SANYO DENKI PZ0A100HF86S0N伺服放大器 PDF资料
1.产 品 资 料 介 绍：
概况
型号：PZ0A100HF86S0N
制造商：SANYO DENKI（SANMOTION伺服系统系列）
系列类型：BL Super PZ系列伺服放大器
额定电压：AC200V
主要功能与特性
支持高速位置与速度控制，满足高精度伺服应用需求。
采用IGBT驱动与正弦波PWM输出结构，运行平稳，控制精确。
内置过流、过压、过热、短路等多重保护机制，确保安全可靠。
与SANYO DENKI伺服电机配套使用，可实现最佳系统匹配性能。
支持模拟量、脉冲及数字控制信号输入，兼容多种控制方式。
结构紧凑，安装灵活，适用于多种机械设备。
可在位置、速度、转矩三种控制模式间自由切换。
散热性能优异，支持长时间稳定运行。
具备自动或手动增益调整功能，优化伺服响应。
内置故障与状态指示功能，便于监控与维护。
适合数控机床、机器人、包装设备、自动化生产线等场合。
属于成熟稳定的型号，使用维护方便，性能可靠。
使用注意事项
确认供电电压与系统要求匹配（AC200V或三相200–240V）。
搭配兼容的SANYO DENKI伺服电机使用，确保反馈与参数一致。
安装时保持良好通风，避免过热。
按规范接地与屏蔽，防止干扰与故障。
开机前检查电流、增益、编码器分辨率等设定参数。
对二手或旧型号应注意电容老化及维护记录。
运行中留意再生能量处理，防止过载或回馈异常。
SANYO DENKI PZ0A100HF86S0N伺服放大器 英文介绍
Overview
Model: PZ0A100HF86S0N
Manufacturer: SANYO DENKI (SANMOTION servo system series)
Series type: BL Super PZ series servo amplifier
Rated voltage: AC200V
Main functions and features
Support high-speed position and speed control to meet the requirements of high-precision servo applications.
Adopting IGBT drive and sine wave PWM output structure, it runs smoothly and has precise control.
Built in multiple protection mechanisms such as overcurrent, overvoltage, overheating, and short circuit ensure safety and reliability.
When used in conjunction with SANYO DENKI servo motors, it can achieve optimal system matching performance.
Supports analog, pulse, and digital control signal input, compatible with multiple control modes.
Compact structure, flexible installation, suitable for various mechanical equipment.
It can freely switch between three control modes: position, speed, and torque.
Excellent heat dissipation performance, supporting long-term stable operation.
Equipped with automatic or manual gain adjustment function to optimize servo response.
Built in fault and status indication functions for easy monitoring and maintenance.
Suitable for occasions such as CNC machine tools, robots, packaging equipment, automated production lines, etc.
It belongs to a mature and stable model, easy to use and maintain, and reliable in performance.
Precautions for use
Confirm that the power supply voltage matches the system requirements (AC200V or three-phase 200-240V).
Used with compatible SANYO DENKI servo motors to ensure consistency between feedback and parameters.
Maintain good ventilation during installation to avoid overheating.
Grounding and shielding according to specifications to prevent interference and faults.
Before starting up, check the set parameters such as current, gain, and encoder resolution.
Attention should be paid to capacitor aging and maintenance records for second-hand or old models.
Pay attention to regenerative energy processing during operation to prevent overload or abnormal feedback.
SANYO DENKI PZ0A100HF86S0N伺服放大器 产品展示
