SANYO DENKI QS1A05AN0KE08A伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
SANYO DENKI QS1A05AN0KE08A 伺服驱动器
产品概述
QS1A05AN0KE08A 属于山洋电气（SANYO DENKI）SANMOTION Q 系列交流伺服驱动器。它用于控制配套的 Q 系列伺服电机，实现高精度的位置、速度和转矩控制，广泛应用于工业自动化、数控机床及机器人系统。
主要特点
高响应与高精度
内置高速数字信号处理控制器，可快速响应电机变化，实现平稳定位和高精度控制。多种控制模式
支持位置控制、速度控制和转矩控制，可根据不同应用需求灵活切换。可靠性设计
内置过流、过压、欠压、过热及编码器异常保护机制，保证系统安全稳定运行。兼容性强
可与 Q 系列伺服电机和编码器无缝配合，实现系统整合方便。自动调谐与参数优化
支持伺服增益自动调节和参数优化功能，简化调试过程。紧凑模块化
小巧设计便于安装于控制柜或设备机架，并方便散热与维护。
典型技术参数（参考）
适配电机功率：约 0.4 kW ～ 0.75 kW
输入电压：三相 200–230 V AC
控制方式：全数字伺服控制
反馈方式：增量或绝对值编码器
最大脉冲频率：约 500 kHz
冷却方式：自然风冷
安装方式：面板或导轨安装
SANYO DENKI QS1A05AN0KE08A伺服驱动器 英文介绍
SANYO DENKI QS1A05AN0KE08A servo drive
Product Overview
QS1A05AN0KE08A belongs to SANYO DENKI SANMOTION Q series AC servo drive. It is used to control the supporting Q series servo motors, achieving high-precision position, speed, and torque control, and is widely used in industrial automation, CNC machine tools, and robot systems.
Main Features
High response and high precision
Built in high-speed digital signal processing controller, which can quickly respond to motor changes, achieve smooth positioning and high-precision control.
Multiple control modes
Supports position control, speed control, and torque control, and can be flexibly switched according to different application requirements.
reliability design
Built in overcurrent, overvoltage, undervoltage, overheating, and encoder abnormality protection mechanisms ensure the safe and stable operation of the system.
Strong compatibility
It can seamlessly cooperate with Q series servo motors and encoders to achieve convenient system integration.
Automatic tuning and parameter optimization
Support automatic adjustment of servo gain and parameter optimization functions, simplifying the debugging process.
Compact modular design
The compact design is easy to install in control cabinets or equipment racks, and facilitates heat dissipation and maintenance.
Typical technical parameters (reference)
Suitable motor power: approximately 0.4 kW to 0.75 kW
Input voltage: Three phase 200-230 V AC
Control mode: Full digital servo control
Feedback method: incremental or absolute encoder
Maximum pulse frequency: approximately 500 kHz
Cooling method: natural air cooling
Installation method: panel or rail installation
SANYO DENKI QS1A05AN0KE08A伺服驱动器 产品展示
