SANYO DENKI Q2AA18750LBF34伺服电机编码器 PDF资料
1.产 品 资 料 介 绍：
SANYO DENKI Q2AA18750LBF34 是一款高性能 AC 伺服电机，属于 SANMOTION Q 系列。该系列以高精度控制和快速响应著称，而型号中的编码器部分是其实现高精度定位与控制的关键组件。
编码器特点：
高分辨率反馈系统
配备高分辨率光电式或磁电式编码器，常见分辨率范围从 2500 p/rev 到 20 bit 以上（具体依版本而定）。这种精度使电机能实现细微位置控制和极平滑的转速调节。绝对式编码器选项
可支持绝对值编码器版本，断电后仍能保持位置数据，避免复位或原点回归操作，提升系统启动效率与安全性。高速响应性能
编码器输出信号响应频率高，与伺服放大器通讯延迟极低，保证系统在高速运转下仍能精准控制位置与速度。抗干扰能力强
信号接口采用差分输出（如 A/B/Z 或 RS-485 通信），抗噪声性能优异，适用于工业环境中长距离信号传输。与伺服驱动器高匹配度
与 PY、Q、R 系列伺服驱动器完全兼容，支持自动识别与参数同步，提高系统整体性能与调试效率。结构坚固、可靠性高
编码器装配在电机尾部，具备良好的防尘、防振动设计，可在高温及复杂工况下保持信号稳定。
功能作用总结：
Q2AA18750LBF34 的编码器提供电机实时位置与速度反馈，是闭环伺服系统的核心。通过与驱动器的高速数据交换，实现精准位置控制、速度控制及转矩控制。
典型应用场景：
高精度定位设备（如数控机床、半导体设备）
高速装配与搬运机械
自动化生产线与检测设备
印刷、包装机械等需要同步控制的系统
SANYO DENKI Q2AA18750LBF34伺服电机编码器 英文介绍
SANYO DENKI Q2AA18750LBF34 is a high-performance AC servo motor belonging to the SANMOTION Q series. This series is known for its high-precision control and fast response, and the encoder part in the model is a key component for achieving high-precision positioning and control.
Encoder features:
High resolution feedback system
Equipped with high-resolution photoelectric or magneto electric encoders, the common resolution range is from 2500 p/rev to over 20 bits (depending on the version). This precision enables the motor to achieve fine position control and extremely smooth speed adjustment.
Absolute encoder options
It can support absolute value encoder versions and maintain position data even after power failure, avoiding reset or origin regression operations and improving system startup efficiency and safety.
High speed response performance
The encoder output signal has a high response frequency and extremely low communication delay with the servo amplifier, ensuring that the system can accurately control position and speed even at high speeds.
Strong anti-interference ability
The signal interface adopts differential output (such as A/B/Z or RS-485 communication), which has excellent noise resistance and is suitable for long-distance signal transmission in industrial environments.
High compatibility with servo drives
Fully compatible with PY, Q, and R series servo drives, supporting automatic recognition and parameter synchronization, improving overall system performance and debugging efficiency.
Sturdy structure and high reliability
The encoder is installed at the rear of the motor and has good dust-proof and anti vibration design, which can maintain signal stability under high temperature and complex working conditions.
Summary of Function and Function:
The encoder of Q2AA18750LBF34 provides real-time position and speed feedback of the motor, which is the core of the closed-loop servo system. By exchanging high-speed data with the driver, precise position control, speed control, and torque control can be achieved.
Typical application scenarios:
High precision positioning equipment (such as CNC machine tools, semiconductor equipment)
High speed assembly and handling machinery
Automated production line and testing equipment
Systems that require synchronous control for printing, packaging machinery, etc
SANYO DENKI Q2AA18750LBF34伺服电机编码器 产品展示
