适的增益、加减速时间、位置环／速度环参数，以适应所控制负载的惯性、摩擦及机械特性。
定期监控其状态报警输出、温度、负载情况，以防止因异常而影响系统稳定。
SANYO DENKI PY0A030J05C7B0放大器 英文介绍
Overview
Model: PY0A100J0C77B0
Series: PY series servo amplifier (a member of the "BL Super/SANMOTION" series)
Type: AC servo driver/amplifier, used to control parameters such as current, speed, and position of servo motors
Key Features
Suitable for driving medium power level servo motors with strong output capability.
Support multiple modes such as position control, speed control, torque control, etc., to meet diverse control requirements.
Adopting mature servo control algorithms (current loop, speed loop, position loop) can improve system response speed and accuracy.
Built in multiple protection functions, including but not limited to overcurrent protection, overvoltage protection, overheating protection, short circuit protection, etc., to ensure equipment and system safety.
Highly compatible with SANYO DENKI's servo motors, electrical feedback devices (encoders, etc.), making it easy to match the entire system.
Supports multiple input interfaces (such as pulse signals, analog signals, digital signals, etc.), and can be flexibly connected to upper computers or motion control systems.
The structural design is relatively compact, making it easy to install in industrial control cabinets or equipment spaces.
Good heat dissipation and durable design can meet the continuous operation needs of industrial environments.
Providing status monitoring and fault alarm output interfaces helps with maintenance, fault diagnosis, and system monitoring.
Strong ability to resist electromagnetic interference, suitable for environments with complex wiring and high noise in industrial sites.
In selection and integration, the overall performance and reliability of the automation system can be improved.
Typical applications include CNC equipment, assembly lines, robot systems, and other scenarios that require high motion performance.
Usage recommendations
When selecting, it should be confirmed whether the rated input voltage/current/output power of the model matches the matched servo motor and on-site power system.
During installation, it is necessary to ensure good ventilation and heat dissipation, appropriate installation space, reliable grounding and shielding wiring.
Before wiring, carefully correspond the encoder feedback, drive output, and control signal interfaces, and configure them according to specifications.
During the debugging phase, it is necessary to set appropriate gain, acceleration/deceleration time, position/velocity loop parameters to adapt to the inertia, friction, and mechanical characteristics of the controlled load.
Regularly monitor its status alarm output, temperature, and load conditions to prevent system stability from being affected by abnormalities.
SANYO DENKI PY0A030J05C7B0放大器 产品展示
