SANYO DENKI A8PU10ABFW02伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
SANYO DENKI A8PU10ABFW02 伺服驱动器
产品概述：
SANYO DENKI A8PU10ABFW02 属于 PY Super BL 系列伺服放大器，额定输出功率约 1.0 kW，输入电压为单相或三相 200～240 V AC，适用于高精度伺服控制系统。该驱动器采用强制风冷设计，能长时间保持稳定的温升与性能。
主要特点
高性能控制：支持速度、位置与转矩三种控制模式，可与多种类型的伺服电机匹配。
兼容性强：与 SANYO DENKI 的伺服电机及编码器系统完美配合，易于构建完整伺服系统。
高响应速度：具备快速的电流环与速度环控制，可实现精确的动态响应。
多种接口形式：同时支持模拟输入和数字控制信号，便于与 PLC、CNC 或运动控制器连接。
安全与保护功能：内置过流、过压、过热及编码器反馈异常保护机制。
可靠的散热结构：采用风冷方式，适合连续高负载运行。
技术要点
额定功率：约 1.0 kW
输入电压：200～240 V AC，50/60 Hz
驱动方式：三相 PWM 控制
冷却方式：强制风冷
过载能力：可承受 150% 额定电流（30 秒）
控制模式：转矩／速度／位置控制
反馈类型：增量或绝对值编码器信号
使用与选型建议
安装时应保持良好通风环境，避免散热风口受阻。
确认电机参数与驱动器容量相匹配，防止驱动过载。
接线时务必可靠接地并使用屏蔽电缆，以抑制电磁干扰。
若替换旧型号，应核对编码器接口及控制信号兼容性。
SANYO DENKI A8PU10ABFW02伺服驱动器 英文介绍
SANYO DENKI A8PU10ABFW02 servo drive
Product Overview:
SANYO DENKI A8PU10ABFW02 belongs to the PY Super BL series servo amplifier, with a rated output power of about 1.0 kW and an input voltage of single-phase or three-phase 200-240 V AC, suitable for high-precision servo control systems. This drive adopts a forced air cooling design, which can maintain stable temperature rise and performance for a long time.
Main Features
High performance control: supports three control modes: speed, position, and torque, and can be matched with various types of servo motors.
Strong compatibility: Perfectly compatible with SANYO DENKI's servo motor and encoder system, making it easy to build a complete servo system.
High response speed: Equipped with fast current loop and speed loop control, it can achieve precise dynamic response.
Multiple interface forms: Supports both analog input and digital control signals, making it easy to connect with PLC, CNC, or motion controllers.
Safety and protection functions: Built in overcurrent, overvoltage, overheating, and encoder feedback abnormal protection mechanisms.
Reliable heat dissipation structure: using air cooling method, suitable for continuous high load operation.
Technical Points
Rated power: approximately 1.0 kW
Input voltage: 200-240 V AC, 50/60 Hz
Drive mode: Three phase PWM control
Cooling method: forced air cooling
Overload capacity: capable of withstanding 150% of rated current (30 seconds)
Control mode: torque/speed/position control
Feedback type: incremental or absolute encoder signal
Usage and selection suggestions
During installation, a good ventilation environment should be maintained to avoid obstruction of the heat dissipation vents.
Confirm that the motor parameters match the drive capacity to prevent drive overload.
When wiring, it is necessary to ensure reliable grounding and use shielded cables to suppress electromagnetic interference.
If replacing the old model, the compatibility of the encoder interface and control signal should be checked.
SANYO DENKI A8PU10ABFW02伺服驱动器 产品展示
