SANYO DENKI PY0A030J05C7B0放大器 PDF资料
1.产 品 资 料 介 绍：
概况
型号：PY0A030J05C7B0
所属系列：P 系列伺服放大器（“PY”系列）
制造商：SANYO DENKI
用途：配合伺服电机使用，实现位置／速度／转矩控制
主要特性
适用于中功率伺服系统，能够驱动相应匹配的伺服电机。
支持三相交流输入，常见工业电压等级，适配自动化设备环境。
提供位置控制与速度控制模式，可灵活切换以适应不同任务。
集成电流环、速度环控制算法，提升系统响应速度与控制精度。
内置多重保护机制，如：过流保护、过压保护、过热保护、短路保护等，确保设备运行安全。
与 SANYO DENKI 的伺服电机及编码器系统高度兼容，便于系统整体集成。
支持多种控制信号输入（如脉冲信号、模拟量信号、数字量信号），与上位控制系统（PLC、运动控制器）接口丰富。
结构设计紧凑，便于安装在机柜内或设备空间有限的场景。
散热性能设计良好，可在较长时间连续运行的工业环境中保持稳定。
提供状态监控与报警输出，可实时监控运行状态与故障诊断。
抗电磁干扰能力强，适应复杂的工业现场环境。
广泛应用于数控机床、自动装配线、机器人系统、包装机械等需要中等功率、高精度控制的自动化场合。
使用建议／注意事项
在选型时需确认输入电压是否与现场电源匹配（例如三相200‑230V、50/60Hz 或三相400V 等，应根据具体型号确认）。
与所驱动伺服电机的额定电流、功率、反馈编码器类型必须匹配，以保证系统性能与稳定性。
安装时应保证良好的通风与散热空间，避免因热积累导致保护动作。
接线时应严格按照规格书进行，注意接地、屏蔽、驱动输出与编码器反馈线路，避免信号干扰。
在调试阶段，应对位置环、速度环、增益等参数进行优化，以适应具体机械负载惯量。
若设备为旧机或库存件，应检查放大器是否有维修或更换记录，电解电容是否老化。
SANYO DENKI PY0A030J05C7B0放大器 英文介绍
Overview
Model: PY0A030J05C7B0
Series: P series servo amplifier ("PY" series)
Manufacturer: SANYO DENKI
Purpose: Used in conjunction with servo motors to achieve position/speed/torque control
Key Features
Suitable for medium power servo systems, capable of driving corresponding matching servo motors.
Supports three-phase AC input, common industrial voltage levels, and adapts to automation equipment environments.
Provide position control and speed control modes, which can be flexibly switched to adapt to different tasks.
Integrate current loop and speed loop control algorithms to improve system response speed and control accuracy.
Built in multiple protection mechanisms, such as overcurrent protection, overvoltage protection, overheating protection, short circuit protection, etc., ensure the safe operation of the equipment.
Highly compatible with SANYO DENKI's servo motor and encoder systems, facilitating overall system integration.
Supports multiple control signal inputs (such as pulse signals, analog signals, digital signals), and has rich interfaces with upper control systems (PLC, motion controllers).
Compact structural design, easy to install in cabinets or in scenarios where equipment space is limited.
The heat dissipation performance is well-designed and can maintain stability in industrial environments that operate continuously for a long time.
Provide status monitoring and alarm output, allowing real-time monitoring of operational status and fault diagnosis.
Strong ability to resist electromagnetic interference and adapt to complex industrial site environments.
Widely used in automation applications such as CNC machine tools, automatic assembly lines, robot systems, packaging machinery, etc. that require medium power and high-precision control.
Usage suggestions/precautions
When selecting, it is necessary to confirm whether the input voltage matches the on-site power supply (such as three-phase 200-230V, 50/60Hz, or three-phase 400V, etc., which should be confirmed according to the specific model).
The rated current, power, and feedback encoder type of the driven servo motor must be matched to ensure system performance and stability.
During installation, good ventilation and heat dissipation space should be ensured to avoid protective actions caused by heat accumulation.
When wiring, strict adherence to the specifications should be followed, paying attention to grounding, shielding, driving output, and encoder feedback circuits to avoid signal interference.
During the debugging phase, parameters such as position loop, speed loop, and gain should be optimized to adapt to the specific mechanical load inertia.
If the equipment is an old machine or inventory part, the amplifier should be checked for maintenance or replacement records, and the electrolytic capacitor should be checked for aging.
SANYO DENKI PY0A030J05C7B0放大器 产品展示
